Arrow[{pt1,pt2}]

is a graphics primitive that represents an arrow from pt1 to pt2.

Arrow[{pt1,pt2},s]

represents an arrow with its ends set back from pt1 and pt2 by a distance s.

Arrow[{pt1,pt2},{s1,s2}]

sets back by s1 from pt1 and s2 from pt2.

Arrow[curve,…]

represents an arrow following the specified curve.

Details
Details and Options Details and Options
Examples
Basic Examples
Scope
Arrow Specification
Arrow Styling
Coordinate Specification
Applications
Properties & Relations
Neat Examples
See Also
Related Guides
Related Links
History
Cite this Page

Arrow

Arrow[{pt1,pt2}]

is a graphics primitive that represents an arrow from pt1 to pt2.

Arrow[{pt1,pt2},s]

represents an arrow with its ends set back from pt1 and pt2 by a distance s.

Arrow[{pt1,pt2},{s1,s2}]

sets back by s1 from pt1 and s2 from pt2.

Arrow[curve,…]

represents an arrow following the specified curve.

Details

  • Arrow can be used in both Graphics and Graphics3D (two- and three-dimensional graphics).
  • The following curve specifications can be used in Graphics:
  • Line[…]piecewise line segments
    BezierCurve[…]composite Bezier curve
    BSplineCurve[…]B-spline curve
    JoinedCurve[…]joined curve object
  • The following curve specifications can be used in Graphics3D:
  • Line[…]piecewise line segments
    BezierCurve[…]composite Bezier curve
    BSplineCurve[…]B-spline curve
    Tube[…]tubed curve object
  • Arrow[Line[…]] is equivalent to Arrow[…]. Arrow[Tube[…]] yields a 3D arrow based on a tube.
  • Arrow[{pt1,pt2,…}] represents an arrow whose shaft passes through the sequence of points pti.
  • The positions of points can be specified either in ordinary coordinates as {x,y}, or in scaled coordinates as Scaled[{x,y}] or using ImageScaled or Offset. »
  • The shaft of the arrow consists of a sequence of straight segments joining the specified points.
  • Arrow[{pt1,pt2}] is drawn by default with its tail at pt1 and its head at pt2.
  • The form, orientation, and position of arrowheads can be specified by an Arrowheads directive. »
  • Graphics directives such as RGBColor or Thickness apply to both the shaft and arrowhead elements of an arrow. »
  • You can prevent directives from applying to an arrowhead by including explicit directives within the graphic used to specify the arrowhead.
  • In Arrow[{pt1,pt2},s] the setback distance s is measured in the ordinary coordinate system of the whole graphic, so that the arrow will just touch Disk[pti,s]. »
  • If the whole graphic does not have AspectRatio->Automatic, then a specified arrow setback may correspond to different distances in different directions in the graphic.

Examples

open all close all

Basic Examples  (6)

A 2D arrow primitive:

Wolfram Language code: Graphics[Arrow[{{1, 0}, {2, 1}, {3, 0}, {4, 1}}]]

A 3D arrow primitive:

Wolfram Language code: Graphics3D[Arrow[{{1, 1, -1}, {2, 2, 0}, {3, 3, -1}, {4, 4, 0}}]]

A full 3D arrow primitive using tubes:

Wolfram Language code: Graphics3D[{Red, Arrowheads[0.1], Arrow[Tube[{{1, 1, -1}, {2, 2, 0}, {3, 3, -1}, {4, 4, 0}}, 0.05]]}]

Curved arrows:

Wolfram Language code: {Graphics[{Arrow[BezierCurve[{{0, 0}, {1, 1}, {2, -1}}]]}], Graphics3D[{Arrow[BSplineCurve[{{0, 0, 0}, {1, 1, 1}, {2, -1, 1}, {3, 0, 2}}]]}]}

Double-headed arrows:

Wolfram Language code: {Graphics[{Arrowheads[{-.1, .1}], Arrow[{{0, 0}, {1, 1 / 3}}]}], Graphics3D[{Arrowheads[{-.1, .1}], Arrow[{{0, 0, 0}, {2, 1, 1}}]}], Graphics3D[{Arrowheads[{-.1, .1}], Arrow[Tube[{{0, 0, 0}, {2, 1, 1}}]]}]}

Differently styled 2D arrows:

Wolfram Language code: a = {Arrowheads[Large], Arrow[{{0, 0}, {1, .5}}]};
Wolfram Language code: {Graphics[{Dashed, a}], Graphics[{Red, a}], Graphics[{Thick, a}], Graphics[{Thick, Dashed, Red, a}]}

Scope  (17)

Arrow Specification  (7)

Straight arrow:

Wolfram Language code: Graphics[Arrow[{{0, 0}, {2, 1}}]]

Jagged arrow:

Wolfram Language code: Graphics[Arrow[{{0, 0}, {2, 1}, {4, 0}}]]

Line and tube arrows:

Wolfram Language code: {Graphics[Arrow[Line[{{0, 0}, {2, 1}}]]], Graphics3D[Arrow[Line[{{0, 0, 0}, {2, 1, 1}}]]], Graphics3D[Arrow[Tube[{{0, 0, 0}, {2, 1, 1}}]]]}

Curved arrows:

Wolfram Language code: {Graphics[Arrow[BezierCurve[{{0, 0}, {1, 2}, {4, 2}}]]], Graphics3D[Arrow[BSplineCurve[{{0, 0, 0}, {1, 2, 2}, {4, 2, 2}}]]], Graphics3D[Arrow[Tube[BSplineCurve[{{0, 0, 0}, {1, 2, 2}, {4, 2, 2}}]]]]}

Multiple disconnected arrows:

Wolfram Language code: s = {{0, 0}, {2, 1.5}, {4, 0}};
Wolfram Language code: {Graphics[Arrow[Line[{s, s + 1}]]], Graphics[Arrow[BezierCurve[{s, s + 1}]]]}

Specify the setback distance for 2D arrows:

Wolfram Language code: {Graphics[{Arrow[{{0, 0}, {2, 1}}], Circle[{2, 1}, .3]}], Graphics[{Arrow[{{0, 0}, {2, 1}}, .3], Circle[{2, 1}, .3]}]}

For curved arrows:

Wolfram Language code: {Graphics[{Arrow[BSplineCurve[{{0, 0}, {1, -1}, {2, 1}}]], Circle[{2, 1}, .3]}], Graphics[{Arrow[BSplineCurve[{{0, 0}, {1, -1}, {2, 1}}], .3], Circle[{2, 1}, .3]}]}

Specify the setback distance for 3D arrows with line shaft:

Wolfram Language code: {Graphics3D[{Opacity[.8], Arrow[{{0, 0, 0}, {2, 1, 0}}], Sphere[{2, 1, 0}, .3]}], Graphics3D[{Opacity[.8], Arrow[{{0, 0, 0}, {2, 1, 0}}, .3], Sphere[{2, 1, 0}, .3]}]}

Arrow Styling  (7)

Arrows with different thicknesses:

Wolfram Language code: Table[Graphics[{Thickness[i], Arrow[{{0, 0}, {2, 1}}]}], {i, {Tiny, Small, Medium, Large}}]
Wolfram Language code: Table[Graphics3D[{Thickness[i], Arrow[{{0, 0, 0}, {2, 1, 1}}]}], {i, {Tiny, Small, Medium, Large}}]

Dashed arrows:

Wolfram Language code: {Graphics[{Dashed, Arrow[{{0, 0}, {2, 1}}]}], Graphics[{Dotted, Arrow[{{0, 0}, {2, 1}}]}], Graphics[{DotDashed, Arrow[{{0, 0}, {2, 1}}]}]}
Wolfram Language code: {Graphics3D[{Dashed, Arrow[{{0, 0, 0}, {2, 1, 1}}]}], Graphics3D[{Dotted, Arrow[{{0, 0, 0}, {2, 1, 1}}]}], Graphics3D[{DotDashed, Arrow[{{0, 0, 0}, {2, 1, 1}}]}]}

Colored arrows:

Wolfram Language code: Table[Graphics[{c, Arrow[{{0, 0}, {2, 1}}]}], {c, {Red, Green, Blue}}]
Wolfram Language code: Table[Graphics3D[{c, Arrow[{{0, 0, 0}, {2, 1, 1}}]}], {c, {Red, Green, Blue}}]

Two-dimensional arrows with different sizes of arrowheads:

Wolfram Language code: Table[Graphics[{Arrowheads[i], Arrow[{{0, 0}, {1, .5}}]}], {i, {Tiny, Small, Medium, Large}}]
Wolfram Language code: Table[Graphics[{Arrowheads[i], Arrow[BezierCurve[{{0, 0}, {1, -1}, {2, 1}}]]}], {i, {.1, .2, .3, .4}}]

Three-dimensional arrows with different sizes of arrowheads:

Wolfram Language code: Table[Graphics3D[{Arrowheads[i], Arrow[{{0, 0, 0}, {2, 1, 1}}]}], {i, {Tiny, Small, Medium, Large}}]
Wolfram Language code: Table[Graphics3D[{Arrowheads[i], Arrow[Tube[{{0, 0, 0}, {2, 1, 1}}, 0.02]]}], {i, {Tiny, Small, Medium, Large}}]

Graphics can be used as an arrowhead for 2D and 3D arrows:

Wolfram Language code: h = Graphics[Line[{{-1, 1 / 2}, {0, 0}, {-1, -1 / 2}, {-1, 1 / 2}}]];
Wolfram Language code: {Graphics[{Arrowheads[{{-.1, 0, {h, 1}}, {.1, 1, {h, 1}}}], Arrow[{{0, 0}, {2, 1}}]}], Graphics[{Arrowheads[{{-.1, 0, {h, 1}}, {.1, 1, {h, 1}}}], Arrow[BezierCurve[{{0, 0}, {1, -1}, {2, 1}}]]}]}
Wolfram Language code: h = Graphics[{Green, Polygon[{{-1, 1 / 2}, {0, 0}, {-1, -1 / 2}, {-1, 1 / 2}}]}];
Wolfram Language code: Graphics3D[{Arrowheads[{{-.1, 0, {h, 1}}, {.1, 1, {h, 1}}}, Appearance -> "Projected"], Arrow[{{0, 0, 0}, {2, 1, 1}}]}]

Use Graphics3D to specify the arrowhead:

Wolfram Language code: h = Graphics3D[Line[{{-1, 1 / 2, 0}, {0, 0, 0}, {-1, -1 / 2, 0}, {-1, 1 / 2, 0}}]];
Wolfram Language code: {Graphics3D[{Arrowheads[{{-.1, 0, {h, 1}}, {.1, 1, {h, 1}}}], Arrow[{{0, 0, 0}, {2, 1, 1}}]}], Graphics3D[{Arrowheads[{{-.1, 0, {h, 1}}, {.1, 1, {h, 1}}}], Arrow[BSplineCurve[{{0, 0, 0}, {.5, 1, 1}, {2, 1, 1}}]]}]}

Coordinate Specification  (3)

Use Scaled coordinates:

Wolfram Language code: Graphics[Arrow[{Scaled[{0, .2}], Scaled[{1, .8}]}], Frame -> True]
Wolfram Language code: Graphics3D[{Arrow[{Scaled[{0, .2, 0}], Scaled[{1, .8, 0.8}]}]}, Axes -> True]
Wolfram Language code: Graphics3D[{Arrow[Tube[{Scaled[{0, .2, 0}], Scaled[{1, .8, 0.8}]}]]}, Axes -> True]

Use ImageScaled coordinates:

Wolfram Language code: Graphics[Arrow[{ImageScaled[{0, .2}], ImageScaled[{1, .8}]}], Frame -> True]

Use Offset coordinates:

Wolfram Language code: Graphics[Arrow[{Offset[{10, 20}, {0, 0}], Offset[{-10, -20}, {1, 1}]}], Frame -> True]

Applications  (7)

Make programmatic annotations to plots:

Wolfram Language code: Plot[Sin[x], {x, 0, 2Pi}, Epilog -> {Arrow[{{3Pi / 2, 1 / 2}, {Pi, 0}}], Text["Zero", {3Pi / 2, 1 / 2}, {-1, -1}]}]
Wolfram Language code: Show[Plot3D[Sin[x]Sin[y], {x, 0, 2Pi}, {y, 0, 2Pi}, Mesh -> None, PlotRange -> {-1, 4}, BoxRatios -> Automatic], Graphics3D[{Arrow[{{Pi, Pi, 4}, {Pi / 2, Pi / 2, 1}}], Arrow[{{Pi, Pi, 4}, {3Pi / 2, 3Pi / 2, 1}}], Text[Panel["Maximum", FrameMargins -> 0], {Pi, Pi, 4}]}]]

A simple display of vector fields:

Wolfram Language code: With[{f = {v, u} / 5 - 1}, Graphics[Table[Arrow[{{u, v}, f + {u, v}}], {u, 0, 10}, {v, 0, 10}]]]
Wolfram Language code: With[{f = {v, u, 0} / 5 - 1}, Graphics3D[Table[Arrow[{{u, v, 0}, f + {u, v, 0}}], {u, 0, 10}, {v, 0, 10}]]]
Wolfram Language code: With[{f = {v, u, 0} / 5 - 1}, Graphics3D[Table[Arrow[Tube[{{u, v, 0}, f + {u, v, 0}}]], {u, 0, 10}, {v, 0, 10}]]]

VectorPlot and VectorPlot3D use Arrow:

Wolfram Language code: VectorPlot[{x, -y}, {x, -3, 3}, {y, -3, 3}, VectorColorFunction -> "Rainbow"]
Wolfram Language code: VectorPlot3D[{x, y - 2 x, z - x}, {x, -3, 3}, {y, -3, 3}, {z, -3, 3}, VectorColorFunction -> "Rainbow", VectorMarkers -> "Arrow"]

Use Arrow as an EdgeShapeFunction for GraphPlot:

Wolfram Language code: GraphPlot[Table[i -> Mod[i + 1, 6], {i, 0, 5}], EdgeShapeFunction -> (Arrow[#1]&), PlotStyle -> Arrowheads[Medium]]
Wolfram Language code: PolyhedronData["Dodecahedron", "Skeleton", "Rule"]
Wolfram Language code: GraphPlot3D[%, EdgeShapeFunction -> (Arrow[#1]&)]

Define an annotated arrow primitive:

Wolfram Language code: AnnotatedArrow[p_, q_, label_] := {Arrowheads[{{-.1, 0}, {.1, .5, Graphics[Inset[Style[label, Medium], {Center, Top}]]}, {.1, 1}}], Arrow[{p, q}]}
Wolfram Language code: Graphics[{AnnotatedArrow[{-1, 0}, {1, 0}, "diameter = 2"], Circle[]}]
Wolfram Language code: Graphics[{AnnotatedArrow[1 / Sqrt[2]{-1, -1}, 1 / Sqrt[2]{1, 1}, "*d* = 2"], Circle[]}]

Parallel dimensioning:

Wolfram Language code: ParallelDim[p_, q_, offset_, label_] := {Arrowheads[{{-.1, 0}, {.1, 0, Graphics[Line[{{0, 1}, {0, -1}}]]}, {.1, .5, Graphics[Inset[Style[label, Medium], {Center, Top}]]}, {.1, 1, Graphics[Line[{{0, 1}, {0, -1}}]]}, {.1, 1}}], Arrow[{p + offset, q + offset}]}
Wolfram Language code: Graphics[{Thick, Line[{{0, 0}, {1, 1}, {1, 0}, {0, 0}}], Thin, ParallelDim[{0, 0}, {1, 1}, {-.1, .1}, Sqrt[2]]}]

Show the direction along curves:

Wolfram Language code: Graphics[{Arrowheads[{Table[{0.04, i}, {i, 0.04, 1, 0.05}], Table[{0.04, i}, {i, 0.04, 1, 0.2}]}], Arrow[JoinedCurve[{{Line[{{2, 3}, {0.8125, 0.625}}], BezierCurve[{{0.6875, 0.375}, {0.375, 0.25}, {1.125, 0.25}}, SplineDegree -> 2], BezierCurve[{{0.8125, 0.375}, {0.9375, 0.625}}], Line[{{1.3125, 1.375}, {2.4375, 1.375}, {2.8125, 0.625}}], BezierCurve[{{2.9375, 0.375}, {2.625, 0.25}, {3.625, 0.25}}, SplineDegree -> 2], BezierCurve[{{3.3125, 0.375}, {3.1875, 0.625}}]}, {Line[{{1.875, 2.5}, {1.375, 1.5}, {2.375, 1.5}}]}}, CurveClosed -> True]]}]
Wolfram Language code: ListLinePlot[Table[{Sin[3t], Cos[5t]}, {t, 0, 2Pi, 2Pi / 50}], Axes -> False] /. Line[rest_] :> {Arrowheads[Table[0.05, {i, 0, 1, .02}]], Arrow[BSplineCurve@rest]}

Properties & Relations  (1)

Use Arrowheads to style the axes:

Wolfram Language code: Plot[x ^ 3, {x, -1, 1}, AxesStyle -> Arrowheads[{-0.05, 0.05}]]

Neat Examples  (4)

A random collection of arrows:

Wolfram Language code: Graphics[Table[{Hue[RandomReal[]], Arrow[RandomReal[1, {2, 2}]]}, {75}]]
Wolfram Language code: Graphics3D[Table[{Hue[RandomReal[]], Arrow[Tube[RandomReal[1, {2, 3}], Scaled[0.007]]]}, {50}]]

An arrow wheel:

Wolfram Language code: Graphics[Table[{Hue[k / 40], Arrow[{{0, 0}, {Cos[2k Pi / 40], Sin[2k Pi / 40]}}]}, {k, 40}]]

Tangent vectors along an elliptic curve:

Wolfram Language code: With[{f = {Cos[x] + Sin[x], Sin[x]}}, Graphics[Table[{Hue[t / (2Pi), 1, .8], Arrow[{f, Normalize[D[f, x]] + f}]} /. x -> t, {t, 0, 2Pi, .1}]]]

A billboard tree using a projected arrowhead:

Wolfram Language code: tree = \!\(\*GraphicsBox[«2»]\);
Wolfram Language code: Graphics3D[{Arrowheads[{{.1, 1, tree}}, Appearance -> "Projected"], Arrow[{{0, 0, 0}, {0, -0, 0.001}}], Green, Cuboid[{-10, -10, -3}, {10, 10, -2.8}]}]
