NicholsGridLines

NicholsGridLines

is an option to NicholsPlot that specifies contours of constant magnitude and constant phase of the closed-loop system.

Details

  • The following settings can be given:
  • Noneno contours drawn
    Automaticcontours chosen automatically
    {magnitude,phase}contours specified by magnitude and phase are drawn
  • The magnitude values are the absolute values.
  • The phase values are in radians.
  • The following settings can be given for magnitude and phase:
  • Noneno contours drawn
    Automaticcontours chosen automatically
    {c1,c2,…}draw the contours ci
    {{c1,style1,r1},…}contours with specified styles and regions
  • The default style of a magnitude contour is Dashed, and the default style of a phase contour is Dotted.
  • The setting ri specifies that a point should be included if ri[x,y,ci] yields True.
  • The default value of ri is Automatic.

Examples

open all close all

Basic Examples  (1)

Show the closed-loop magnitude and phase contours:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{5*(-1 + s)}}, s^2*(4 + s + s^2)}, s], NicholsGridLines -> Automatic]

Scope  (8)

Choose contours automatically:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> Automatic]

Show specific magnitude and phase contours:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> {{0.01, 0.05, 0.2, 0.5, 1.1, 1.25, 2}, Range[-60, 60, 10]Degree}]

Use different contour styles:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> {{0.01, 0.05, 0.2, 0.5, {1.1, Directive[Dashed, Green]}, {1.25, Directive[Dashed, Yellow]}, {2, Directive[Dashed, Red]}}, {{-60 Degree, Green}, -50 Degree, -40 Degree, {-30 Degree, Yellow}, -20Degree, -10Degree, 0, 10Degree, 20Degree, {30Degree, Yellow}, 40Degree, 50Degree, {60Degree, Green}}}]

Specify different regions:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> {{0.01, 0.05, 0.2, 0.5, {1.1, Directive[Dashed, Green], #2 > -5&}, {1.25, Directive[Dashed, Yellow]}, {2, Directive[Dashed, Red]}}, {{-60 Degree, Green}, -50 Degree, -40 Degree, {-30 Degree, Yellow, True&}, -20Degree, -10Degree, 0, 10Degree, 20Degree, {30Degree, Yellow, True&}, 40Degree, 50Degree, {60Degree, Green}}}]

Magnitude contours with specific dB values:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> {10^(#/20)& /@ {10, 5, 3, 2, 1, -1, -2, -5, -10, -20, -35}, None}]

Specify contours with phase from -70 to 70 degrees in increments of 5:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> {None, Range[-70, 70, 5] Degree}]

The contours depend on the type of feedback:

Wolfram Language code: GraphicsRow@Table[NicholsPlot[TransferFunctionModel[{{{1}}, s*(1 + s)*(1 + 2*s)}, s], NicholsGridLines -> Automatic, FeedbackType -> f, PlotLabel -> Style["Feedback Type: " <> ToString@f, Italic]], {f, {"Negative", "Positive", None}}]

A discrete-time system:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{0.25 + z}}, (-0.25 + z)*z}, z, SamplingPeriod -> 1], NicholsGridLines -> Automatic]

Applications  (1)

Estimate closed-loop magnitude and phase values at various frequencies:

Wolfram Language code: NicholsPlot[TransferFunctionModel[{{{30}}, s*(1 + s)*(2 + s)* (3 + s)}, s], Mesh -> {{0.5, 1, 2, 4}}, MeshStyle -> Directive[PointSize[Medium], Red], NicholsGridLines -> Automatic]
