EstimatedBackground

EstimatedBackground[data]

estimates the background of data.

EstimatedBackground[data,σ]

tries to preserve peaks up to scale σ.

Details and Options

  • EstimatedBackground estimates the background or baseline while trying to preserve features of the input list.
  • Input data can be of one of the following forms:
  • {y1,y2,…}a list of values
    TimeSeries[…]time series object
    EventSeries[…]event series object
  • The following options can be given:
  • MethodAutomaticmethod to use
    Padding "Reversed"padding scheme to use
  • EstimatedBackground accepts a Method option. Possible settings are:
  • "MovingAverage"moving-average background estimation
    {"SNIP",r}statistics-sensitive nonlinear iterative peak clipping

Examples

open all close all

Basic Examples  (2)

Estimate the baseline of a list:

Wolfram Language code: data = {2, 1, 3, 5, 6, 6, 4, 3, 2, 4, 7, 3, 2, 4, 2, 2, 1};
Wolfram Language code: base = EstimatedBackground[data]
Wolfram Language code: ListLinePlot[{data, base}]

Remove the baseline from original data and visually compare the lists:

Wolfram Language code: ListLinePlot[{data, data - base}]

Estimate background of a sinusoidal signal:

Wolfram Language code: data = Table[Sin[i] + .1Sin[10 i], {i, 0, 2Pi, 0.01}]; ListLinePlot[{data, EstimatedBackground[data]}]

Scope  (4)

The background is scale dependent; by default, an automatically computed scale is used:

Wolfram Language code: data = FinancialData["GE", {"Jun 2010", "Jan 2011"}, "Value"];
Wolfram Language code: ListLinePlot[{data, EstimatedBackground[data]}]

At scale the background is a close estimation of the input data:

Wolfram Language code: ListLinePlot[{data, EstimatedBackground[data, 0]}]

Specify a different scale:

Wolfram Language code: ListLinePlot[{data, EstimatedBackground[data, 10]}]

Comparison of different scales:

Wolfram Language code: list = Range[5, 20, 5]; ListLinePlot[Prepend[EstimatedBackground[data, #]& /@ list, data], PlotLegends -> Prepend["σ = " <> ToString[#]& /@ list, "Original"], Filling -> Table[i -> {i + 1}, {i, 1, Length[list]}]]

Estimate baseline of a Quantity object:

Wolfram Language code: data = WeatherData["New York", "Temperature", {"2010", "2012", "Month"}, "Value"]
Wolfram Language code: EstimatedBackground[data]

Estimate baseline of a regularly sampled TimeSeries object:

Wolfram Language code: ts = TimeSeries[FinancialData["MSFT", "Jan. 1, 2008"], TemporalRegularity -> True]
Wolfram Language code: base = EstimatedBackground[ts]
Wolfram Language code: DateListPlot[{ts, EstimatedBackground[ts]}]

Estimated baseline of an irregularly sampled TimeSeries object:

Wolfram Language code: v = {2, 1, 6, 5, 7, 4}; t = {1, 2, 5, 10, 12, 15}; ts = TimeSeries[v, {t}]
Wolfram Language code: RegularlySampledQ[ts]
Wolfram Language code: EstimatedBackground[ts]
Wolfram Language code: DateListPlot[{ts, %}]

Options  (1)

Padding  (1)

The default padding is "Reversed":

Wolfram Language code: data = Sin[Range[0, 1, 1 / 50]] + RandomReal[.5, 51]; ListLinePlot[{data, EstimatedBackground[data]}]

Specify a different padding:

Wolfram Language code: ListLinePlot[{data, EstimatedBackground[data, Padding -> "Periodic"]}]

Applications  (2)

Estimate and subtract the background from the recent sunspot activity:

Wolfram Language code: data = WolframAlpha["sunspot", {{"SunspotsPartialTimeSeries:SpaceWeatherData", 1}, "TimeSeriesData"}][[All, 2]];
Wolfram Language code: bg = EstimatedBackground[data];
Wolfram Language code: ListLinePlot[{data, bg}, AspectRatio -> 1 / 3]

Plot data after background subtraction:

Wolfram Language code: ListLinePlot[data - bg, AspectRatio -> 1 / 3]

Hourly temperature for Chicago in December:

Wolfram Language code: temp = WeatherData["Chicago", "Temperature", {{2014, 12, 1, 0, 0}, {2014, 12, 31, 23, 59}, All}]
Wolfram Language code: DateListPlot[temp]

The plot indicates that data contains missing values. Specify MissingDataMethod and estimate the background:

Wolfram Language code: res = EstimatedBackground[data = TimeSeries[temp, MissingDataMethod -> {"Interpolation", InterpolationOrder -> 1}]]
Wolfram Language code: DateListPlot[{data, res}]

Create the time series of the original data minus the background:

Wolfram Language code: diff = TimeSeriesThread[Subtract[#[[1]], #[[2]]]&, {data, res}]
Wolfram Language code: DateListPlot[diff]

Fit a weakly stationary time series model:

Wolfram Language code: model = TimeSeriesModelFit[TimeSeriesResample[diff]]
Wolfram Language code: model["Process"]

Properties & Relations  (1)

The "MovingAverage" computes the MovingAverage of the padded input:

Wolfram Language code: data = Table[Sin[i] + .1Sin[10 i], {i, 0, 2Pi, 0.01}]; r = 10;
Wolfram Language code: bg1 = EstimatedBackground[data, r, Method -> "MovingAverage"]; bg2 = MovingAverage[ArrayPad[data, r, "Reversed"], 2r + 1];
Wolfram Language code: bg1 == bg2
