Slider[x]

represents a slider with setting x in the range 0 to 1.

Slider[Dynamic[x]]

takes the setting to be the dynamically updated current value of x, with the value of x being reset if the slider is moved.

Slider[x,{xmin,xmax}]

represents a slider with range xmin to xmax.

Slider[x,{xmin,xmax,dx}]

represents a slider that jumps in steps dx.

Slider[x,{{e1,e2,…}}]

represents a slider in which equally spaced intervals correspond to successive settings ei.

Slider[x,{{{e1,w1},{e2,w2},…}}]

uses intervals of relative widths wi for the ei.

Details and Options
Details and Options Details and Options
Examples
Basic Examples
Scope
Options
Appearance
AutoAction
Background
Show More Show More
BaselinePosition
ContinuousAction
Enabled
Exclusions
ImageMargins
ImageSize
Applications
Possible Issues
Neat Examples
See Also
Tech Notes
Related Guides
Related Workflows
Related Links
History
Cite this Page

Slider

Slider[x]

represents a slider with setting x in the range 0 to 1.

Slider[Dynamic[x]]

takes the setting to be the dynamically updated current value of x, with the value of x being reset if the slider is moved.

Slider[x,{xmin,xmax}]

represents a slider with range xmin to xmax.

Slider[x,{xmin,xmax,dx}]

represents a slider that jumps in steps dx.

Slider[x,{{e1,e2,…}}]

represents a slider in which equally spaced intervals correspond to successive settings ei.

Slider[x,{{{e1,w1},{e2,w2},…}}]

uses intervals of relative widths wi for the ei.

Details and Options

  • Slider[…] displays in a notebook as a horizontal slider that can be manipulated interactively.
  • Slider[Dynamic[x]] will reset the value of x when the slider is moved; Slider[x] will not.
  • Slider[n,{nmin,nmax,dn}] jumps to integer positions if nmin and dn are integers. »
  • Slider[x,{xmin,xmax,dx}] in general jumps to positions given by Range[xmin,xmax,dx]. »
  • Slider[x] represents a slider running from left to right.
  • Slider[x,{xmax,xmin}] with xmax > xmin represents a slider running from right to left. »
  • If the value of the slider is outside the range given, it will be displayed at one of the ends.
  • Slider[x,{0,1,dx}] displays at position x, even if this is not a multiple of dx.
  • In Slider[x,{{e1,e2,…}}], the ei can be any expressions, not just numbers. »
  • The following options can be given:
  • Appearance Automaticthe overall appearance of the slider
    AutoAction Falsewhether to move the slider automatically when the mouse is over it
    BaselinePosition Automaticalignment relative to surrounding text
    BaseStyle{}base style specifications for the slider
    ContinuousAction Truewhether to update continuously when the slider is moved
    Enabled Automaticwhether the slider is enabled or grayed out
    Exclusions {}specific values to be excluded
    ImageMargins 0margins around the image of the displayed slider
    ImageSize Automaticthe overall image size of the displayed slider
  • Possible settings for Appearance include Tiny, Small, Medium, and Large, as well as typically some other settings such as "UpArrow" and "DownArrow".
  • Appearance->"Labeled" displays the current value of the slider as an editable label.
  • The settings for BaseStyle are appended to the default style typically given by the "Slider" style in the current stylesheet.
  • Slider[] is equivalent to Slider[0.5].
  • The resulting slider can be finely manipulated by holding down the key (or on Macintosh) while dragging the mouse. This causes the slider to move at 1/20 the rate of the mouse. The slider can be even more finely manipulated by also holding the and/or keys.

Examples

open all close all

Basic Examples  (3)

A slider set at in the default range to :

Wolfram Language code: Slider[0.8]

A slider with its value updated dynamically:

Wolfram Language code: {Slider[Dynamic[x]], Dynamic[x]}

A slider with integer values in the range to :

Wolfram Language code: {Slider[Dynamic[n], {0, 100, 1}], Dynamic[n]}

Scope  (5)

Use the range to , increasing when going from left to right:

Wolfram Language code: x = 0;{Slider[Dynamic[x], {-1, 1}], Dynamic[x]}

A slider with range to , increasing when going from right to left:

Wolfram Language code: y = 0;{Slider[Dynamic[y], {1, -1}], Dynamic[y]}

Use only integer variable values:

Wolfram Language code: {Slider[Dynamic[n], {0, 100, 1}], Dynamic[n]}

Use rational steps:

Wolfram Language code: {Slider[Dynamic[x], {0, 1, 1 / 5}], Dynamic[x]}

Use slider increments of π:

Wolfram Language code: {Slider[Dynamic[y], {0, 10Pi, Pi}], Dynamic[y]}

Use a symbolic range:

Wolfram Language code: {Slider[Dynamic[z], {a, 20a, 2a}], Dynamic[z]}

Use a list of possible values:

Wolfram Language code: {Slider[Dynamic[x], {{a, 2, True}}], Dynamic[x]}

Change the relative width corresponding to each possible value:

Wolfram Language code: {Slider[Dynamic[x], {{{a, 10}, {2, 5}, {True, 20}}}], Dynamic[x]}

Options  (20)

Appearance  (4)

Different sizes:

Wolfram Language code: Table[Slider[0.5, Appearance -> a], {a, {Tiny, Small, Medium, Large}}]

Add a label:

Wolfram Language code: Slider[0.5, Appearance -> "Labeled"]

Special arrow appearances are available on some platforms:

Wolfram Language code: Table[Slider[Appearance -> a], {a, {"UpArrow", "DownArrow"}}]

Use dynamic appearance, based on whether Round[x] is or :

Wolfram Language code: {Slider[Dynamic[x], Appearance -> Dynamic[If[Round[x] == 1, "UpArrow", "DownArrow"]]], Dynamic[Round[x]]}

AutoAction  (2)

By default, no slider values change until you click in the slider area:

Wolfram Language code: {Slider[Dynamic[x]], Dynamic[x]}

By setting AutoAction, the slider values change as the mouse moves over the slider area:

Wolfram Language code: {Slider[Dynamic[x], AutoAction -> True], Dynamic[x]}

Background  (2)

Change the background colors:

Wolfram Language code: Table[Slider[0.5, Background -> c], {c, {Pink, Green, Gray, Yellow}}]

Change the background color dynamically:

Wolfram Language code: Slider[Dynamic[x], Background -> Dynamic[Hue[x]]]

BaselinePosition  (2)

Align with the surrounding text:

Wolfram Language code: Row[Table[Slider[0.5, ImageSize -> 100, BaselinePosition -> p], {p, {Top, Center, Bottom}}], "xxx"]

Dynamically change the baseline position:

Wolfram Language code: {"x", Slider[Dynamic[x], {{Top, Center, Bottom}}, BaselinePosition -> Dynamic[x]], "x"}//Row

ContinuousAction  (2)

By default, variables are continuously updated:

Wolfram Language code: {Slider[Dynamic[x]], Dynamic[x]}

Setting ContinuousAction to False makes variables update only when the slider is released:

Wolfram Language code: {Slider[Dynamic[y], ContinuousAction -> False], Dynamic[y]}

Enabled  (2)

By default, Slider is enabled:

Wolfram Language code: Slider[0.5]

By setting Enabled->False, the slider is disabled but visible in its current state:

Wolfram Language code: Slider[0.3, Enabled -> False]

Exclusions  (1)

Exclude values from the range:

Wolfram Language code: {Slider[Dynamic[x], {0, 1, 0.2}, Exclusions -> {0.4, 0.8}], Dynamic[x]}

ImageMargins  (1)

By setting ImageMargins, you make the slider area larger:

Wolfram Language code: Table[Slider[0.5, ImageMargins -> m, Background -> Pink], {m, {0, 5, 10, 20}}]

ImageSize  (4)

Use preset values:

Wolfram Language code: Column[Table[Slider[0.5, ImageSize -> i], {i, {Tiny, Small, Medium, Large}}]]

Or use any values:

Wolfram Language code: Column[Table[Slider[0.5, ImageSize -> i], {i, {50, 150, 300, 500}}]]

By setting the second element, you can also control the height reserved by the slider:

Wolfram Language code: Slider[0.5, ImageSize -> {Automatic, 50}]

A fully custom image size:

Wolfram Language code: Slider[ImageSize -> {400, 50}]

Applications  (2)

Selecting the n^(th) prime:

Wolfram Language code: DynamicModule[{n = 1000}, {Slider[Dynamic[n], {1, 10^5, 1}], Subscript[p, Dynamic[n]]⟶Dynamic[Prime[n]]}]

Selecting the n^(th) digit in the decimal expansion of π:

Wolfram Language code: DynamicModule[{n = 10000}, {Slider[Dynamic[n], {1, 10^5, 1}], Subscript[π, Dynamic[n]]⟶Dynamic[First@First@RealDigits[Pi, 10, 1, -n]]}]

A color selector:

Wolfram Language code: DynamicModule[{red = 0, green = 0, blue = 0}, Column[{Grid[{ {Graphics[{Red, Rectangle[]}, ImageSize -> 30], Slider[Dynamic[red]]}, {Graphics[{Green, Rectangle[]}, ImageSize -> 30], Slider[Dynamic[green]]}, {Graphics[{Blue, Rectangle[]}, ImageSize -> 30], Slider[Dynamic[blue]]}}], Dynamic[Graphics[{RGBColor[Dynamic[red], Dynamic[green], Dynamic[blue]], Disk[]}]]}]]

Possible Issues  (1)

Appearances provided by the operating system may be different or unavailable on other platforms:

Wolfram Language code: Slider[0.5, Appearance -> "UpArrow"]

Generic appearances are available on all platforms:

Wolfram Language code: Style[Slider[0.5, Appearance -> "UpArrow"], ControlsRendering -> "Generic"]

Neat Examples  (1)

Randomly sized sliders:

Wolfram Language code: DynamicModule[{x = RandomReal[]}, Column[Table[Slider[Dynamic[x], ImageSize -> RandomReal[200]], {10}]]]
