InverseJacobiSC

InverseJacobiSC[v,m]

gives the inverse Jacobi elliptic function .

Details

  • Mathematical function, suitable for both symbolic and numerical manipulation.
  • gives the value of u for which .
  • InverseJacobiSC has branch cut discontinuities in the complex v plane with branch points at and infinity, and in the complex m plane with branch points at and infinity.
  • The inverse Jacobi elliptic functions are related to elliptic integrals.
  • For certain special arguments, InverseJacobiSC automatically evaluates to exact values.
  • InverseJacobiSC can be evaluated to arbitrary numerical precision.
  • InverseJacobiSC automatically threads over lists.

Examples

open all close all

Basic Examples  (4)

Evaluate numerically:

Wolfram Language code: InverseJacobiSC[3.5, 0.3]//Chop
Wolfram Language code: JacobiSC[%, 0.3]

Plot the function over a subset of the reals:

Wolfram Language code: Plot[InverseJacobiSC[x, 1 / 2], {x, -10, 10}]

Plot over a subset of the complexes:

Wolfram Language code: ComplexPlot3D[InverseJacobiSC[z, 1 / 3], {z, -2 - 2I, 2 + 2I}, PlotLegends -> Automatic]

Series expansions at the origin:

Wolfram Language code: Series[InverseJacobiSC[z, m], {z, 0, 7}]
Wolfram Language code: Series[InverseJacobiSC[z, m], {m, 0, 1}]

Scope  (29)

Numerical Evaluation  (5)

Evaluate to high precision:

Wolfram Language code: N[InverseJacobiSC[3, 1 / 2], 50]

The precision of the output tracks the precision of the input:

Wolfram Language code: InverseJacobiSC[3, 0.5000000000000000000000000000000000]

Evaluate for complex arguments:

Wolfram Language code: InverseJacobiSC[1.2 + 0.3I, 1.5 - I]

Evaluate InverseJacobiSC efficiently at high precision:

Wolfram Language code: InverseJacobiSC[3, 0.5`500]//Timing
Wolfram Language code: InverseJacobiSC[3, 0.5`50000];//Timing

Compute average-case statistical intervals using Around:

Wolfram Language code: InverseJacobiSC[Around[3, 0.01], .5]

Compute the elementwise values of an array:

Wolfram Language code: InverseJacobiSC[{{-I, 0}, {0, I}}, 1]

Or compute the matrix InverseJacobiSC function using MatrixFunction:

Wolfram Language code: MatrixFunction[InverseJacobiSC[#, 1]&, {{-I, 0}, {0, I}}]//FullSimplify

Specific Values  (4)

Simple exact results are generated automatically:

Wolfram Language code: {InverseJacobiSC[ν, 0], InverseJacobiSC[ν, 1]}
Wolfram Language code: {InverseJacobiSC[0, m], InverseJacobiSC[I, m]}

Values at infinity:

Wolfram Language code: InverseJacobiSC[ν, Infinity]
Wolfram Language code: InverseJacobiSC[Infinity, m]

Find a real root of the equation TemplateBox[{x, {1, /, 3}}, InverseJacobiSC]=1:

Wolfram Language code: f[x_] := InverseJacobiSC[x, 1 / 3] - 1; xzero = Solve[f[x] == 0 && 1.0 < x < 2.0, x][[1, 1, 2]]//Quiet
Wolfram Language code: Plot[f[ν], {ν, 0, 2}, Epilog -> Style[Point[{xzero, f[xzero]}], PointSize[Large], Red]]

Parity transformation is automatically applied:

Wolfram Language code: InverseJacobiSC[-ν, m]

Visualization  (3)

Plot InverseJacobiSC for various values of the second parameter :

Wolfram Language code: Plot[{InverseJacobiSC[ν, -5], InverseJacobiSC[ν, 0], InverseJacobiSC[ν, 1], InverseJacobiSC[ν, 2]}, {ν, -3, 3}]

Plot InverseJacobiSC as a function of its parameter :

Wolfram Language code: Plot[{InverseJacobiSC[1, m], InverseJacobiSC[3 / 2, m], InverseJacobiSC[2, m]}, {m, -3, 3}]

Plot the real part of TemplateBox[{z, 2}, InverseJacobiSC]:

Wolfram Language code: ComplexContourPlot[Re[InverseJacobiSC[z, 2]], {z, -3 - 3I, 3 + 3I}, IconizedObject[«PlotOptions»]]

Plot the imaginary part of TemplateBox[{z, 2}, InverseJacobiSC]:

Wolfram Language code: ComplexContourPlot[Im[InverseJacobiSC[z, 2]], {z, -3 - 3I, 3 + 3I}, IconizedObject[«PlotOptions»]]

Function Properties  (6)

InverseJacobiSC is not an analytic function:

Wolfram Language code: FunctionAnalytic[InverseJacobiSC[x, m], {x, m}]

It has both singularities and discontinuities:

Wolfram Language code: Reduce[FunctionSingularities[InverseJacobiSC[x, 3], x], x, Reals]//Quiet
Wolfram Language code: Reduce[FunctionDiscontinuities[InverseJacobiSC[x, 3], x], x, Reals]//Quiet

TemplateBox[{x, 3}, InverseJacobiSC] is nondecreasing on its real domain:

Wolfram Language code: FunctionMonotonicity[{InverseJacobiSC[x, 3], (-1/Sqrt[2]) < x < (1/Sqrt[2])}, x]

TemplateBox[{x, {1, /, 3}}, InverseJacobiSC] is injective:

Wolfram Language code: FunctionInjective[InverseJacobiSC[x, 1 / 3], x]
Wolfram Language code: Plot[{InverseJacobiSC[x, 1 / 3], .3}, {x, -5, 5}]

TemplateBox[{x, 3}, InverseJacobiSC] is not surjective:

Wolfram Language code: FunctionSurjective[InverseJacobiSC[x, 3], x]
Wolfram Language code: Plot[{InverseJacobiSC[x, 3], 2}, {x, -5, 5}]

TemplateBox[{x, {1, /, 3}}, InverseJacobiSC] is neither non-negative nor non-positive:

Wolfram Language code: FunctionSign[InverseJacobiSC[x, 1 / 3], x]

TemplateBox[{x, {1, /, 3}}, InverseJacobiSC] is neither convex nor concave:

Wolfram Language code: FunctionConvexity[InverseJacobiSC[x, 1 / 3], x]

Differentiation and Integration  (4)

First derivative:

Wolfram Language code: D[InverseJacobiSC[ν, m], ν]

Higher derivatives:

Wolfram Language code: derivs = Table[D[InverseJacobiSC[ν, m], {ν, n}], {n, 1, 3}]//Simplify

Plot higher derivatives for :

Wolfram Language code: Plot[Evaluate[derivs /. m -> 2], {ν, -1, 1}, PlotLegends -> {"First Derivative", "Second Derivative", "Third Derivative"}]

Differentiate InverseJacobiSC with respect to the second argument :

Wolfram Language code: D[InverseJacobiSC[ν, m], m]

Definite integral of an odd function over an interval centered at the origin is 0:

Wolfram Language code: Integrate[InverseJacobiSC[ν, m], {ν, -ν0, ν0}, Assumptions -> ν0∈Reals]

Series Expansions  (3)

Taylor expansion for TemplateBox[{nu, m}, InverseJacobiSC] around :

Wolfram Language code: Series[InverseJacobiSC[ν, m], {ν, 0, 5}]

Plot the first three approximations for TemplateBox[{nu, 2}, InverseJacobiSC] around :

Wolfram Language code: terms = Normal@Table[Series[InverseJacobiSC[ν, 2], {ν, 0, n}], {n, 2, 12, 4}]; Plot[{InverseJacobiSC[ν, 2], terms}, {ν, -1.1, 1.1}]

Taylor expansion for TemplateBox[{nu, m}, InverseJacobiSC] around :

Wolfram Language code: Series[InverseJacobiSC[ν, m], {m, 0, 3}]//FullSimplify

Plot the first three approximations for TemplateBox[{nu, m}, InverseJacobiSC] around :

Wolfram Language code: terms = Normal@Table[Series[InverseJacobiSC[2, m], {m, 0, n}], {n, 1, 3}]; Plot[{InverseJacobiSC[2, m], terms}, {m, -1, 1}]

InverseJacobiSC can be applied to a power series:

Wolfram Language code: InverseJacobiSC[ν, Exp[m] + O[m] ^ 2]

Function Identities and Simplifications  (2)

InverseJacobiSC is the inverse function of JacobiSC:

Wolfram Language code: Solve[ν == JacobiSC[u, m], u][[1, 1]]//Quiet

Compose with inverse function:

Wolfram Language code: {InverseJacobiSC[JacobiSC[ν, m], m], JacobiSC[InverseJacobiSC[ν, m], m]}

Use PowerExpand to disregard multivaluedness of the inverse function:

Wolfram Language code: PowerExpand[%]

Other Features  (2)

InverseJacobiSC threads elementwise over lists:

Wolfram Language code: InverseJacobiSC[{ν1, ν2}, m]

TraditionalForm formatting:

Wolfram Language code: InverseJacobiSC[ν, m]//TraditionalForm

Applications  (2)

Plot contours of constant real and imaginary parts in the complex plane:

Wolfram Language code: Table[ContourPlot[f[InverseJacobiSC[x + I y, 1 + I]], {x, -3, 3}, {y, -3, 3}, Contours -> 24], {f, {Re, Im}}]

Construct lowpass elliptic filter for analog signal:

Wolfram Language code: 𝒩 = 5;ωPass = 4.8;ℊPass = 0.92;ℊStop = 0.08;

Compute filter ripple parameters and associate elliptic function parameter:

Wolfram Language code: ϵp = Sqrt[ℊPass^-2 - 1];ϵs = Sqrt[ℊStop^-2 - 1]; m1 = (ϵp / ϵs)^2; K1 = EllipticK[m1]; K1p = EllipticK[1 - m1];

Use elliptic degree equation to find the ratio of the pass and the stop frequencies:

Wolfram Language code: us = Range[1, 2⌊(𝒩/2)⌋ - 1, 2] / 𝒩; m = 1 - (1 - m1) ^ 𝒩 Apply[Times, JacobiSN[us K1p, 1 - m1] ^ 8]

Compute corresponding stop frequency and elliptic parameters:

Wolfram Language code: K = EllipticK[m];Kp = EllipticK[1 - m]; ωStop = ωPass / Sqrt[m]

Compute ripple locations and poles and zeros of the transfer function:

Wolfram Language code: ζs = JacobiCD[us K, m]; zeros = I ωStop / ζs;

Compute poles of the transfer function:

Wolfram Language code: Subscript[ν, 0] = (1/𝒩 K1)InverseJacobiSC[(1/ϵp), 1 - m1]; poles = ωPass I JacobiCD[(us - I Subscript[ν, 0])K, m];

Assemble the transfer function:

Wolfram Language code: H[ω_] = Piecewise[{{ℊPass, Mod[𝒩, 2] == 0}, {(1/1 + I ω / ωPass JacobiCS[Subscript[ν, 0] K, 1 - m]), Mod[𝒩, 2] == 1}}] Apply[Times, ((1 - I ω / zeros)(1 - I ω / Conjugate[zeros])/(1 - I ω / poles)(1 - I ω / Conjugate[poles]))];
Wolfram Language code: Plot[Abs[H[ω]], {ω, 0, 8}, PlotRange -> All, Epilog -> {Pink, Dashed, Line[{{0, ℊPass}, {ωPass, ℊPass}, {ωPass, ℊStop}}], Line[{{ωStop, ℊPass}, {ωStop, ℊStop}, {10, ℊStop}}]}]

Compare with the result of EllipticFilterModel:

Wolfram Language code: tf = EllipticFilterModel[{"Lowpass", {ωPass, ωStop}, -20Log10[{ℊPass, ℊStop}]}];
Wolfram Language code: Plot[Abs[tf[I ω]], {ω, 0, 8}]

Properties & Relations  (1)

Obtain InverseJacobiSC from solving equations containing elliptic functions:

Wolfram Language code: Solve[JacobiSC[x, m]^2 + 2JacobiSC[x, m] == a, x]
