JacobiCS[u,m]

gives the Jacobi elliptic function .

Details
Details and Options Details and Options
Examples
Basic Examples
Scope
Numerical Evaluation
Specific Values
Visualization
Show More Show More
Function Properties
Differentiation
Integration
Series Expansions
Function Identities and Simplifications
Function Representations
Applications
Properties & Relations
Possible Issues
See Also
Tech Notes
Related Guides
Related Links
History
Cite this Page

JacobiCS

JacobiCS[u,m]

gives the Jacobi elliptic function .

Details

  • Mathematical function, suitable for both symbolic and numerical manipulation.
  • , where .
  • is a doubly periodic function in u with periods and , where is the elliptic integral EllipticK.
  • JacobiCS is a meromorphic function in both arguments.
  • For certain special arguments, JacobiCS automatically evaluates to exact values.
  • JacobiCS can be evaluated to arbitrary numerical precision.
  • JacobiCS automatically threads over lists.

Examples

open all close all

Basic Examples  (5)

Evaluate numerically:

Wolfram Language code: JacobiCS[0.2, 0.5]

Plot the function over a subset of the reals:

Wolfram Language code: Plot[JacobiCS[u, 1 / 3], {u, -6, 6}]

Plot over a subset of the complexes:

Wolfram Language code: ComplexPlot3D[JacobiCS[z, 1 / 3], {z, -2 - 2I, 2 + 2I}, PlotLegends -> Automatic]

Series expansions at the origin:

Wolfram Language code: Series[JacobiCS[u, m], {u, 0, 5}]
Wolfram Language code: Series[JacobiCS[u, m], {m, 0, 1}]

Series expansion at a singular point:

Wolfram Language code: Series[JacobiCS[x, 1], {x, I π, 3}]

Scope  (34)

Numerical Evaluation  (5)

Evaluate numerically to high precision:

Wolfram Language code: N[JacobiCS[Pi / 3, 1 / 3], 50]

The precision of the output tracks the precision of the input:

Wolfram Language code: JacobiCS[Pi / 3, 0.3333333333333333333333333333333333]

Evaluate for complex arguments:

Wolfram Language code: JacobiCS[5.2 - 2.5I, 0.3 + I]

Evaluate JacobiCS efficiently at high precision:

Wolfram Language code: JacobiCS[Pi / 3, 0.3`500]//Timing
Wolfram Language code: JacobiCS[Pi / 3, 0.3`10000];//Timing

Compute average-case statistical intervals using Around:

Wolfram Language code: JacobiCS[2, Around[1 / 2, 0.01]]

Compute the elementwise values of an array:

Wolfram Language code: JacobiCS[-(I π/3), {{1, 0}, {0, 1}}]

Or compute the matrix JacobiCS function using MatrixFunction:

Wolfram Language code: MatrixFunction[JacobiCS[-(I π/3), #]&, {{1, 0}, {0, 1}}]

Specific Values  (3)

Simple exact values are generated automatically:

Wolfram Language code: {JacobiCS[z, 0], JacobiCS[z, 1]}
Wolfram Language code: {JacobiCS[EllipticK[m] / 2, m], JacobiCS[EllipticK[m], m], JacobiCS[3 I EllipticK[1 - m], m]}

Some poles of JacobiCS:

Wolfram Language code: {JacobiCS[0, m], JacobiCS[2EllipticK[m], m], JacobiCS[2I EllipticK[1 - m], m]}

Find a zero of TemplateBox[{x, {1, /, 3}}, JacobiCS]:

Wolfram Language code: xzero = N@Solve[JacobiCS[x, 1 / 3] == 0 && 1.0 < x < 3.0, x][[1, 1, 2]]//Quiet
Wolfram Language code: Plot[JacobiCS[x, 1 / 3], {x, -3, 5}, Epilog -> Style[Point[{xzero, JacobiCS[xzero, 1 / 3]}], PointSize[Large], Red]]

Visualization  (3)

Plot the JacobiCS functions for various parameter values:

Wolfram Language code: Plot[{JacobiCS[x, 0], JacobiCS[x, 3], JacobiCS[x, -3]}, {x, -3.5, 3.5}]

Plot JacobiCS as a function of its parameter :

Wolfram Language code: Plot[{JacobiCS[1, m], JacobiCS[3 / 2, m], JacobiCS[2, m]}, {m, -10, 10}]

Plot the real part of TemplateBox[{z, {1, /, 2}}, JacobiCS]:

Wolfram Language code: ComplexContourPlot[Re[JacobiCS[z, 1 / 2]], {z, -4 - 4 I, 4 + 4 I}, IconizedObject[«PlotOptions»]]

Plot the imaginary part of TemplateBox[{z, {1, /, 2}}, JacobiCS]:

Wolfram Language code: ComplexContourPlot[Im[JacobiCS[z, 1 / 2]], {z, -4 - 4 I, 4 + 4 I}, IconizedObject[«PlotOptions»]]

Function Properties  (8)

JacobiCS is 2 TemplateBox[{m}, EllipticK]-periodic along the real axis:

Wolfram Language code: JacobiCS[x, m] == JacobiCS[x + 2EllipticK[m], m]

JacobiCS is 4ⅈTemplateBox[{{1, -, m}}, EllipticK]-periodic along the imaginary axis:

Wolfram Language code: JacobiCS[x, m] == JacobiCS[x + 4I EllipticK[1 - m], m]

JacobiCS is an odd function in its first argument:

Wolfram Language code: JacobiCS[-x, m] == -JacobiCS[x, m]

JacobiCS is not an analytic function:

Wolfram Language code: FunctionAnalytic[JacobiCS[x, m], {x, m}]

It has both singularities and discontinuities:

Wolfram Language code: FunctionSingularities[JacobiCS[x, m], {x, m}]
Wolfram Language code: FunctionDiscontinuities[JacobiCS[x, m], {x, m}]

TemplateBox[{x, 3}, JacobiCS] is neither nondecreasing nor nonincreasing:

Wolfram Language code: FunctionMonotonicity[JacobiCS[x, 3], x]

TemplateBox[{x, m}, JacobiCS] is not injective for any fixed :

Wolfram Language code: FunctionInjective[JacobiCS[x, m], x, Assumptions -> m < 1]
Wolfram Language code: FunctionInjective[JacobiCS[x, m], x, Assumptions -> m > 1]
Wolfram Language code: Plot[{JacobiCS[x, 1 / 3], 2}, {x, -5, 5}]

It is injective for :

Wolfram Language code: FunctionInjective[JacobiCS[x, 1], x]
Wolfram Language code: Plot[{JacobiCS[x, 1], 2}, {x, -5, 5}]

TemplateBox[{x, m}, JacobiCS] is not surjective for fixed :

Wolfram Language code: FunctionSurjective[JacobiCS[x, m], x, Assumptions -> m >= 1]
Wolfram Language code: Plot[{JacobiCS[x, 3], .5}, {x, -5, 5}]

It is surjective for :

Wolfram Language code: FunctionSurjective[JacobiCS[x, m], x, Assumptions -> m < 1]

JacobiCS is neither non-negative nor non-positive:

Wolfram Language code: FunctionSign[JacobiCS[x, m], {x, m}]

JacobiCS is neither convex nor concave:

Wolfram Language code: FunctionConvexity[JacobiCS[x, m], {x, m}]

Differentiation  (3)

First derivative:

Wolfram Language code: D[JacobiCS[x, m], x]

Higher derivatives:

Wolfram Language code: derivs = Table[D[JacobiCS[x, m], {x, n}], {n, 1, 4}]

Plot higher derivatives for :

Wolfram Language code: Plot[Evaluate[derivs /. m -> 1 / 3], {x, -3, 3}, PlotLegends -> {"First Derivative", "Second Derivative", "Third Derivative", "Fourth Derivative"}]

Derivative with respect to :

Wolfram Language code: D[JacobiCS[x, m], m]

Integration  (3)

Indefinite integral of JacobiCS:

Wolfram Language code: Integrate[JacobiCS[z, m], z]

Definite integral of an odd function over the interval centered at the origin is 0:

Wolfram Language code: Integrate[JacobiCS[z, 1 / 3], {z, -1, 1}, PrincipalValue -> True]

More integrals:

Wolfram Language code: Integrate[JacobiCS[z, m] JacobiDS[z, m], z]
Wolfram Language code: Integrate[1 / JacobiCS[z, m], z]

Series Expansions  (3)

Series expansion for TemplateBox[{x, {1, /, 3}}, JacobiCS]:

Wolfram Language code: Series[JacobiCS[x, 1 / 3], {x, 0, 7}]

Plot the first three approximations for TemplateBox[{x, {1, /, 3}}, JacobiCS] around :

Wolfram Language code: terms = Normal@{Series[JacobiCS[x, 1 / 3], {x, 0, 0}], Series[JacobiCS[x, 1 / 3], {x, 0, 1}], Series[JacobiCS[x, 1 / 3], {x, 0, 3}]}; Plot[{JacobiCS[x, 1 / 3], terms}, {x, 0, 3}]

Taylor expansion for TemplateBox[{1, m}, JacobiCS]:

Wolfram Language code: Series[JacobiCS[1, m], {m, 0, 3}]//Simplify

Plot the first three approximations for TemplateBox[{1, m}, JacobiCS] around :

Wolfram Language code: terms = Normal@Table[Series[JacobiCS[1, m], {m, 0, n}], {n, 1, 3}]; Plot[{JacobiCS[1, m], terms}, {m, -4, 4}, PlotLegends -> {"cs(1❘m)", "cot(1)-FractionBox[1, 8]SuperscriptBox[cot, 2](1)(sin(2)-2)m", "Second approximation", "Third approximation"}]

JacobiCS can be applied to a power series:

Wolfram Language code: JacobiCS[EllipticK[m] + ArcSin[x] + O[x] ^ 8, m]

Function Identities and Simplifications  (3)

Primary definition:

Wolfram Language code: JacobiCS[z, m] == (JacobiCN[z, m]/JacobiSN[z, m])//FullSimplify

Parity transformation and periodicity relations are automatically applied:

Wolfram Language code: JacobiCS[-u, m]
Wolfram Language code: JacobiCS[u + 2 EllipticK[m] + 4I EllipticK[1 - m], m]

Automatic argument simplifications:

Wolfram Language code: JacobiCS[z + EllipticK[m], m]
Wolfram Language code: JacobiCS[z + I EllipticK[1 - m], m]

Function Representations  (3)

Representation in terms of Cot of JacobiAmplitude:

Wolfram Language code: Cot[JacobiAmplitude[z, m]]//FullSimplify

Relation to other Jacobi elliptic functions:

Wolfram Language code: JacobiCS[z, m] == (1/JacobiSC[z, m])//FullSimplify
Wolfram Language code: JacobiCS[z, m]^2 == m - 1 + JacobiDS[z, m]^2//FullSimplify

TraditionalForm formatting:

Wolfram Language code: JacobiCS[z, m]//TraditionalForm

Applications  (5)

Hierarchy of solutions of the nonlinear diffusion equation :

Wolfram Language code: φ[0, y_] := JacobiDS[y, 1 / 2]; φ[n_, y_] := D[Log[φ[n - 1, y]], y];u[n_, {t_, x_}] := 2 x φ[n, y] /. y -> x^2 + 6 t
Wolfram Language code: Table[u[k, {t, x}], {k, 0, 2}]//Simplify

Check:

Wolfram Language code: (D[u[t, x], t] - D[u[t, x], x, x] + 2u[t, x] ^ 3 /. u -> Function[{t, x}, Evaluate[%]])//FullSimplify

Flow lines in a rectangular region with a current flowing from the lower‐right to the upper‐left corner:

Wolfram Language code: With[{m = 0.4, ε = 1 / 10 ^ 6}, ContourPlot[(JacobiDN[x, m]JacobiDN[y, 1 - m]/JacobiCS[x, m]JacobiCS[y, 1 - m]), {x, ε, EllipticK[m]}, {y, ε, EllipticK[1 - m]}, ContourShading -> False]]

Conformal map from a unit triangle to the unit disk:

Wolfram Language code: w[z_] := With[{ζ = (z Gamma[1 / 3] ^ 3/2^1 / 33^1 / 4π), m = Sin[π / 12] ^ 2}, 2^11 / 6Cos[π / 12](1 - JacobiCS[ζ, m]JacobiSN[ζ, m])(1 + Tan[π / 12]JacobiCS[ζ, m]JacobiSN[ζ, m]) / (2 3^1 / 4JacobiSN[ζ, m]JacobiDN[ζ, m] + (1 - JacobiCN[ζ, m]) ^ 2)]

Show points before and after the map:

Wolfram Language code: trianglePoints = With[{t = E ^ (2Pi I / 3)}, Flatten[Table[s / 8. Table[#1 + j / 16(#2 - #1), {j, 0, 16}]&@@@({{1, t}, {t, 1 / t}, {1 / t, 1}} / Sqrt[3]), {s, 8}]]];
Wolfram Language code: Row[{Graphics[Point[{Re[#], Im[#]}]& /@ trianglePoints, Frame -> True, ImageSize -> Small], Graphics[Point[{Re[#], Im[#]}]& /@ w[trianglePoints], Frame -> True, ImageSize -> Small]}, Spacer[20]]

Solution of the sinh‐Gordon equation :

Wolfram Language code: u[x_, t_] := 2ArcSinh[JacobiCS[x - t, m]]

Check the solution:

Wolfram Language code: FullSimplify[D[u[x, t], x, t] + Sinh[u[x, t]], JacobiNS[t - x, m] ^ 2 - JacobiCS[t - x, m] ^ 2 == 1]

Plot the solution:

Wolfram Language code: Plot3D[Evaluate[u[x, t] /. m -> 4 / 3], {x, -3, 2}, {t, 0, 5 / 2}]

Construct lowpass elliptic filter for analog signal:

Wolfram Language code: 𝒩 = 5;ωPass = 4.8;ℊPass = 0.92;ℊStop = 0.08;

Compute filter ripple parameters and associate elliptic function parameter:

Wolfram Language code: ϵp = Sqrt[ℊPass^-2 - 1];ϵs = Sqrt[ℊStop^-2 - 1]; m1 = (ϵp / ϵs)^2; K1 = EllipticK[m1]; K1p = EllipticK[1 - m1];

Use elliptic degree equation to find the ratio of the pass and the stop frequencies:

Wolfram Language code: us = Range[1, 2⌊(𝒩/2)⌋ - 1, 2] / 𝒩; m = 1 - (1 - m1) ^ 𝒩 Apply[Times, JacobiSN[us K1p, 1 - m1] ^ 8]

Compute corresponding stop frequency and elliptic parameters:

Wolfram Language code: K = EllipticK[m];Kp = EllipticK[1 - m]; ωStop = ωPass / Sqrt[m]

Compute ripple locations and poles and zeros of the transfer function:

Wolfram Language code: ζs = JacobiCD[us K, m]; zeros = I ωStop / ζs;

Compute poles of the transfer function:

Wolfram Language code: Subscript[ν, 0] = (1/𝒩 K1)InverseJacobiSC[(1/ϵp), 1 - m1]; poles = ωPass I JacobiCD[(us - I Subscript[ν, 0])K, m];

Assemble the transfer function:

Wolfram Language code: H[ω_] = Piecewise[{{ℊPass, Mod[𝒩, 2] == 0}, {(1/1 + I ω / ωPass JacobiCS[Subscript[ν, 0] K, 1 - m]), Mod[𝒩, 2] == 1}}] Apply[Times, ((1 - I ω / zeros)(1 - I ω / Conjugate[zeros])/(1 - I ω / poles)(1 - I ω / Conjugate[poles]))];
Wolfram Language code: Plot[Abs[H[ω]], {ω, 0, 8}, PlotRange -> All, Epilog -> {Pink, Dashed, Line[{{0, ℊPass}, {ωPass, ℊPass}, {ωPass, ℊStop}}], Line[{{ωStop, ℊPass}, {ωStop, ℊStop}, {10, ℊStop}}]}]

Compare with the result of EllipticFilterModel:

Wolfram Language code: tf = EllipticFilterModel[{"Lowpass", {ωPass, ωStop}, -20Log10[{ℊPass, ℊStop}]}];
Wolfram Language code: Plot[Abs[tf[I ω]], {ω, 0, 8}]

Properties & Relations  (2)

Compose with inverse functions:

Wolfram Language code: {JacobiCS[InverseJacobiCS[z, m], m], InverseJacobiCS[JacobiCS[z, m], m]}

Use PowerExpand to disregard multivaluedness of the inverse function:

Wolfram Language code: PowerExpand[%]

Solve a transcendental equation:

Wolfram Language code: Solve[JacobiCS[x, m]^2 + 3JacobiCS[x, m] == a, x]//Quiet

Possible Issues  (2)

Machine-precision input is insufficient to give the correct answer:

Wolfram Language code: JacobiCS[10. ^ 15, 3 / 7]
Wolfram Language code: N[JacobiCS[10 ^ 15, 3 / 7], 20]

Currently only simple simplification rules are built in for Jacobi functions:

Wolfram Language code: JacobiCS[z, m] - (JacobiCN[z, m]/JacobiSN[z, m])
Wolfram Language code: FullSimplify[%]
Wolfram Language code: JacobiCS[u, m]^2 + JacobiCD[u, m]^2 (-1 + m - JacobiCS[u, m]^2)//FullSimplify
