MoleculeMesh

MoleculeMesh[mol]

returns a BoundaryMeshRegion object representing the Molecule or BioMolecule mol.

MoleculeMesh[mol,type]

returns a mesh of surface type type.

MoleculeMesh[mol,{type,param1val1,…}]

uses the supplied parameters to create the mesh.

Details and Options

  • Supported mesh types include
  • "Gaussian"Gaussian surface
    "VanDerWaals"Van der Waals surface
    "SolventAccessible"solvent accessible surface
    "BallAndStick"spheres for atoms and cylinders for bonds
  • The "VanDerWaals" surface is a union of spheres for each atom using its van der Waals radius.
  • A Gaussian surface is defined as an isosurface of the scalar field defined by , where xi and ri are the position and radius of the i^(th) atom, respectively, and d is a prefactor. The "Gaussian" surface has the following parameters and default values:
  • "GaussianPrefactor"0.9the parameter d
    "Isosurface"1.1the value of the isosurface
  • The "SolventAccessible" surface has the following parameters and default values:
  • "ProbeRadius"1.4an atom radius that is added to each atom in the molecule
  • MoleculeMesh has the following options:
  • MaxCellMeasure Automaticmax cell measure
    IncludeWaters Falsewhether to include waters of hydration
    IncludeHydrogens Automaticwhether to include hydrogen atoms
  • SurfaceArea and Volume will act on a molecule mesh to return the surface are and volume as real numbers, with units of Angstroms2 and Angstroms3, respectively.

Examples

open all close all

Basic Examples  (2)

Convert a molecule to a boundary mesh:

Wolfram Language code: MoleculeMesh[Molecule["adenosine triphosphate"]]

Create a mesh for the Gaussian surface of this molecule:

Wolfram Language code: MoleculeMesh[Molecule["adenosine triphosphate"], "Gaussian"]

Convert a biomolecule to a boundary mesh:

Wolfram Language code: MoleculeMesh[BioMolecule[ExternalIdentifier["PDBStructureID", "1PPT"]], "Gaussian"]

Scope  (3)

Create a mesh region showing the atoms and bonds as spheres and tubes:

Wolfram Language code: m = Molecule["biotin sulfone"]; MoleculeMesh[m, "BallAndStick"]

Show the same molecule with no bonds and atoms represented as spheres with their van der Waals radii:

Wolfram Language code: MoleculeMesh[m, "VanDerWaals"]

Use different parameter settings for the "Gaussian" surface:

Wolfram Language code: MoleculeMesh[Molecule["caffeine"], {"Gaussian", "GaussianPrefactor" -> .5, "Isosurface" -> .5}]
Wolfram Language code: MoleculeMesh[Molecule["caffeine"], {"Gaussian", "GaussianPrefactor" -> 1.5, "Isosurface" -> 2.5}]

Combine a Gaussian mesh with a ribbon diagram from BioMoleculePlot3D to show the ribbons in place:

Wolfram Language code: Show[ MoleculeMesh[bm = BioMolecule[ExternalIdentifier["PDBStructureID", "2H3S"]], "Gaussian", MeshCellStyle -> {2 -> Opacity[0.5]}], BioMoleculePlot3D[bm] ]

Options  (3)

IncludeHydrogens  (1)

Control whether hydrogen atoms are included in the mesh:

Wolfram Language code: MoleculeMesh[Molecule["octane"], IncludeHydrogens -> #]& /@ {All, None}

IncludeWaters  (1)

Some biomolecules have extra water molecules taken from the crystal structure. These typically have no hydrogens attached. By default, these are not included in a MoleculeMesh output. Use the option IncludeWatersTrue to show the waters:

Wolfram Language code: Show[ MoleculeMesh[BioMolecule[ExternalIdentifier["PDBStructureID", "3NIR"]], BaseStyle -> Red], MoleculeMesh[BioMolecule[ExternalIdentifier["PDBStructureID", "3NIR"]], IncludeWaters -> True, BaseStyle -> {ColorData[97][2], Opacity[0.5]}] ]

MaxCellMeasure  (1)

Use the option MaxCellMeasure to control the mesh quality:

Wolfram Language code: Table[MoleculeMesh[Molecule["adenosine triphosphate"], MaxCellMeasure -> mcm], {mcm, {0.1, 0.5, 1.0}}]

Neat Examples  (2)

Start with two different conformers for a metacyclophane molecule:

Wolfram Language code: {open, closed} = {Molecule[{"C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H"}, {Bond[{1, 2}, "Aromatic"], Bond[{2, 3}, " ... 76}, {0.6831232154052924, -4.0285717933215155, 1.1081934685316917}, {-0.9262392601471943, -2.5175472725588364, 2.4624327671626323}, {-1.4434860342175224, -3.33439958979902, 1.0428035282432913}}, "Angstroms", {{1}, {2}}}]]}], Molecule[{"C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "C", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H", "H"}, {Bond[{1, 2}, "Aromatic"], Bond[{2, 3}, " ... 02}, {-0.6217270037327405, 3.9282380552832916, -1.7914369796330016}, {1.6101569706934553, 3.189352838787685, -1.5971355600030785}, {0.8578376108664171, 3.513517457137615, -0.05199782925204585}}, "Angstroms", {{1}, {2}}}]]}]};

View the ball-and-stick mesh regions:

Wolfram Language code: MoleculeMesh[#, "BallAndStick"]& /@ {open, closed}

Create Gaussian surfaces for these conformers:

Wolfram Language code: MoleculeMesh[#, "Gaussian"]& /@ {open, closed}

Find the surface area and volume:

Wolfram Language code: Comap[{SurfaceArea, Volume}] /@ %

Find the isomers of decane with the smallest and largest surface areas:

Wolfram Language code: decanes = Molecule /@ IconizedObject[«decane isomer SMILES»]; TakeLargestBy[decanes, SurfaceArea @* MoleculeMesh, 2]

A greater degree of branching leads to a decrease in the surface area:

Wolfram Language code: TakeSmallestBy[decanes, SurfaceArea @* MoleculeMesh, 2]

Create a scatter plot of the volume versus surface area for these isomers:

Wolfram Language code: ListPlot[Tooltip[{Volume[MoleculeMesh[#]], SurfaceArea[MoleculeMesh[#]]}, MoleculePlot[#]]& /@ decanes]
