MIDI (.mid)

  • Export fully supports the standard MIDI file format.
  • Import supports versions 0 and 1 of the MIDI file format.

Background & Context

    • MIME type: audio/midi
    • Standard MIDI file format.
    • Audio format.
    • Used for controlling electronic musical instruments, computer sound cards, and sequencers.
    • Stores a sequence of discrete sound events such as the beginning and end of a note, velocity and timbre information, and instrument and sound bank codes.
    • MIDI is an acronym for Musical Instrument Digital Interface.
    • Binary file format.
    • Introduced in 1983.
    • Developed and published by the MIDI Manufacturers Association (US) and the Association of Musical Electronic Industry MIDI committee (Japan).

Import & Export

  • Import["file.mid"] imports a MIDI file, returning a sound object.
  • Export["file.mid",expr] exports a sound object to MIDI.
  • Import["file.mid",elem] imports the specified element from a MIDI file.
  • Import["file.mid",{elem,suba,subb,…}] imports a subelement.
  • Import["file.mid",{{elem1,elem2,…}}] imports multiple elements.
  • The import format can be specified with Import["file","MIDI"] or Import["file",{"MIDI",elem,…}].
  • Export["file.mid",Sound[…]] creates a MIDI file from a Sound expression consisting of SoundNote primitives.
  • Export["file.mid",MusicScore[…]] creates a MIDI file from a MusicScore expression consisting of symbolic music primitives.
  • Export["file.mid",expr,elem] creates a MIDI file by treating expr as specifying element elem.
  • The file format can be explicitly specified using Export["file",Sound[…],"MIDI"].
  • See the following reference pages for full general information:
  • Import, Exportimport from or export to a file
    CloudImport, CloudExportimport from or export to a cloud object
    ImportString, ExportStringimport from or export to a string
    ImportByteArray, ExportByteArrayimport from or export to a byte array

Import Elements

  • General Import elements:
  • "Elements" list of elements and options available in this file
    "Summary"summary of the file
    "Rules"list of rules for all available elements
  • Data representation elements:
  • "Sound"MIDI file represented as a Sound object
    "Sound",nn^(th) tracks of the MIDI file given as a Sound object
    "SoundNotes"sound notes of all tracks in the MIDI file
    "SoundNotes",nsound notes of the n^(th) tracks in the MIDI file
    "MusicScore"MIDI file represented as a MusicNote object
    "MusicVoice"MusicVoice objects from the tracks of the MIDI file
    "MusicVoice",nMusicVoice object from the n^(th) track of the MIDI file
    "RawData"raw events of all tracks in the MIDI file
    "RawData",nraw events of the n^(th) tracks in the MIDI file
  • Metadata elements:
  • "Metadata"metadata of all tracks in the MIDI file
    "Metadata",nmetadata of the n^(th) tracks in the MIDI file
    "Duration"duration in seconds
    "Header"header in the MIDI file
    "TrackCount"number of tracks in the MIDI file
  • Data representation element:
  • "Sound"a Sound expression consisting of SoundNote primitives
  • Export by default uses the "Sound" element for MIDI files.
  • Export["file.mid",Sound[ SoundNote[0]]] creates a MIDI file representing the "middle C" note played for 1 second in the default "Piano" style.
  • The pitch specification 0 in the Wolfram Language corresponds to MIDI pitch level 60.
  • Export["file.mid",Sound[SoundNote[pitch,t,"style"]]] specifies a duration t and an instrument style. The following General MIDI styles are supported:
  • "Accordion""Agogo""AltoSax""Applause"
    "Atmosphere""Bagpipe""Bandoneon""Banjo"
    "BaritoneSax""Bass""BassAndLead""Bassoon"
    "Bird""BlownBottle""Bowed""BrassSection"
    "Breath""Brightness""BrightPiano""Calliope"
    "Celesta""Cello""Charang""Chiff"
    "Choir""Clarinet""Clavi""Contrabass"
    "Crystal""DrawbarOrgan""Dulcimer""Echoes"
    "ElectricBass""ElectricGrandPiano""ElectricGuitar""ElectricPiano"
    "ElectricPiano2""EnglishHorn""Fiddle""Fifths"
    "Flute""FrenchHorn""FretlessBass""FretNoise"
    "Glockenspiel""Goblins""Guitar""GuitarDistorted"
    "GuitarHarmonics""GuitarMuted""GuitarOverdriven""Gunshot"
    "Halo""Harmonica""Harp""Harpsichord"
    "Helicopter""HonkyTonkPiano""JazzGuitar""Kalimba"
    "Koto""Marimba""MelodicTom""Metallic"
    "MusicBox""MutedTrumpet""NewAge""Oboe"
    "Ocarina""OrchestraHit""Organ""PanFlute"
    "PercussiveOrgan""Piano""Piccolo""PickedBass"
    "PizzicatoStrings""Polysynth""Rain""Recorder"
    "ReedOrgan""ReverseCymbal""RockOrgan""Sawtooth"
    "SciFi""Seashore""Shakuhachi""Shamisen"
    "Shanai""Sitar""SlapBass""SlapBass2"
    "SopranoSax""Soundtrack""Square""Steeldrums"
    "SteelGuitar""Strings""Strings2""Sweep"
    "SynthBass""SynthBass2""SynthBrass""SynthBrass2"
    "SynthDrum""SynthStrings""SynthStrings2""SynthVoice"
    "Taiko""Telephone""TenorSax""Timpani"
    "Tinklebell""TremoloStrings""Trombone""Trumpet"
    "Tuba""TubularBells""Vibraphone""Viola"
    "Violin""Voice""VoiceAahs""VoiceOohs"
    "Warm""Whistle""Woodblock""Xylophone"
  • Percussion sounds are represented as an expression of the form SoundNote["perc",t]. Possible percussion styles include:
  • "BassDrum""BassDrum2""BellTree""Cabasa"
    "Castanets""ChineseCymbal""Clap""Claves"
    "Cowbell""CrashCymbal""CrashCymbal2""ElectricSnare"
    "GuiroLong""GuiroShort""HighAgogo""HighBongo"
    "HighCongaMute""HighCongaOpen""HighFloorTom""HighTimbale"
    "HighTom""HighWoodblock""HiHatClosed""HiHatOpen"
    "HiHatPedal""JingleBell""LowAgogo""LowBongo"
    "LowConga""LowFloorTom""LowTimbale""LowTom"
    "LowWoodblock""Maracas""MetronomeBell""MetronomeClick"
    "MidTom""MidTom2""MuteCuica""MuteSurdo"
    "MuteTriangle""OpenCuica""OpenSurdo""OpenTriangle"
    "RideBell""RideCymbal""RideCymbal2""ScratchPull"
    "ScratchPush""Shaker""SideStick""Slap"
    "Snare""SplashCymbal""SquareClick""Sticks"
    "Tambourine""Vibraslap""WhistleLong""WhistleShort"
  • Import by default uses the "Sound" element when importing from MIDI.

Options

  • General Import options:
  • MusicTempoAutomaticforce a specific tempo when importing "MusicScore" and "MusicVoice" elements
    "QuantizationLevel"Automaticrounding of timestamps to be used in "MusicScore" and "MusicVoice" elements
  • Possible settings for the "QuantizationLevel" option include:
  • Automaticautomatically computed rounding according to the statistics of the input
    Noneno time rounding
    dtimes are quantized as multiples of d whole notes

Examples

open all close all

Basic Examples  (6)

A sequence of three notes, each played for 1.75 seconds:

Wolfram Language code: Sound[SoundNote[#, 1.75, "Trumpet"]& /@ {0, 7, 12}]

Export to a MIDI file:

Wolfram Language code: Export["sequence.mid", %]

This exports some chord notes to MIDI:

Wolfram Language code: Sound[{SoundNote[{-12, 0, 4, 7, 12, 16}, 0.2, "Trumpet"], SoundNote[{-12, 0, 3, 7, 12, 15}, 2.2, "Trumpet"]}]
Wolfram Language code: Export["chords.mid", %]

Export a few percussion sounds to MIDI:

Wolfram Language code: Export["perc.mid", Sound[ SoundNote["RideCymbal", #] & /@ {0.26, 0.1, 0.26, 0.1, 2} ] ]

A simple MusicScore object with a single voice:

Wolfram Language code: MusicScore[{"G", "A", "D", "C"}]
Wolfram Language code: Export["score.mid", %]

A score with multiple voices:

Wolfram Language code: MusicScore[{MusicVoice@{"G", "A", "D", "C"}, MusicVoice[{"C", "D", "F", "G"}]}]
Wolfram Language code: Export["score2.mid", %]

Import a MIDI file as a Sound object:

Wolfram Language code: Import["ExampleData/scaleprogression.mid"]

Import a MIDI file as a MusicScore object:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicScore"]

Import a MIDI file as a list of MusicVoice objects:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicVoice"]

Scope  (3)

This creates a musical fragment in the style of WolframTones by taking cellular automaton data and mapping it to musical notes:

Wolfram Language code: Sound[SoundNote[#, 1 / 5, "Harpsichord"]& /@ (Pick[{0, 4, 7, 12, 16}, #, 1]& /@ CellularAutomaton[ 60, {{1, 0, 0, 0, 0}, 0}, 15, {15, 4}]) ]

Export to MIDI:

Wolfram Language code: Export["rule60.mid", %]

Generate a basic algorithmic composition and export it to MIDI:

Wolfram Language code: Sound[Table[SoundNote[ #, 1 / 12, "Harp" ]& /@ Pick[Range[12], IntegerDigits[scale, 2, 12], 1], {scale, 2304, 2352}]]
Wolfram Language code: Export["scaleprogression.mid", %]

Import the SoundNote objects contained in a MIDI file:

Wolfram Language code: sn = Import["ExampleData/scaleprogression.mid", "SoundNotes"]; Take[sn[[1]], 10]

Replay the notes in the MIDI file using an organ instead of a harp:

Wolfram Language code: Sound[sn /. {"Harp" -> "Organ"}]

Import Options  (2)

"QuantizationLevel"  (1)

Import a MIDI file as a MusicScore object:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicScore"]

Avoid any quantization:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicScore", "QuantizationLevel" -> None]

Set the quantization level to 1/32:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicScore", "QuantizationLevel" -> 1 / 32]

MusicTempo  (1)

Import a MIDI file as a MusicScore object:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicScore"]

Note that the note durations are a bit unusual:

Wolfram Language code: MusicMeasurements[%, "NoteList"][[1, ;; 4]]

Force the import to use 180 beats per minute as tempo by using the MusicTempo option:

Wolfram Language code: Import["ExampleData/scaleprogression.mid", "MusicScore", MusicTempo -> 180]
Wolfram Language code: MusicMeasurements[%, "NoteList"][[1, ;; 4]]
