Wolfram Language & System Documentation Center

PowerModel

PowerModel[]

represents a power law function.

PowerModel[vars]

represents a model with the given variables vars with unknown constants.

PowerModel[pars,vars]

represents the model of vars variables with the given parameters pars.

Details

PowerModel represents a power law relationship in the given variables in a format suitable for symbolic or numerical evaluation and fitting.
Power models describe phenomena such as geometric scaling (area/volume), allometric relationships, inverse-square laws and other scale-invariant physical and empirical relationships.

PowerModel is parametrized as .
Multivariate power models are parametrized as $TemplateBox[{1}, CTraditional]+TemplateBox[{2}, CTraditional] product_(i=3)^nx_i^(TemplateBox[{i}, CTraditional])$ .
A fully specified model can be evaluated either numerically or symbolically using PowerModel[…][x].
Multivariate models expect a list of variables PowerModel[…][{x,y,…}].

Variables

When not specified, variables will automatically be enumerated using x[i].
Valid variable specifications vars include:
n the number of variables

symb a symbolic representation of a single variable

{symb_1,…} a list of symbolic variables

Parameters

When not specified, parameters will automatically be enumerated using C[i].
Valid parameter pars specifications in the form {par₁,…} include:

	val	a fixed parameter value val
	par	a symbolic parameter name par
	parval	a symbolic name par set to a fixed value val
	{par,val₀}	a symbolic parameter named par with the initial value val₀

Properties

Model properties can be extracted using Information[PowerModel[…],prop].
Valid basic properties include:

	"BaseType"	model base type
	"Name"	model name
	"ShortName"	short identifier to use as label
	"InputType"	supported input types
	"OutputType"	supported output types

Valid data-related properties include:

	"ColumnNames"	names of the input features
	"ColumnVariableMap"	map between column names and model variables
	"InputSize"	dimensionality of the input
	"OutputSize"	dimensionality of the output
	"Trainable"	whether the model is fully specified and can be trained
	"Trained"	whether the model can be evaluated numerically
	"VariableColumnMap"	map between model variables and column names
	"Variables"	name of the model variables

Best model-related properties include:

	"Expression"	model expression
	"Function"	model as a pure function
	"SymbolicExpression"	model expression with symbolic parameters
	"TabularFunction"	pure function suitable to work on a tabular row

Parameter-related properties include:

	"ParameterAssociation"	association of parameter names and values
	"ParameterCount"	the number of parameters
	"ParameterInitialValues"	initial values for the fit
	"ParameterNames"	parameter names
	"ParameterRules"	list of rules with parameter names and values
	"Parameters"	parameter values if present; names otherwise
	"ParameterValues"	parameter values
	"Constraints"	parameter constraints

Examples

open all close all

Basic Examples (3)

Specify a generic power model:

Wolfram Language code: PowerModel[]

Use an explicit input size and custom names for the symbolic parameters:

Wolfram Language code: PowerModel[{a, b, c}, 1]

Compare the model of multiple different powers:

Wolfram Language code: Plot[{PowerModel[{0, 1, -0.5}, 1][x], PowerModel[{1, 1, 0.5}, 1][x], PowerModel[{5, -1, 1.5}, 1][x]}, {x, 0, 5}]

Scope (19)

Variables (2)

Specify a generic power model:

Wolfram Language code: PowerModel[]

The number of variables is inferred from the input:

Wolfram Language code: PowerModel[][{x}]

Wolfram Language code: PowerModel[][{x, y}]

ModelFit will assume the number of variables is one less than the dimensionality of data points:

Wolfram Language code: ModelFit[{{1, 9, 55}, {1, 1, 7}, {1, 4, 25}, {8, 9, 118}, {8, 10, 124}, {8, 5, 94}}, PowerModel[]]

Specify the number of variables:

Wolfram Language code: PowerModel[2]

Give the variables a custom symbolic representation:

Wolfram Language code: PowerModel[{var1, var2}]

These names are overwritten when the model is evaluated symbolically:

Wolfram Language code: PowerModel[{var1, var2}][{a, b}]

Parameters (5)

Parameter names are assigned automatically:

Wolfram Language code: PowerModel[1]

Specify custom parameter names:

Wolfram Language code: PowerModel[{a, b, c}, 1]

Set a parameter to a specific value:

Wolfram Language code: PowerModel[{0, 42, b}, 1]

Specify both parameter names and values:

Wolfram Language code: PowerModel[{a -> 0, b, c}, 1]

Specify initial values for some parameters:

Wolfram Language code: PowerModel[{a, b, {c, -1}}, 1]

Inspect the initial values:

Wolfram Language code: Information[%, "ParameterInitialValues"]

Evaluation (5)

Symbolically evaluate a single-variable model:

Wolfram Language code: PowerModel[1][x]

Symbolically evaluate a two-variable model:

Wolfram Language code: PowerModel[2][{x, y}]

The number of variables is automatically inferred if not specified:

Wolfram Language code: PowerModel[][x]

Wolfram Language code: PowerModel[][{x, y}]

Evaluate the model on multiple symbolic variables:

Wolfram Language code: PowerModel[2][{{x, y}, {a, b}}]

Evaluate the model on a list of points:

Wolfram Language code: PowerModel[1][{1, 2, 3}]

Information (4)

View general information about a model:

Wolfram Language code: Information[PowerModel[]]

A model will only show information available based on the provided variables and parameters:

Wolfram Language code: Information[PowerModel[x]]

Extract a single property:

Wolfram Language code: Information[PowerModel[{a, b, c}, x], "Variables"]

Retrieve multiple properties:

Wolfram Language code: Information[PowerModel[{a, b, c}, x], {"Variables", "Parameters"}]

Get information about the default model values:

Wolfram Language code: Information[PowerModel[1], {"Variables", "Parameters"}]

Model Fit (3)

Fit a power model specifying the parameter and variable names:

Wolfram Language code: ModelFit[{{1, 1, 2}, {2, 5, 9}, {3, 8, 16}}, PowerModel[{a, b, c, d}, {x, y}]]

Numerical parameter values are considered fixed during fitting:

Wolfram Language code: ModelFit[{{1, 2}, {2, 9}, {3, 16}}, PowerModel[{0, Pi, a}, 1]]

Specify initial parameter values:

Wolfram Language code: ModelFit[{...}, PowerModel[{a, b, {c, -1}}, 1]]

Applications (2)

Confirming the Formula for Kinetic Energy (1)

Experimentally validate the kinetic energy formula . Measure the time it takes for a ball to roll a set horizontal distance after traveling down a ramp from different heights:

Wolfram Language code: data = Tabular[...]

Calculate the initial potential energy and the velocity given a 0.3m ball and a 0.104kg mass:

Wolfram Language code:

mass = 0.104;
distance = 0.30;
g  = 9.81 ;
velocityData = TransformColumns[data, {"PotentialEnergy" -> Function[mass * g * #Height], "Speed" -> Function[distance / #Time ]}]

Assuming all potential energy is converted to kinetic energy (no friction), you can find the kinetic energy by fitting a power model:

Wolfram Language code: model = ModelFit[velocityData -> {"Speed", "PotentialEnergy"}, PowerModel[]]

By definition, a stationary object must have zero kinetic energy. Set the intercept to zero for a better fit:

Wolfram Language code: model = ModelFit[velocityData -> {"Speed", "PotentialEnergy"}, PowerModel[{0, c, m}, 1]]

Compare the model to the fit:

Wolfram Language code: ListPlot[velocityData -> {"Speed", "PotentialEnergy"}, PlotFit -> model, AxesLabel -> {"Speed (m/s)", "Energy (J)"}]

The fit is to the following expression:

Wolfram Language code: Information[model, "Expression"]

Compare with the theoretical formula :

Wolfram Language code: 1 / 2 mass v ^ 2

Predicting Abalone Weight (1)

Retrieve data on abalone (a marine mollusc) measurements:

Wolfram Language code: abalone = Tabular@ResourceData["Sample Data: Abalone Measurements"]

Clean the data by removing anomalous (0mm-high abalone) measurements:

Wolfram Language code: cleanAbalone = Select[abalone, QuantityMagnitude[#Height] > 0&];

Predict the weight of an abalone based on the shell measurements, treating the abalone as radially symmetric and ignoring the length:

Wolfram Language code: ModelFit[cleanAbalone -> {"Diameter", "Height", "ShuckedWeight"}, PowerModel[]]

Possible Issues (1)

Zero or negative input values will give errors during the fit:

Wolfram Language code:

data = ResourceData["Sample Data: Abalone Measurements"];
ModelFit[data -> {"Diameter", "Height", "WholeWeight"}, PowerModel[]]

Remove the high crab from the dataset:

Wolfram Language code: cleanData = Select[data, Positive[#Height]&];

The fit will now complete as expected:

Wolfram Language code: ModelFit[cleanData -> {"Diameter", "Height", "WholeWeight"}, PowerModel[]]
