Rotate[g,θ]

represents 2D graphics primitives or any other objects g rotated counterclockwise by θ radians about the center of their bounding box.

Rotate[g,θ,{x,y}]

rotates about the point {x,y}.

Rotate[g,{u,v}]

rotates around the origin, transforming the 2D or 3D vector u to v.

Rotate[g,θ,w]

rotates 3D graphics primitives by θ radians around the 3D vector w anchored at the origin.

Rotate[g,θ,w,p]

rotates around the 3D vector w anchored at p.

Rotate[g,θ,{u,v}]

rotates by angle θ in the plane spanned by 3D vectors u and v.

Details and Options
Details and Options Details and Options
Examples
Basic Examples
Scope
Applications
Properties & Relations
Possible Issues
Neat Examples
See Also
Related Guides
Related Workflows
Related Links
History
Cite this Page

Rotate

Rotate[g,θ]

represents 2D graphics primitives or any other objects g rotated counterclockwise by θ radians about the center of their bounding box.

Rotate[g,θ,{x,y}]

rotates about the point {x,y}.

Rotate[g,{u,v}]

rotates around the origin, transforming the 2D or 3D vector u to v.

Rotate[g,θ,w]

rotates 3D graphics primitives by θ radians around the 3D vector w anchored at the origin.

Rotate[g,θ,w,p]

rotates around the 3D vector w anchored at p.

Rotate[g,θ,{u,v}]

rotates by angle θ in the plane spanned by 3D vectors u and v.

Details and Options

  • θ Degree or θ° specifies an angle in degrees.
  • If Rotate appears outside a graphic, the object g in Rotate[g,θ] etc. can be any expression.
  • You can specify special points such as {Left,Bottom} within the bounding box for g.
  • The x position can be specified as Left, Center, or Right; the y position as Bottom, Center, or Top.
  • If Rotate appears within a graphic, the coordinates {x,y} are taken to be in the coordinate system of the graphic.
  • If Rotate appears outside a graphic, the coordinates {x,y} are taken to run from to across the bounding box of the object being rotated.
  • Rotate[g,θ] is equivalent to Rotate[g,θ,{Center,Center}].
  • For objects specified with scaled coordinates Scaled[{x,y}], Rotate effectively applies its transformation to the corresponding ordinary coordinates.
  • If Rotate appears inside a graphic, Normal[expr] if possible replaces all Rotate[gi,…] constructs by versions of the gi in which the coordinates have explicitly been transformed.

Examples

open all close all

Basic Examples  (3)

Rotate a square by 30°:

Wolfram Language code: Graphics[Rotate[Rectangle[], 30Degree]]

Rotate a cuboid by 30° around the axis:

Wolfram Language code: Graphics3D[Rotate[Cuboid[], 30Degree, {0, 0, 1}]]

Rotate text by 45°:

Wolfram Language code: Rotate[Sqrt[b^2 - 4 a c], 45 Degree]

Scope  (8)

Transformation applied to a 2D shape:

Wolfram Language code: gr = {Rectangle[], AbsolutePointSize[10], Opacity[1], {Magenta, Point[{0, 0}]}, {Green, Point[{1, 1}]}};
Wolfram Language code: Graphics[{{Opacity[.35], Blue, gr}, Rotate[{Opacity[.85], Red, gr}, Pi / 6]}]

Transformation applied to a 3D shape:

Wolfram Language code: gr = {Cuboid[], AbsolutePointSize[10], Opacity[1], {Magenta, Point[{0, 0, 0}]}, {Green, Point[{1, 1, 1}]}};
Wolfram Language code: Graphics3D[{{Opacity[.35], Blue, gr}, Rotate[{Opacity[.85], Red, gr}, Pi / 6, {0, 0, 1}, {.5, .5, .5}]}, Boxed -> False]

Rotation around the vector anchored at the point :

Wolfram Language code: Graphics3D[Rotate[Cuboid[], Pi, {0, 0, 1}, {1, 1, 1}], Axes -> True, PlotRange -> {{0, 2}, {0, 2}, {0, 2}}]

Rotation mapping vector to vector :

Wolfram Language code: Graphics3D[Rotate[Cuboid[], {{1, 1, 1}, {0, 0, 1}}]]

Rotation in the plane spanned by vectors and :

Wolfram Language code: Graphics3D[Rotate[Cylinder[], Pi / 2, {{1, 1, 0}, {0, 0, 1}}]]

Rotate text:

Wolfram Language code: Graphics[Rotate[Style[Text["Mathematica"], 24], -Pi / 4]]

Rotate objects with scaled coordinates:

Wolfram Language code: Graphics[Rotate[Circle[Scaled[{1, 0}]], Pi, {0, 0}], Axes -> True]

Keep the lower-right corner of the rectangle fixed:

Wolfram Language code: Graphics[{Circle[], Rotate[Rectangle[], Pi / 4, {Right, Bottom}]}, Axes -> True]

Applications  (2)

Grid with vertical text:

Wolfram Language code: Grid[{ {Rotate["Primary", 90°, {1, 1}], "Red"}, {, "Blue"}, {, "Yellow"}, {Rotate["Secondary", 90°, {1, 1}], "Purple"}, {, "Green"}, {, "Orange"} }, Frame -> All, Alignment -> Left]

Diamond grid:

Wolfram Language code: Rotate[Grid[Table[Rotate[{i, j}, 45°], {i, 0, 2}, {j, 0, 2}], Frame -> All], -45°]

Properties & Relations  (1)

When possible, Normal will transform the coordinates explicitly:

Wolfram Language code: Normal@Rotate[Cylinder[], Pi / 4, {1, 0, 0}]

Possible Issues  (4)

By default, Rotate uses the center of the bounding box as the center of rotation:

Wolfram Language code: Graphics[{Opacity[0.5], Rotate[Rectangle[], Pi / 3]}, Axes -> True]

Explicitly specify a center of rotation:

Wolfram Language code: Graphics[{Opacity[0.5], Rotate[Rectangle[], Pi / 3, {0, 0}]}, Axes -> True]

Transforming an object may move it out of view:

Wolfram Language code: Graphics[Rotate[Circle[], Pi / 2, Right], Axes -> True]

Adjust the PlotRange to display the transformed object:

Wolfram Language code: Graphics[Rotate[Circle[], Pi / 2, Right], Axes -> True, PlotRange -> 2]

The center of the baseline of rotated text aligns with the baseline of the surrounding text:

Wolfram Language code: Row[{"abc", Rotate["ghi", 90°], "xyz"}, " "]

For a different alignment, specify an explicit center of rotation:

Wolfram Language code: Row[{"abc", Rotate["ghi", 90°, {Left, Baseline}], "xyz"}, " "]

Since text bounding boxes are always rectilinear, successive rotations can introduce extra space:

Wolfram Language code: NestList[Style[Rotate[#, 30 Degree], Background -> RGBColor[1, 0, 0, 0.2]]&, "R", 8]

Neat Examples  (2)

Rotations of a regular polygon:

Wolfram Language code: Graphics[Outer[Rotate[Rotate[Line[{{1, 0}, {Sqrt[3], 1} / 2}], #, {0, 0}], #2, {1, 0}]&, Pi / 6Range[12], Pi / 6Range[12]]]

Nested, rotated square roots:

Wolfram Language code: Nest[Rotate[Sqrt[#], 90°]&, 2, 8]
