FourierDST

FourierDST[list]

finds the Fourier discrete sine transform of a list of real numbers.

FourierDST[list,m]

finds the Fourier discrete sine transform of type .

Details

  • Possible types of discrete sine transform for a list of length giving a result are:
  • 1 (DST-I)
    2 (DST-II)
    3 (DST-III)
    4 (DST-IV)
  • FourierDST[list] is equivalent to FourierDST[list,2].
  • The inverse discrete sine transforms for types 1, 2, 3, 4 are types 1, 3, 2, 4, respectively.
  • The list given in FourierDST[list] can be nested to represent an array of data in any number of dimensions.
  • The array of data must be rectangular.
  • If the elements of list are exact numbers, FourierDST begins by applying N to them.
  • FourierDST can be used on SparseArray objects.

Examples

open all close all

Basic Examples  (2)

Find a discrete sine transform:

Wolfram Language code: FourierDST[{0, 0, 1, 0, 1}]

Find the inverse discrete sine transform:

Wolfram Language code: FourierDST[%, 3]

Find a discrete sine transform of type 1 (DST-I):

Wolfram Language code: FourierDST[{1, 0, 0, 1, 2}, 1]

Find the inverse discrete sine transform:

Wolfram Language code: FourierDST[%, 1]

Scope  (2)

Use machine arithmetic to compute the discrete sine transform:

Wolfram Language code: v = {0, 1, 2, 3, 4, 3, 2, 1, 0};
Wolfram Language code: FourierDST[v]

Use 24‐digit precision arithmetic:

Wolfram Language code: FourierDST[N[v, 24]]

Two-dimensional discrete sine transform:

Wolfram Language code: m = RandomReal[1, {4, 3}];
Wolfram Language code: FourierDST[m]

Four-dimensional discrete sine transform:

Wolfram Language code: m = RandomReal[1, {4, 4, 4, 4}];
Wolfram Language code: Max[FourierDST[m]]

Generalizations & Extensions  (2)

The list may have complex values:

Wolfram Language code: FourierDST[{1, 2I, 3, 4I}]

You can use "I", "II", "III", or "IV" for the types 1, 2, 3, and 4 respectively:

Wolfram Language code: FourierDST[{0, 0, 1, 0, 0}, "IV"]

Applications  (2)

Sine Series Expansion  (1)

Get an expansion for an odd function as a sum of sines:

Wolfram Language code: f[x_] := Exp[-100(x - 1 / 2) ^ 2];

The function values on a uniformly spaced grid with n points on [-L,L):

Wolfram Language code: n = 20; xg = N[Range[n - 1]] / n; fg = Map[f, xg]; fp = ListPlot[Transpose[{xg, fg}], PlotRange -> All]

Compute the DST-I and renormalize:

Wolfram Language code: coef = FourierDST[fg, 1] / Sqrt[n / 2];

The function has, in effect, been periodized with a particular odd symmetry:

Wolfram Language code: Show[fp, Plot[Sum[coef[[r]] * Sin[Pi r x], {r, n - 1}], {x, -1, 1}, PlotRange -> All]]

Plot the expansion error where the points are defined:

Wolfram Language code: Plot[f[x] - Sum[coef[[r]] * Sin[Pi r x], {r, n - 1}], {x, 0, 1 - 1 / n}, PlotRange -> All]

Pseudospectral PDE Discretization  (1)

Approximate the second derivative for a function with zero boundary conditions:

Wolfram Language code: uxx[u_ ? VectorQ] := Module[{n = Length[u]}, FourierDST[-(Pi N[Range[n] / (n + 1)]) ^ 2 FourierDST[u, 1], 1]]
Wolfram Language code: n = 20; xg = N[Range[n]] / (n + 1); u0 = 1 - 2 Abs[xg - .5]; ListPlot[{Transpose[{xg, u0}], Transpose[{xg, uxx[u0]}]}]

Solve the wave equation for a plucked string:

Wolfram Language code: sol = First[NDSolve[{u'[t] == v[t], v'[t] == uxx[u[t]], u[0] == u0, v[0] == ConstantArray[0., n]}, {u, v}, {t, 0, 25}]]

Plot the solution as a surface:

Wolfram Language code: ListPlot3D[Table[u[t] /. sol, {t, 0, 25}], Mesh -> False, DataRange -> {{0, 25}, {0, 1}}]

Properties & Relations  (3)

DST-I and DST-IV are their own inverses:

Wolfram Language code: data = RandomReal[1, 9];
Wolfram Language code: Chop[FourierDST[FourierDST[data, 1], 1] - data]
Wolfram Language code: Chop[FourierDST[FourierDST[data, 4], 4] - data]

DST-II and DST-III are inverses of each other:

Wolfram Language code: data = RandomReal[1, 15];
Wolfram Language code: Chop[FourierDST[FourierDST[data, 2], 3] - data]
Wolfram Language code: Chop[FourierDST[FourierDST[data, 3], 2] - data]

The DST is equivalent to matrix multiplication:

Wolfram Language code: dstII[n_] := (1/Sqrt[n])Table[Sin[Pi(r - 1 / 2)s / n], {s, n}, {r, n}]
Wolfram Language code: MatrixForm[dstII[7]]
Wolfram Language code: data = RandomReal[1, 7];
Wolfram Language code: Chop[dstII[7].data - FourierDST[data]]

Possible Issues  (1)

FourierDST always returns normalized results:

Wolfram Language code: TableForm[Table[FourierDST[ConstantArray[1, 5], type], {type, 1, 4}]]

To get unnormalized results, you can multiply by the normalization:

Wolfram Language code: nc[n_, 1] = Sqrt[(n + 1) / 2]; nc[n_, 2 | 3] = Sqrt[n]; nc[n_, 4] = Sqrt[n / 2];
Wolfram Language code: unnormalizedDST[data_, type_] := FourierDST[data, type] * nc[Length[data], type]
Wolfram Language code: TableForm[Table[unnormalizedDST[ConstantArray[1, 5], type], {type, 1, 4}]]
