JacobiCD

JacobiCD[u,m]

gives the Jacobi elliptic function .

Details

  • Mathematical function, suitable for both symbolic and numerical manipulation.
  • , where .
  • is a doubly periodic function in u with periods and , where is the elliptic integral EllipticK.
  • JacobiCD is a meromorphic function in both arguments.
  • For certain special arguments, JacobiCD automatically evaluates to exact values.
  • JacobiCD can be evaluated to arbitrary numerical precision.
  • JacobiCD automatically threads over lists.

Examples

open all close all

Basic Examples  (4)

Evaluate numerically:

Wolfram Language code: JacobiCD[3.14, 0.3]

Plot the function over a subset of the reals:

Wolfram Language code: Plot[JacobiCD[x, 1 / 3], {x, -6, 6}]

Plot over a subset of the complexes:

Wolfram Language code: ComplexPlot3D[JacobiCD[z, 1 / 3], {z, -2 - 2I, 2 + 2I}, PlotLegends -> Automatic]

Series expansions at the origin:

Wolfram Language code: Series[JacobiCD[z, m], {z, 0, 6}]
Wolfram Language code: Series[JacobiCD[z, m], {m, 0, 1}]

Scope  (34)

Numerical Evaluation  (5)

Evaluate to high precision:

Wolfram Language code: N[JacobiCD[3, 1 / 2], 50]

The precision of the output tracks the precision of the input:

Wolfram Language code: JacobiCD[3, 0.500000000000000000000000000000000000000]

Evaluate for complex arguments:

Wolfram Language code: JacobiCD[2.5 + I, 0.2 - 0.3 I]

Evaluate JacobiCD efficiently at high precision:

Wolfram Language code: JacobiCD[2, 0.3`500]//Timing
Wolfram Language code: JacobiCD[2, 0.3`10000];//Timing

Compute average-case statistical intervals using Around:

Wolfram Language code: JacobiCD[2, Around[1 / 2, 0.01]]

Compute the elementwise values of an array:

Wolfram Language code: JacobiCD[-(π/3), {{1, 0}, {0, 1}}]

Or compute the matrix JacobiCD function using MatrixFunction:

Wolfram Language code: MatrixFunction[JacobiCD[-(π/3), #]&, {{1, 0}, {0, 1}}]

Specific Values  (3)

Simple exact answers are generated automatically:

Wolfram Language code: {JacobiCD[z, 0], JacobiCD[z, 1]}
Wolfram Language code: {JacobiCD[0, m], JacobiCD[EllipticK[m] / 2, m], JacobiCD[EllipticK[m], m]}

Some poles of JacobiCD:

Wolfram Language code: {JacobiCD[EllipticK[m] + I EllipticK[1 - m], m], JacobiCD[3EllipticK[m] + I EllipticK[1 - m], m], JacobiCD[3EllipticK[m] + 3 I EllipticK[1 - m], m]}

Find a zero of TemplateBox[{x, {1, /, 3}}, JacobiCD]:

Wolfram Language code: xzero = N@Solve[JacobiCD[x, 1 / 3] == 0 && 1 < x < 2, x][[1, 1, 2]]//Quiet
Wolfram Language code: Plot[JacobiCD[x, 1 / 3], {x, -π, 2π}, Epilog -> Style[Point[{xzero, JacobiCD[xzero, 1 / 3]}], PointSize[Large], Red]]

Visualization  (3)

Plot the JacobiCD functions for various values of parameter:

Wolfram Language code: Plot[{JacobiCD[x, 0], JacobiCD[x, 0.8], JacobiCD[x, 3], JacobiCD[x, -3]}, {x, -2π, 2π}]

Plot JacobiCD as a function of its parameter :

Wolfram Language code: Plot[{JacobiCD[1, m], JacobiCD[2, m], JacobiCD[3, m]}, {m, -10, 10}]

Plot the real part of TemplateBox[{z, {1, /, 2}}, JacobiCD]:

Wolfram Language code: ComplexContourPlot[Re[JacobiCD[z, 1 / 2]], {z, -8 - 8 I, 8 + 8 I}, IconizedObject[«PlotOptions»]]

Plot the imaginary part of TemplateBox[{z, {1, /, 2}}, JacobiCD]:

Wolfram Language code: ComplexContourPlot[Im[JacobiCD[z, 1 / 2]], {z, -8 - 8 I, 8 + 8 I}, IconizedObject[«PlotOptions»]]

Function Properties  (8)

JacobiCD is 4 TemplateBox[{m}, EllipticK]-periodic along the real axis:

Wolfram Language code: JacobiCD[x, m] == JacobiCD[x + 4EllipticK[m], m]

JacobiCD is 2ⅈTemplateBox[{{1, -, m}}, EllipticK]-periodic along the imaginary axis:

Wolfram Language code: JacobiCD[x, m] == JacobiCD[x + 2I EllipticK[1 - m], m]

JacobiCD is an even function in its first argument:

Wolfram Language code: JacobiCD[-x, m] == JacobiCD[x, m]

TemplateBox[{x, m}, JacobiCD] is an analytic function of for :

Wolfram Language code: FunctionAnalytic[JacobiCD[x, m], x, Assumptions -> m <= 1]

It is not, in general, an analytic function:

Wolfram Language code: FunctionAnalytic[JacobiCD[x, m], {x, m}]//Quiet

It has both singularities and discontinuities for :

Wolfram Language code: FunctionSingularities[JacobiCD[x, m], {x, m}]
Wolfram Language code: FunctionDiscontinuities[JacobiCD[x, m], {x, m}]

TemplateBox[{x, {1, /, 3}}, JacobiCD] is neither nondecreasing nor nonincreasing:

Wolfram Language code: FunctionMonotonicity[JacobiCD[x, 1 / 3], x]

TemplateBox[{x, m}, JacobiDC] is not injective for any fixed :

Wolfram Language code: FunctionInjective[JacobiCD[x, m], x, Assumptions -> m < 1]
Wolfram Language code: FunctionInjective[JacobiCD[x, m], x, Assumptions -> m > 1]
Wolfram Language code: FunctionInjective[JacobiCD[x, 1], x]
Wolfram Language code: Plot[{JacobiCD[x, 3], .5}, {x, -10, 10}]

TemplateBox[{x, m}, JacobiCD] is not surjective for any fixed :

Wolfram Language code: FunctionSurjective[JacobiCD[x, m], x, Assumptions -> m∈Reals]
Wolfram Language code: Plot[{JacobiCD[x, 1 / 3], -1.5}, {x, -10, 10}]

JacobiCD is neither non-negative nor non-positive:

Wolfram Language code: FunctionSign[JacobiCD[x, m], {x, m}]

JacobiCD is neither convex nor concave:

Wolfram Language code: FunctionConvexity[JacobiCD[x, m], {x, m}]

Differentiation  (3)

First derivative:

Wolfram Language code: D[JacobiCD[x, m], x]

Higher derivatives:

Wolfram Language code: derivs = Table[D[JacobiCD[x, m], {x, n}], {n, 1, 3}]

Plot higher derivatives for :

Wolfram Language code: Plot[Evaluate[derivs /. m -> 1 / 3], {x, -6, 6}, PlotLegends -> {"First Derivative", "Second Derivative", "Third Derivative"}]

Derivative with respect to :

Wolfram Language code: D[JacobiCD[x, m], m]

Integration  (3)

Indefinite integral of JacobiCD:

Wolfram Language code: Integrate[JacobiCD[z, m], z]

Definite integral of an even integrand over the interval centered at the origin:

Wolfram Language code: Integrate[JacobiCD[z, 1 / 3], {z, -1, 1}]

This is twice the integral over half the interval:

Wolfram Language code: 2 Integrate[JacobiCD[z, 1 / 3], {z, 0, 1}] == Integrate[JacobiCD[z, 1 / 3], {z, -1, 1}]//FullSimplify

More integrals:

Wolfram Language code: Integrate[JacobiCD[z, m] JacobiSN[z, m], z]
Wolfram Language code: Integrate[JacobiCD[z, m] ^ 3, z]//FullSimplify

Series Expansions  (3)

Taylor expansion for TemplateBox[{x, {1, /, 3}}, JacobiCD]:

Wolfram Language code: Series[JacobiCD[x, 1 / 3], {x, 0, 7}]

Plot the first three approximations for TemplateBox[{x, {1, /, 3}}, JacobiCD] around :

Wolfram Language code: terms = Normal@Table[Series[JacobiCD[x, 1 / 3], {x, 0, n}], {n, 2, 7, 2}]; Plot[{JacobiCD[x, 1 / 3], terms}, {x, -2.5, 2.5}]

Taylor expansion for TemplateBox[{1, m}, JacobiCD]:

Wolfram Language code: Series[JacobiCD[1, m], {m, 0, 3}]//Simplify

Plot the first three approximations for TemplateBox[{1, m}, JacobiCD] around :

Wolfram Language code: terms = Normal@Table[Series[JacobiCD[1, m], {m, 0, n}], {n, 1, 3}]; Plot[{JacobiCD[1, m], terms}, {m, -2, 2}]

JacobiCD can be applied to a power series:

Wolfram Language code: JacobiCD[u, m + m ^ 2 + O[m] ^ 3]//Simplify

Function Identities and Simplifications  (3)

Primary definition:

Wolfram Language code: JacobiCD[z, m] == (JacobiCN[z, m]/JacobiDN[z, m])//FullSimplify

Parity transformations and periodicity relations are automatically applied:

Wolfram Language code: JacobiCD[-u, m]
Wolfram Language code: JacobiCD[u + 4 EllipticK[m] + 2I EllipticK[1 - m], m]

Automatic argument simplifications:

Wolfram Language code: JacobiCD[z + I EllipticK[1 - m], m]
Wolfram Language code: JacobiCD[z + EllipticK[m], m]

Function Representations  (3)

Representation in terms of trigonometry functions and JacobiAmplitude:

Wolfram Language code: JacobiCD[z, m]^2 == (Cos[JacobiAmplitude[z, m]]^2/1 - m Sin[JacobiAmplitude[z, m]]^2)//FullSimplify

Relation to other Jacobi elliptic functions:

Wolfram Language code: JacobiCD[z, m] == (1/JacobiDC[z, m])//FullSimplify
Wolfram Language code: JacobiCD[z, m]^2 == (1 - (1 - m) JacobiND[z, m]^2/m)//FullSimplify

TraditionalForm formatting:

Wolfram Language code: JacobiCD[u, m]//TraditionalForm

Applications  (4)

Derivatives of Jacobi elliptic functions with respect to parameter :

Wolfram Language code: D[JacobiSN[u, m], m]

Conformal map from a unit triangle to the unit disk:

Wolfram Language code: w[z_] := With[{ζ = z(Gamma[1 / 3]^3/2^1 / 3 3^1 / 4 π), m = Sin[(π/12)] ^ 2}, (2^11 / 6 Sqrt[1 - m] (1 - JacobiCD[ζ, m] JacobiDN[ζ, m]) (1 + Sqrt[(m/1 - m)] JacobiCD[ζ, m] JacobiDN[ζ, m])) / ((-1 + JacobiCD[ζ, m] JacobiDN[ζ, m])^2 + 2 3^1 / 4 JacobiDN[ζ, m] JacobiSN[ζ, m])]

Show points before and after the map:

Wolfram Language code: trianglePoints = With[{t = E ^ (2 Pi I / 3)}, Flatten[Table[α / 8. Table[N[#1 + j / 16(#2 - #1)], {j, 0, 16}]&@@@({{1, t}, {t, 1 / t}, {1 / t, 1}} / Sqrt[3]), {α, 8}]]];
Wolfram Language code: Row[{Graphics[Point[{Re[#], Im[#]}]& /@ trianglePoints, Frame -> True, ImageSize -> Small], Graphics[Point[{Re[#], Im[#]}]& /@ w[trianglePoints], Frame -> True, ImageSize -> Small]}, Spacer[20]]

Solution of the Poisson–Boltzmann equation :

Wolfram Language code: ψ[x_, y_] = 4 ArcTanh[Sqrt[1 + (2/-1 + α^2 + β^2)] JacobiCD[x α, ((1 + α^2)^2 - β^4/4 α^2)] JacobiCD[y β, (-α^4 + (1 + β^2)^2/4 β^2)]JacobiDN[x α, ((1 + α^2)^2 - β^4/4 α^2)] JacobiDN[y β, (-α^4 + (1 + β^2)^2/4 β^2)]];

Check solution using series expansion:

Wolfram Language code: Series[Subscript[∂, x, x]ψ[x, y] + Subscript[∂, y, y]ψ[x, y] - Sinh[ψ[x, y]], {x, 0, 3}, {y, 0, 3}]//Normal

Construct lowpass elliptic filter for analog signal:

Wolfram Language code: 𝒩 = 5;ωPass = 4.8;ℊPass = 0.92;ℊStop = 0.08;

Compute filter ripple parameters and associate elliptic function parameter:

Wolfram Language code: ϵp = Sqrt[ℊPass^-2 - 1];ϵs = Sqrt[ℊStop^-2 - 1]; m1 = (ϵp / ϵs)^2; K1 = EllipticK[m1]; K1p = EllipticK[1 - m1];

Use elliptic degree equation to find the ratio of the pass and the stop frequencies:

Wolfram Language code: us = Range[1, 2⌊(𝒩/2)⌋ - 1, 2] / 𝒩; m = 1 - (1 - m1) ^ 𝒩 Apply[Times, JacobiSN[us K1p, 1 - m1] ^ 8]

Compute corresponding stop frequency and elliptic parameters:

Wolfram Language code: K = EllipticK[m];Kp = EllipticK[1 - m]; ωStop = ωPass / Sqrt[m]

Compute ripple locations and poles and zeros of the transfer function:

Wolfram Language code: ζs = JacobiCD[us K, m]; zeros = I ωStop / ζs;

Compute poles of the transfer function:

Wolfram Language code: Subscript[ν, 0] = (1/𝒩 K1)InverseJacobiSC[(1/ϵp), 1 - m1]; poles = ωPass I JacobiCD[(us - I Subscript[ν, 0])K, m];

Assemble the transfer function:

Wolfram Language code: H[ω_] = Piecewise[{{ℊPass, Mod[𝒩, 2] == 0}, {(1/1 + I ω / ωPass JacobiCS[Subscript[ν, 0] K, 1 - m]), Mod[𝒩, 2] == 1}}] Apply[Times, ((1 - I ω / zeros)(1 - I ω / Conjugate[zeros])/(1 - I ω / poles)(1 - I ω / Conjugate[poles]))];
Wolfram Language code: Plot[Abs[H[ω]], {ω, 0, 8}, PlotRange -> All, Epilog -> {Pink, Dashed, Line[{{0, ℊPass}, {ωPass, ℊPass}, {ωPass, ℊStop}}], Line[{{ωStop, ℊPass}, {ωStop, ℊStop}, {10, ℊStop}}]}]

Compare with the result of EllipticFilterModel:

Wolfram Language code: tf = EllipticFilterModel[{"Lowpass", {ωPass, ωStop}, -20Log10[{ℊPass, ℊStop}]}];
Wolfram Language code: Plot[Abs[tf[I ω]], {ω, 0, 8}]

Properties & Relations  (3)

Compose with inverse functions:

Wolfram Language code: {JacobiCD[InverseJacobiCD[z, m], m], InverseJacobiCD[JacobiCD[z, m], m]}

Use PowerExpand to disregard multivaluedness of the inverse function:

Wolfram Language code: PowerExpand[%]

Solve a transcendental equation:

Wolfram Language code: Solve[JacobiCD[x, m]^2 + 3JacobiCD[x, m] == a, x]

Integrals:

Wolfram Language code: Integrate[JacobiCD[z, m], z]

Possible Issues  (2)

Machine-precision input is insufficient to give the correct answer:

Wolfram Language code: JacobiCD[10. ^ 16, 2 / 7]
Wolfram Language code: N[JacobiCD[10 ^ 16, 2 / 7], 20]

Currently only simple simplification rules are built in for Jacobi functions:

Wolfram Language code: JacobiCD[z, m] - (JacobiCN[z, m]/JacobiDN[z, m])
Wolfram Language code: FullSimplify[%]
Wolfram Language code: 1 - JacobiSN[u, m]^2 + JacobiCD[u, m]^2 (-1 + m JacobiSN[u, m]^2)//FullSimplify
