ZIP (.zip)

  • Import and Export fully support the ZIP format.
  • Import and Export can work with general ZIP archives as well as with specific application formats consisting of multiple related files.

Background & Context

    • Registered MIME type: application/zip
    • Popular data compression and archival format.
    • Used to reduce storage space and transfer times.
    • Binary format.
    • Can contain multiple files.
    • Supports a variety of compression methods.
    • Published by Phil Katz in 1989.

Import & Export

  • When importing files from a ZIP archive, the specific converter for each format will be used.
  • Import["file.zip"] returns an expression of the form {"fn1", "fn2",…}, giving full path specifications for all files in "file.zip".
  • Import["file.zip",elem] imports the specified element from a ZIP file.
  • Import["file.zip","fn"] extracts "fn" from the archive and imports it.
  • Import["file.zip",{elem,suba,subb,…}] imports a subelement.
  • Import["file.zip",{{elem1,elem2,…}}] imports multiple elements.
  • Import["file","ZIP"] or Import["file",{"ZIP",elem,…}] imports any file as a ZIP archive.
  • Export["file.zip",expr,elem] creates a ZIP archive by treating expr as specifying element elem.
  • Export["file.zip",{expr1,expr2,…},{{elem1,elem2,…}}] treats each expri as specifying the corresponding elemi.
  • Export["file.zip","fn"->expr] exports expr to a file and compresses it as a ZIP archive, inferring the file format from the file extension of "fn".
  • Export["file.zip","fn1"->expr1,"fn2"->expr2,…] exports multiple expressions to a ZIP file archive.
  • See the following reference pages for full general information:
  • Import, Exportimport from or export to a file
    CloudImport, CloudExportimport from or export to a cloud object
    ImportString, ExportStringimport from or export to a string
    ImportByteArray, ExportByteArrayimport from or export to a byte array

Import Elements

  • General Import elements:
  • "Elements" list of elements and options available in this file
    "Summary"summary of the file
    "Rules"list of rules for all available elements
  • The following can be used to select or specify individual files in a ZIP archive:
  • "FileNames"list of filenames representing the contents of a ZIP archive
    "filename"a single file
    "filename","format" a single file, taken to be in the specified format
    "filename","format",elemelement elem from the specified file
  • Import by default uses the "FileNames" element for the ZIP format.
  • Import["file.zip","fn"] extracts and imports file "fn".
  • File names can include relative or absolute directory specifications and the abbreviated string patterns supported by StringMatchQ.
  • Import["file.zip","*"] imports an entire archive.
  • Import["file.zip","dir/*.jpg"] imports all JPEG files from subdirectory dir.
  • Export["file.zip","file1.gif"->expr1,"file2.txt"->expr2] creates a ZIP archive containing a GIF and a text file.
  • Export["file",{expr1,expr2},{"ZIP",{{"file1","GIF"},{"file2","Text"}}}] is equivalent to the above.

Options

  • General Export option:
  • CompressionLevelAutomaticZIP compression strength, given as a number in the range 0 to 1
  • The setting CompressionLevel->1 corresponds to the strongest available compression, resulting in the smallest possible file size.

Examples

open all close all

Basic Examples  (1)

This creates a ZIP archive containing a GIF and a text file:

Wolfram Language code: Export["test.zip", <|"a.gif" -> \!\(\*GraphicsBox[«3»]\), "b.txt" -> "earth seen from space"|>, "Rules" ];

Importing a ZIP archive gives the names of the files in the archive by default:

Wolfram Language code: Import["test.zip"]

Import all files using their default element:

Wolfram Language code: Import["test.zip", "*"]

Extract and import the GIF file:

Wolfram Language code: Import["test.zip", "a.gif"]

Extract and import all text files:

Wolfram Language code: Import["test.zip", "*.txt"]

Scope  (1)

Elements for a ZIP archive:

Wolfram Language code: Export["test.zip", <|"a.gif" -> \!\(\*GraphicsBox[«3»]\), "b.fa" -> {"TTTCG", "GATAG"}, "c.col" -> {{0, 1, 1, 1}, {1, 0, 1, 1}, {1, 1, 0, 1}, {1, 1, 1, 0}}|>, "Rules" ];
Wolfram Language code: Import["test.zip", "Elements"]

Extract available elements for one of the files in the ZIP archive:

Wolfram Language code: Import["test.zip", {"a.gif", "Elements"}]

Import some elements from one of the files in the archive:

Wolfram Language code: Import["test.zip", {"a.gif", {"ColorSpace", "Image"}}]

Import the default element for multiple files with different formats:

Wolfram Language code: Import["test.zip", "*"]

Import Elements  (1)

"FileNames"  (1)

Get the names of all files in a ZIP archive:

Wolfram Language code: Export["test.zip", <|"a.gif" -> \!\(\*GraphicsBox[«3»]\), "b.txt" -> "earth seen from space"|>, "Rules" ];
Wolfram Language code: Import["test.zip", "FileNames"]

This is also the default element:

Wolfram Language code: Import["test.zip"]

Export Options  (1)

CompressionLevel  (1)

Get some text to export:

Wolfram Language code: data = <|"a.txt" -> ExampleData[{"Text", "DeclarationOfIndependence"}], "b.txt" -> ExampleData[{"Text", "AliceInWonderland"}]|>;

By default, the maximum amount of compression is used:

Wolfram Language code: ExportString[data, "ZIP"]//ByteCount

This is equivalent to CompressionLevel1:

Wolfram Language code: ExportString[data, "ZIP", CompressionLevel -> 1]//ByteCount

Specify the minimum amount of compression:

Wolfram Language code: ExportString[data, "ZIP", CompressionLevel -> 0]//ByteCount

Properties & Relations  (2)

Get some text to export:

Wolfram Language code: data = <|"a.txt" -> StringJoin[ConstantArray[ExampleData[{"Text", "DeclarationOfIndependence"}], 3]], "b.txt" -> StringJoin[ConstantArray[ExampleData[{"Text", "AliceInWonderland"}], 5]]|>;

Compare ZIP, TARGZ, TARBZ2 and TARZST compression to the uncompressed size:

Wolfram Language code: formats = {"Text", "ZIP", {"GZIP", "TAR"}, {"BZIP2", "TAR"}, {"ZSTD", "TAR"}}; BarChart[ByteCount[ExportString[data, #]]& /@ formats, ...]

Compare ZIP, TARGZ, TARBZ2 and TARZST compression speeds:

Wolfram Language code: formats = {"ZIP", {"GZIP", "TAR"}, {"BZIP2", "TAR"}, {"ZSTD", "TAR"}}; BarChart[Round[First[AbsoluteTiming[ExportString[data, #]]], .001]& /@ formats, ChartLabels -> Placed[{"ZIP", "TARGZ", "TARBZ2", "TARZST"}, Above], LabelingFunction -> Bottom, Ticks -> None]

The amount of compression depends on the data being compressed. For example, JPEG images are already compressed and cannot be compressed any further by ZIP:

Wolfram Language code: ByteCount[ExportString[\!\(\*GraphicsBox[«3»]\), "JPEG"]]
Wolfram Language code: ByteCount[ExportString[<|"a.jpeg" -> \!\(\*GraphicsBox[«4»]\)|>, "ZIP"]]
