Simplex

Simplex[{p1,…,pk}]

represents the simplex spanned by points pi.

Details and Options

  • Simplex is also known as point, line segment, triangle, tetrahedron, pentachoron, hexateron, etc.
  • Simplex represents all convex combinations of the given points . The region is dimensional when are affinely independent and .
  • Example simplices where rows correspond to embedding dimension:
  • Simplex[n] for integer n is equivalent to Simplex[{{0,…,0},{1,0,…,0},…,{0,…,0,1}}], the unit standard simplex in .
  • Simplex can be used as a geometric region and graphics primitive.
  • In graphics, the points pi can be Scaled and Dynamic expressions.
  • Graphics rendering is affected by directives such as FaceForm, EdgeForm, Opacity, and color.

Examples

open all close all

Basic Examples  (3)

A Simplex in 3D:

Wolfram Language code: Graphics3D[Simplex[{{0, 0, 1}, {1, 0, 0}, {1, 0, 1}, {1, 1, 1}}]]

And in 2D:

Wolfram Language code: Graphics[Simplex[{{0, 0}, {1, 1}, {2, 0}}]]

Different styles applied to a simplex:

Wolfram Language code: ℛ = Simplex[3];
Wolfram Language code: {Graphics3D[{Pink, ℛ}], Graphics3D[{EdgeForm[Thick], ℛ}], Graphics3D[{Opacity[0.25], Blue, ℛ}], Graphics3D[{EdgeForm[Directive[Thick, Dotted]], FaceForm[None], ℛ}]}

Volume and centroid:

Wolfram Language code: ℛ = Simplex[{{1, 0, 0}, {1, 0, 1}, {1, 1, 1}, {0, 0, 1}}];
Wolfram Language code: Volume[ℛ]
Wolfram Language code: RegionCentroid[ℛ]

Scope  (20)

Graphics  (9)

Specification  (3)

A standard unit Simplex in 3D:

Wolfram Language code: Graphics3D[Simplex[3]]

A 2D simplex spanning three points:

Wolfram Language code: Graphics[Simplex[{{0, 0}, {1, 1}, {2, 0}}]]

A simplex in dimensions is specified by at most points:

Wolfram Language code: pts = {{0, 0, 1}, {1, 0, 0}, {1, 0, 1}, {1, 1, 1}};
Wolfram Language code: Table[Graphics3D[Simplex[Take[pts, n]]], {n, 4}]

Styling  (3)

Different styles applied to a simplex:

Wolfram Language code: ℛ = Simplex[3];
Wolfram Language code: {Graphics3D[{Pink, ℛ}], Graphics3D[{EdgeForm[Thick], ℛ}], Graphics3D[{Opacity[0.25], Blue, ℛ}], Graphics3D[{EdgeForm[Directive[Thick, Dotted]], FaceForm[None], ℛ}]}

Color directives specify the face color:

Wolfram Language code: Table[Graphics3D[{c, Simplex[3]}], {c, {Red, Green, Blue, Yellow}}]

FaceForm and EdgeForm can be used to specify the styles of the faces and edges:

Wolfram Language code: Graphics3D[{FaceForm[Pink], EdgeForm[Directive[Thick, Dashed, Blue]], Simplex[3]}]

Coordinates  (3)

Specify coordinates by fractions of the plot range:

Wolfram Language code: Graphics3D[Simplex[{Scaled[{0, 0, 0}], Scaled[{0.5, 0, 0}], Scaled[{0, 0.5, 0}], Scaled[{0, 0, 0.5}]}], PlotRange -> {{0, 10}, {0, 10}, {0, 10}}, Axes -> True]

Specify scaled offsets from the ordinary coordinates:

Wolfram Language code: Graphics3D[Simplex[{Scaled[{0, 0, 0.5}, {0, 0, 0}], Scaled[{0, 0, 0.5}, {1, 0, 0}], Scaled[{0, 0, 0.5}, {0, 1, 0}], Scaled[{0, 0, 0.5}, {0, 0, 1}]}], PlotRange -> {{0, 2}, {0, 2}, {0, 2}}, Axes -> True]

Points can be Dynamic:

Wolfram Language code: DynamicModule[{x}, {Slider[Dynamic[x], {0, 1}], Graphics3D[Simplex[{Dynamic[{1, 1, 1}x], {1, 0, 0}, {0, 1, 0}, {0, 0, 1}}]]}]

Regions  (11)

Embedding dimension is the dimension of the space in which the simplex lives:

Wolfram Language code: RegionEmbeddingDimension[Simplex[{{0, 0}, {1, 0}, {0, 1}}]]
Wolfram Language code: RegionEmbeddingDimension[Simplex[{{0, 0, 0}, {1, 0, 0}, {0, 1, 1}}]]
Wolfram Language code: Table[RegionEmbeddingDimension[Simplex[d]], {d, 5}]

Geometric dimension is the dimension of the shape itself:

Wolfram Language code: RegionDimension[Simplex[{{0, 0}, {1, 0}, {0, 1}}]]
Wolfram Language code: RegionDimension[Simplex[{{0, 0, 0}, {1, 0, 0}, {0, 1, 1}}]]
Wolfram Language code: Table[RegionDimension[Simplex[d]], {d, 5}]

Point membership test:

Wolfram Language code: RegionMember[Simplex[{{0, 0}, {1, 0}, {0, 1}}], {1 / 2, 1 / 2}]
Wolfram Language code: RegionMember[Simplex[{{0, 0}, {1, 0}, {0, 1}}], {1, 1}]

Get conditions for point membership:

Wolfram Language code: RegionMember[Simplex[2], {x, y}]

Measure and centroid:

Wolfram Language code: RegionMeasure[Simplex[3]]
Wolfram Language code: RegionCentroid[Simplex[3]]

The measure for a standard simplex in dimension is :

Wolfram Language code: Table[RegionMeasure[Simplex[d]], {d, 5}]

Distance from a point:

Wolfram Language code: ℛ = Simplex[{{0, 0}, {1, 1}, {2, 0}}];
Wolfram Language code: {RegionDistance[ℛ, {2, 2}], RegionDistance[ℛ, {1 / 2, 1 / 2}]}

Visualize it:

Wolfram Language code: {Plot3D[Evaluate@RegionDistance[ℛ, {x, y}], {x, -1, 3}, {y, -1, 2}, MeshFunctions -> {#3&}, Mesh -> 5], ContourPlot[Evaluate@RegionDistance[ℛ, {x, y}], {x, -2, 4}, {y, -2, 3}, Contours -> {{0.5, Red}, {1, Green}, {1.5, Blue}}]}

Signed distance from a point:

Wolfram Language code: ℛ = Simplex[{{0, 0}, {1, 1}, {2, 0}}];
Wolfram Language code: {SignedRegionDistance[ℛ, {2, 2}], SignedRegionDistance[ℛ, {1 / 2, 1 / 2}]}
Wolfram Language code: Plot3D[SignedRegionDistance[ℛ, {x, y}], {x, -1, 3}, {y, -1, 2}, MeshFunctions -> {#3&}, Mesh -> {{0}}, MeshShading -> {Red, Green}]

Nearest point to the region:

Wolfram Language code: ℛ = Simplex[{{0, 0}, {1, 1}, {2, 0}}];
Wolfram Language code: {RegionNearest[ℛ, {2, 2}], RegionNearest[ℛ, {1 / 3, 1 / 3}]}

Visualize it:

Wolfram Language code: pts = Table[{1, 0.25} + 1.5{Cos[k 2 π / 16], Sin[k 2 π / 16]}, {k, 0, 15}]; nst = RegionNearest[ℛ, #]& /@ pts;
Wolfram Language code: Legended[Graphics[{{Gray, ℛ}, {Thin, Gray, Line[Transpose[{pts, nst}]]}, {Red, Point[pts]}, {Blue, Point[nst]}}], PointLegend[{Red, Blue}, {"start", "nearest"}]]

A simplex is bounded:

Wolfram Language code: ℛ = Simplex[{{0, 0, 0}, {1, 0, 0}, {0, 1, 0}, {0, 0, 1}}];
Wolfram Language code: BoundedRegionQ[ℛ]

Find its range:

Wolfram Language code: r = RegionBounds[ℛ]
Wolfram Language code: Graphics3D[{{EdgeForm[White], Opacity[0.2, Yellow], Cuboid@@Transpose[r]}, ℛ}, Boxed -> False]

Integrate over a simplex:

Wolfram Language code: Integrate[1, {x, y, z}∈Simplex[3]]
Wolfram Language code: Integrate[x y z, {x, y, z}∈Simplex[3]]

Optimize over a simplex:

Wolfram Language code: MinValue[{x y - x, {x, y}∈Simplex[2]}, {x, y}]
Wolfram Language code: MaxValue[{Exp[x y], {x, y}∈Simplex[2]}, {x, y}]

Solve equations constrained by a simplex:

Wolfram Language code: Reduce[(x - 1)(x - 2) == 0 && {x}∈Simplex[1], {x}]
Wolfram Language code: Reduce[4x^2 + 4y^2 + 4z^2 == 1 && {x, y, z}∈Simplex[3], {x, y, z}]

Applications  (1)

Define the Kuhn simplex for dimension :

Wolfram Language code: KuhnSimplex[n_] := Simplex@Table[If[j < i, 1, 0], {i, 1, n + 1}, {j, n}]

The 2D Kuhn simplex:

Wolfram Language code: KuhnSimplex[2]
Wolfram Language code: Graphics[%]

The 3D Kuhn simplex:

Wolfram Language code: KuhnSimplex[3]
Wolfram Language code: Graphics3D[%]

The measure in dimension is :

Wolfram Language code: Table[RegionMeasure[KuhnSimplex[n]], {n, 5}]

The centroid in dimension is :

Wolfram Language code: Table[RegionCentroid[KuhnSimplex[n]], {n, 5}]

Properties & Relations  (8)

TriangulateMesh can be used to decompose a volume mesh into simplices:

Wolfram Language code: {ℛ2 = DiscretizeGraphics[Rectangle[]], TriangulateMesh[ℛ2]}
Wolfram Language code: {ℛ3 = DiscretizeGraphics[Cuboid[]], TriangulateMesh[ℛ3]}

Use options such as MaxCellMeasure to control the number of simplices:

Wolfram Language code: {TriangulateMesh[ℛ2, MaxCellMeasure -> 1], TriangulateMesh[ℛ3, MaxCellMeasure -> 1]}

Point is a special case of Simplex:

Wolfram Language code: RegionMember[Point[{{0, 0}}], {x, y}]
Wolfram Language code: RegionMember[Simplex[{{0, 0}}], {x, y}]

Line is a special case of Simplex:

Wolfram Language code: Subscript[ℛ, 1] = Line[{{0, 0}, {1, 1}}]; Subscript[ℛ, 2] = Simplex[{{0, 0}, {1, 1}}];
Wolfram Language code: RegionEqual[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Triangle is a special case of Simplex:

Wolfram Language code: Subscript[ℛ, 1] = Triangle[{{0, 0}, {0, 1}, {1, 0}}]; Subscript[ℛ, 2] = Simplex[{{0, 0}, {0, 1}, {1, 0}}];
Wolfram Language code: RegionEqual[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Tetrahedron is a special case of Simplex:

Wolfram Language code: Subscript[ℛ, 1] = Tetrahedron[{{0, 0, 0}, {1, 0, 0}, {0, 1, 0}, {0, 0, 1}}]; Subscript[ℛ, 2] = Simplex[{{0, 0, 0}, {1, 0, 0}, {0, 1, 0}, {0, 0, 1}}];
Wolfram Language code: RegionEqual[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Polygon is a generalization of Simplex in dimension 2:

Wolfram Language code: Subscript[ℛ, 1] = Polygon[{{0, 0}, {0, 1}, {1, 0}}]; Subscript[ℛ, 2] = Simplex[{{0, 0}, {0, 1}, {1, 0}}];
Wolfram Language code: RegionEqual[Subscript[ℛ, 1], Subscript[ℛ, 2]]

ImplicitRegion can represent any Simplex:

Wolfram Language code: Subscript[ℛ, 1] = ImplicitRegion[Subscript[t, 1] ≥ 0 && Subscript[t, 2] ≥ 0 && Subscript[t, 3] ≥ 0 && Subscript[t, 4] ≥ 0 && Subscript[t, 1] + Subscript[t, 2] + Subscript[t, 3] + Subscript[t, 4] ≤ 1, {Subscript[t, 1], Subscript[t, 2], Subscript[t, 3], Subscript[t, 4]}]; Subscript[ℛ, 2] = Simplex[{{0, 0, 0, 0}, {1, 0, 0, 0}, {0, 1, 0, 0}, {0, 0, 1, 0}, {0, 0, 0, 1}}];
Wolfram Language code: RegionEqual[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Simplex is the set of convex combinations of its vertices:

Wolfram Language code: {Subscript[p, 1], Subscript[p, 2], Subscript[p, 3], Subscript[p, 4]} = {{1, 2, 3}, {1, 2, 4}, {1, 3, 4}, {2, 3, 4}}; Subscript[ℛ, 1] = ParametricRegion[{Subscript[t, 1]Subscript[p, 1] + Subscript[t, 2]Subscript[p, 2] + Subscript[t, 3]Subscript[p, 3] + Subscript[t, 4]Subscript[p, 4], Subscript[t, 1] ≥ 0 && Subscript[t, 2] ≥ 0 && Subscript[t, 3] ≥ 0 && Subscript[t, 4] ≥ 0 && Subscript[t, 1] + Subscript[t, 2] + Subscript[t, 3] + Subscript[t, 4] == 1}, {Subscript[t, 1], Subscript[t, 2], Subscript[t, 3], Subscript[t, 4]}]; Subscript[ℛ, 2] = Simplex[{Subscript[p, 1], Subscript[p, 2], Subscript[p, 3], Subscript[p, 4]}];
Wolfram Language code: RegionEqual[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Neat Examples  (1)

Random collection of simplices:

Wolfram Language code: Graphics[Table[{Hue[RandomReal[]], Simplex[RandomReal[1, {3, 2}]]}, {10}]]
Wolfram Language code: Graphics3D[Table[{Hue[RandomReal[]], Simplex[RandomReal[1, {4, 3}]]}, {10}]]
