CepstrogramArray[data]

computes an array of cepstra on data.

CepstrogramArray[data,n]

uses partitions of length n.

CepstrogramArray[data,n,d]

uses partitions with offset d.

CepstrogramArray[data,n,d,wfun]

applies a smoothing window wfun to each partition.

CepstrogramArray[data,n,d,wfun,m]

pads partitions with zeros to length m prior to the computation of the transform.

Details and Options
Details and Options Details and Options
Examples
Basic Examples
Scope
See Also
Related Guides
History
Cite this Page

CepstrogramArray

CepstrogramArray[data]

computes an array of cepstra on data.

CepstrogramArray[data,n]

uses partitions of length n.

CepstrogramArray[data,n,d]

uses partitions with offset d.

CepstrogramArray[data,n,d,wfun]

applies a smoothing window wfun to each partition.

CepstrogramArray[data,n,d,wfun,m]

pads partitions with zeros to length m prior to the computation of the transform.

Details and Options

  • Cepstrogram is an array of power cepstra computed on partitions of data.
  • Power cepstrum for each partition is computed as the squared inverse Fourier transform of the log-power spectrum.
  • Use Cepstrogram to directly plot the array of cepstra.
  • The partition length n and offset d can be expressed as an integer number (interpreted as number of samples) or as time or sample quantities.
  • CepstrogramArray[list] uses partitions of length and offset , where m is Length[list].
  • In CepstrogramArray[list,n,d,wfun], the smoothing window wfun can be specified using a window function that will be sampled between and or a list of length n. The default window is DirichletWindow, which effectively does no smoothing.
  • The data can be any of the following:
  • list1D numerical array
    audioan Audio or Sound object
    videoa Video object
  • For multichannel audio objects, the cepstrogram is computed over the sum of all channels.
  • The following options can be given:
  • FourierParameters{1,-1}Fourier parameters
    PaddingAutomaticpadding scheme
    PaddingSize{0,0}amount of padding

Examples

open all close all

Basic Examples  (1)

Cepstrogram array of an audio signal:

Wolfram Language code: a = Import["ExampleData/rule30.wav"];
Wolfram Language code: (ca = CepstrogramArray[a, 2000])//Short

Plot the cepstrogram:

Wolfram Language code: MatrixPlot[Transpose[ca[[All, 1 ;; 400]]], DataReversed -> True, AspectRatio -> 1]

Scope  (7)

Numeric input:

Wolfram Language code: a = RandomReal[1, 6];
Wolfram Language code: CepstrogramArray[a]
Wolfram Language code: CepstrogramArray[a]

Specify the window size:

Wolfram Language code: a = RandomReal[1, 6];
Wolfram Language code: CepstrogramArray[a, Quantity[4, "Samples"]]

Specify the window size and offset:

Wolfram Language code: a = RandomReal[1, 6];
Wolfram Language code: CepstrogramArray[a, 4, 1]

Specify a smoothing window:

Wolfram Language code: a = RandomReal[1, 6];
Wolfram Language code: CepstrogramArray[a, 4, 1, HannWindow]

Single-channel audio:

Wolfram Language code: a = Import["ExampleData/rule30.wav"];
Wolfram Language code: MatrixPlot[Transpose@CepstrogramArray[a, Quantity[0.04, "Seconds"], Quantity[10, "Milliseconds"], HannWindow][[All, 10 ;; 400]], AspectRatio -> 1 / 2, ImageSize -> Medium]

Multichannel audio:

Wolfram Language code: a = ExampleData[{"Audio", "Bee"}];
Wolfram Language code: MatrixPlot[Transpose@#, AspectRatio -> 1 / 2, ImageSize -> Medium]&@CepstrogramArray[a, Quantity[0.04, "Seconds"], Quantity[10, "Milliseconds"], HannWindow][[All, 5 ;; 500]]

Process the audio track of a video:

Wolfram Language code: MatrixPlot[Transpose@#, AspectRatio -> 1 / 2, ImageSize -> Medium]&@CepstrogramArray[\!\(\*VideoBox["![Video Player: ExampleData/fish.mp4](video://content-2sfji)"]\), Quantity[0.04, "Seconds"], Quantity[10, "Milliseconds"], HannWindow][[All, 5 ;; 500]]
