FourierDCT[list]

finds the Fourier discrete cosine transform of a list of real numbers.

FourierDCT[list,m]

finds the Fourier discrete cosine transform of type m.

Details
Details and Options Details and Options
Examples
Basic Examples
Scope
Generalizations & Extensions
Applications
Compressing Image Data
Cosine Series Expansion
Chebyshev Basis Expansion
Properties & Relations
Possible Issues
See Also
Tech Notes
Related Guides
History
Cite this Page

FourierDCT

FourierDCT[list]

finds the Fourier discrete cosine transform of a list of real numbers.

FourierDCT[list,m]

finds the Fourier discrete cosine transform of type m.

Details

  • Possible types m of discrete cosine transform for a list of length giving a result are:
  • 1 (DCT-I)
    2 (DCT-II)
    3 (DCT-III)
    4 (DCT-IV)
  • FourierDCT[list] is equivalent to FourierDCT[list,2].
  • The inverse discrete cosine transforms for types 1, 2, 3, and 4 are types 1, 3, 2, and 4, respectively.
  • The list given in FourierDCT[list] can be nested to represent an array of data in any number of dimensions.
  • The array of data must be rectangular.
  • If the elements of list are exact numbers, FourierDCT begins by applying N to them.
  • FourierDCT can be used on SparseArray objects.

Examples

open all close all

Basic Examples  (2)

Find a discrete cosine transform:

Wolfram Language code: FourierDCT[{0, 0, 1, 0, 1}]

Find the inverse discrete cosine transform:

Wolfram Language code: FourierDCT[%, 3]

Find a discrete cosine transform of type 1 (DCT-I):

Wolfram Language code: FourierDCT[{1, 0, 0, 1, 2}, 1]

Find the inverse discrete cosine transform:

Wolfram Language code: FourierDCT[%, 1]

Scope  (2)

Use machine arithmetic to compute the discrete cosine transform:

Wolfram Language code: v = {0, 1, 2, 3, 4, 3, 2, 1, 0};
Wolfram Language code: FourierDCT[v]

Use 24-digit precision arithmetic:

Wolfram Language code: FourierDCT[N[v, 24]]

A two-dimensional discrete cosine transform:

Wolfram Language code: m = RandomReal[1, {3, 4}];
Wolfram Language code: FourierDCT[m]

A five-dimensional discrete cosine transform:

Wolfram Language code: m = RandomReal[1, {5, 5, 5, 5, 5}];
Wolfram Language code: Max[FourierDCT[m]]

Generalizations & Extensions  (2)

The list may have complex values:

Wolfram Language code: FourierDCT[{1, 2I, 3, 4I}]

You can use "I", "II", "III", or "IV" for the types 1, 2, 3, and 4, respectively:

Wolfram Language code: FourierDCT[{0, 0, 1, 0, 0}, "IV"]

Applications  (3)

Compressing Image Data  (1)

Import some image data:

Wolfram Language code: ArrayPlot[data = 256 - Import["ExampleData/ocelot.jpg", "Data"]]

The two-dimensional DCT:

Wolfram Language code: t = FourierDCT[data];

The diagonal spectra shows exponential decay:

Wolfram Language code: ListLogPlot[Abs@Diagonal[t], Joined -> True, PlotRange -> All]

Truncate modes in each axis, effectively compressing by a factor of :

Wolfram Language code: truncate[data_, f_] := Module[{i, j}, {i, j} = Floor[Dimensions[data] / Sqrt[f]]; PadRight[Take[data, i, j], Dimensions[data], 0.] ];

Invert the DCT:

Wolfram Language code: {ArrayPlot[FourierDCT[truncate[t, 4], 3]], ArrayPlot[FourierDCT[truncate[t, 9], 3]], ArrayPlot[FourierDCT[truncate[t, 16], 3]]}

Cosine Series Expansion  (1)

Get an expansion for an even function as a sum of cosines:

Wolfram Language code: f[x_] := Exp[-100(x - 1 / 2) ^ 2];

The function values on a uniformly spaced grid with points on :

Wolfram Language code: n = 25; xg = N[Range[0, n - 1]] / n; fg = Map[f, xg]; fp = ListPlot[Transpose[{xg, fg}], PlotRange -> All]

Compute the DCT-III and renormalize:

Wolfram Language code: cc = FourierDCT[fg, 3] / Sqrt[n];

The function has, in effect, been periodized with a particular symmetry:

Wolfram Language code: Show[fp, Plot[Sum[cc[[r]] * Cos[Pi(r - 1 / 2)x], {r, Length[cc]}], {x, -1, 3}, PlotRange -> All], PlotRange -> All]

Plot the expansion error where the points are defined:

Wolfram Language code: Plot[f[x] - Sum[cc[[r]] * Cos[Pi(r - 1 / 2)x], {r, Length[cc]}], {x, 0, 1 - 1 / n}, PlotRange -> All]

Chebyshev Basis Expansion  (1)

Get an expansion for a function in the Chebyshev polynomials:

Wolfram Language code: f[x_] := 1 / (1 + (5x) ^ 2);

The values of the function at the Chebyshev nodes:

Wolfram Language code: n = 47; cnodes = N[Cos[Pi Range[0, n] / n]]; fc = Map[f, cnodes]; pf = ListPlot[Transpose[{cnodes, fc}], PlotRange -> All]

Find the Chebyshev coefficients:

Wolfram Language code: cc = FourierDCT[fc, 1] * Sqrt[2 / n]; cc[[{1, -1}]] /= 2;

Show the error:

Wolfram Language code: Plot[f[x] - Sum[ChebyshevT[i - 1, x] * cc[[i]], {i, Length[cc]}], {x, -1, 1}, PlotRange -> All]

Properties & Relations  (3)

DCT-I and DCT-IV are their own inverses:

Wolfram Language code: data = RandomReal[1, 7];
Wolfram Language code: Chop[FourierDCT[FourierDCT[data, 1], 1] - data]
Wolfram Language code: Chop[FourierDCT[FourierDCT[data, 4], 4] - data]

DCT-II and DCT-III are inverses of each other:

Wolfram Language code: data = RandomReal[1, 10];
Wolfram Language code: Chop[FourierDCT[FourierDCT[data, 2], 3] - data]
Wolfram Language code: Chop[FourierDCT[FourierDCT[data, 3], 2] - data]

The DCT is equivalent to matrix multiplication:

Wolfram Language code: dctII[n_] := (1/Sqrt[n])Table[Cos[Pi(r - 1 / 2)(s - 1) / n], {s, n}, {r, n}]
Wolfram Language code: MatrixForm[dctII[7]]
Wolfram Language code: data = RandomReal[1, 7];
Wolfram Language code: Chop[dctII[7].data - FourierDCT[data]]

Possible Issues  (1)

FourierDCT always returns normalized results:

Wolfram Language code: TableForm[Table[FourierDCT[ConstantArray[1, 5], type], {type, 1, 4}]]

To get unnormalized results, you can multiply by the normalization:

Wolfram Language code: nc[n_, 1] = Sqrt[(n - 1) / 2]; nc[n_, 2 | 3] = Sqrt[n]; nc[n_, 4] = Sqrt[n / 2];
Wolfram Language code: unnormalizedDCT[data_, type_] := FourierDCT[data, type] * nc[Length[data], type]
Wolfram Language code: TableForm[Table[unnormalizedDCT[ConstantArray[1, 5], type], {type, 1, 4}]]
