Labeled

Labeled[expr,lbl]

displays expr labeled with lbl.

Labeled[expr,lbl,pos]

places lbl at a position specified by pos.

Labeled[expr,{lbl1,lbl2,…},{pos1,…}]

places the lbli at positions posi.

Labeled[expr,{lbl1,lbl2,lbl3,lbl4},All]

places the lbli at the bottom, left, top, and right, respectively.

Details and Options

Examples

open all close all

Basic Examples  (2)

Create a label:

Wolfram Language code: Labeled[{a, b, c, d}, lbl]
Wolfram Language code: Labeled[Framed[{a, b, c, d}], lbl]

Label on the left:

Wolfram Language code: Labeled[Framed[{a, b, c, d}], lbl, Left]

Label on the left and top:

Wolfram Language code: Labeled[Framed[{a, b, c, d}], {xxx, yyy}, {Left, Top}]

Scope  (5)

Label a graphic:

Wolfram Language code: Labeled[Graphics[Circle[]], Text["a circle"]]

Label a slider:

Wolfram Language code: Labeled[Slider[], "slider"]
Wolfram Language code: Labeled[Slider[], "slider", Left]

Use a checkbox as a label:

Wolfram Language code: Labeled[Framed[{a, b, c}], Checkbox[]]

Control the placement of labels:

Wolfram Language code: g = Graphics[Circle[], ImageSize -> 50];
Wolfram Language code: Labeled[g, lbl]

Put the label at the bottom, aligned left:

Wolfram Language code: Labeled[g, lbl, {{Bottom, Left}}]

Put the label on the right, aligned at the top:

Wolfram Language code: Labeled[g, lbl, {{Right, Top}}]

Use graphics as labels:

Wolfram Language code: d = Graphics[Circle[], ImageSize -> 20];
Wolfram Language code: Labeled[30!, {d, d, d}, {Top, Bottom, Left}]

Options  (18)

Alignment  (1)

Adjust the alignment of the labeled expression:

Wolfram Language code: Grid[Table[Labeled[Range[4], "lbl", ContentSize -> {150, 50}, Alignment -> {i, j}], {j, {Top, Center, Bottom}}, {i, {Left, Center, Right}}], Frame -> All]

Background  (1)

Change the overall background color:

Wolfram Language code: Labeled[{1, 2, 3, 4}, lbl, Background -> StandardGray]

BaselinePosition  (1)

Align with surrounding text:

Wolfram Language code: Row[Table[Labeled[{1, 2, 3, 4}, lbl, BaselinePosition -> p], {p, {Top, Center, Bottom}}], " xxx "]

ContentSize  (1)

Specify a fixed content size:

Wolfram Language code: Table[Labeled[{1, 2, 3, 4}, lbl, ContentSize -> {80, s}], {s, {10, 20, 40}}]

Editable  (2)

By default, editing of labels and expressions is allowed:

Wolfram Language code: Labeled[123456, "number"]

Disallow editing:

Wolfram Language code: Labeled[123456, "number", Editable -> False]

Frame  (1)

Frame only the expression, not the label:

Wolfram Language code: Labeled[{1, 2, 3, 4}, lbl, Frame -> True]

FrameMargins  (2)

Add space within the frame:

Wolfram Language code: Table[Labeled[{1, 2, 3, 4}, lbl, Frame -> True, FrameMargins -> m], {m, {0, 10, 20}}]

FrameMargins also increases the area to which Background applies:

Wolfram Language code: Table[Labeled[{1, 2, 3, 4}, lbl, Frame -> True, Background -> StandardBlue, FrameMargins -> m], {m, {0, 10, 20}}]

FrameStyle  (1)

Change the color of the frame:

Wolfram Language code: Table[Labeled[{1, 2, 3, 4}, lbl, Frame -> True, FrameStyle -> c], {c, {Red, Green, Blue}}]

ImageMargins  (1)

Add margins around the labeled expression:

Wolfram Language code: Table[Framed@ Labeled[{1, 2, 3, 4}, lbl, ImageMargins -> m], {m, {0, 10, 20}}]

Specify different margins for each side:

Wolfram Language code: Framed@Labeled[{1, 2, 3, 4}, lbl, ImageMargins -> {{5, 10}, {20, 30}}]

LabelStyle  (2)

Style the label:

Wolfram Language code: Labeled[{1, 2, 3, 4}, "label", LabelStyle -> Red]

Use Directive to specify compound styles:

Wolfram Language code: Labeled[{1, 2, 3, 4}, "label", LabelStyle -> Directive[Bold, FontFamily -> "Helvetica"]]

RotateLabel  (1)

Rotate vertical labels:

Wolfram Language code: Labeled[Grid[Partition[Range[9], 3]], "label", Left, RotateLabel -> True]

RoundingRadius  (1)

Round the corners of the frame:

Wolfram Language code: Table[Labeled[{1, 2, 3, 4}, lbl, Frame -> True, RoundingRadius -> r], {r, 0, 9, 3}]

Spacings  (3)

Add horizontal spacing between the expression and the label:

Wolfram Language code: Column@Table[Framed@Labeled[{1, 2, 3, 4}, "label", Right, Spacings -> s], {s, {0, 5, 10}}]

Specify vertical spacing:

Wolfram Language code: Table[Framed@Labeled[{1, 2, 3, 4}, "label", Spacings -> {Automatic, s}], {s, {0, 5, 10}}]

Use both vertical and horizontal spacing:

Wolfram Language code: Labeled[Framed[{a, b, c, d}], {x, y}, {Right, Bottom}, Spacings -> {7, 3}]

Applications  (2)

Label images with checkboxes, potentially for later processing:

Wolfram Language code: Table[Labeled[ArrayPlot[CellularAutomaton[i, {{1}, 0}, {30, All}], ImageSize -> Small], Checkbox[]], {i, 20, 23}]

Create an active label:

Wolfram Language code: DynamicModule[{c}, Labeled[Graphics[{Dynamic[c], Disk[]}, ImageSize -> Tiny], Toggler[Dynamic[c], Reverse /@ ColorData["HTML", "ColorRules"], ImageSize -> Automatic]]]

Neat Examples  (2)

Wolfram Language code: NestList[Labeled[#, {a, b}, {Top, Left}]&, x, 5]
Wolfram Language code: NestList[Labeled[#, {a, b, c}, {Top, Left, Right}]&, x, 5]
Wolfram Language code: NestList[Labeled[#, {#, #, #, #}, All]&, x, 2]
Wolfram Language code: NestList[Labeled[#, {#, #}, All]&, x, 3]
Wolfram Language code: NestList[Labeled[#, {#, #}, All]&, Checkbox[], 3]
