RegionBoundary

RegionBoundary[reg]

represents the boundary of the region reg.

Details

Examples

open all close all

Basic Examples  (2)

The boundary of a disk:

Wolfram Language code: Subscript[ℛ, 1] = Disk[]; Subscript[ℛ, 2] = RegionBoundary[Subscript[ℛ, 1]]
Wolfram Language code: {Region[Subscript[ℛ, 1]], Region[Subscript[ℛ, 2]]}

Compute the circumference of the disk:

Wolfram Language code: ArcLength[Subscript[ℛ, 2]]

The boundary of a MeshRegion:

Wolfram Language code: mr1 = DelaunayMesh[RandomReal[1, {15, 2}]]; mr2 = RegionBoundary[mr1];
Wolfram Language code: Show[mr1, HighlightMesh[mr2, 1]]

Compute the arc length of the perimeter:

Wolfram Language code: ArcLength[mr2]

Scope  (14)

Special Regions  (5)

The boundary of a Line in 1D is a set of points:

Wolfram Language code: ℛ = RegionBoundary[Line[{{{0}, {1}}, {{2}, {3}}}]];

Count the number of points:

Wolfram Language code: RegionMeasure[ℛ]

Visualize it:

Wolfram Language code: Region[ℛ]

The boundary of a Polygon in 2D is a Line object:

Wolfram Language code: ℛ = RegionBoundary[Polygon[{{0, 0}, {3, -1}, {2, 0}, {3, 1}}]]

Compute the length of the perimeter of the polygon:

Wolfram Language code: ArcLength[ℛ]

Visualize it:

Wolfram Language code: Region[ℛ]

The boundary of a Disk is a Circle:

Wolfram Language code: ℛ = RegionBoundary[Disk[{0, 0}, r]]

Compute the circumference:

Wolfram Language code: ArcLength[ℛ]

Substitute in a value for to visualize it:

Wolfram Language code: Region[ℛ /. {r -> 1}]

The boundary of a Ball is a Sphere:

Wolfram Language code: ℛ = RegionBoundary[Ball[]]

Compute the surface area:

Wolfram Language code: Area[ℛ]

Visualize it:

Wolfram Language code: Region[ℛ]

The boundary of a unit ball in 7D:

Wolfram Language code: ℛ = RegionBoundary[Ball[7]]

This cannot be visualized, but can still be computed with:

Wolfram Language code: RegionMeasure[ℛ]

Mesh Regions  (6)

The boundary of a BoundaryMeshRegion in 1D:

Wolfram Language code: mr = BoundaryMeshRegion[{{0}, {1}, {2}, {3}}, Point[{1, 2, 3, 4}]]; ℛ = RegionBoundary[mr]

Visualize it overlaid on the original region:

Wolfram Language code: Show[mr, HighlightMesh[ℛ, 0]]

The boundary of a MeshRegion in 1D:

Wolfram Language code: mr = MeshRegion[{{0}, {1}, {2}}, {Point[{1}], Line[{2, 3}]}]; ℛ = RegionBoundary[mr]

Visualize it overlaid on the original region:

Wolfram Language code: Show[mr, HighlightMesh[ℛ, {Style[0, Red]}]]

The boundary of a BoundaryMeshRegion in 2D:

Wolfram Language code: mr = ConvexHullMesh[RandomReal[1, {15, 2}]]; ℛ = RegionBoundary[mr];

Compute the length of the perimeter:

Wolfram Language code: ArcLength[ℛ]

Visualize it overlaid on the original region:

Wolfram Language code: Show[mr, HighlightMesh[ℛ, 1]]

The boundary of a MeshRegion in 2D:

Wolfram Language code: mr = MeshRegion[{{0, 0}, {1, 0}, {2, 0}, {3, -1 / 2}, {3, 1 / 2}}, {Point[{1}], Line[{2, 3}], Polygon[{3, 4, 5}]}]; ℛ = RegionBoundary[mr]

Compute the length of the boundary:

Wolfram Language code: ArcLength[ℛ]

The boundary of a BoundaryMeshRegion in 3D:

Wolfram Language code: mr = ConvexHullMesh[RandomReal[1, {20, 3}]]; ℛ = RegionBoundary[mr]

Compute the surface area:

Wolfram Language code: Area[ℛ]

The boundary of a MeshRegion in 3D:

Wolfram Language code: mr = MeshRegion[{{0, 0, 0}, {1, 0, 0}, {2, 0, 0}, {3, 0, -1 / 2}, {3, 0, 1 / 2}, {4, -1 / 2, 0}, {4, 1 / 2, 0}}, {Point[1], Line[{2, 3}], Triangle[{3, 4, 5}], Tetrahedron[{4, 6, 5, 7}]}]; ℛ = RegionBoundary[mr]

Compute the surface area:

Wolfram Language code: Area[ℛ]

Geographic Regions  (2)

The boundary of a polygon with GeoPosition:

Wolfram Language code: Subscript[ℛ, 1] = Polygon[GeoPosition[{{{40.083441, -88.235716}, {40.083607, -88.257488}, {40.082603, -88.257149}, {40.076136999999996, -88.25740499999999}, {40.076178, -88.270888}, {40.076516, -88.271558}, {40.083686, -88.271512}, {40.083659999999995, -88.267046}, ... 33323}, {40.098112, -88.228687}, {40.095216, -88.228627}, {40.095179, -88.238547}, {40.094480999999995, -88.238546}, {40.094508999999995, -88.23267}, {40.094106, -88.232556}, {40.090666999999996, -88.232477}, {40.090741, -88.235745}}}]]; Subscript[ℛ, 2] = RegionBoundary[Subscript[ℛ, 1]]
Wolfram Language code: {Region[Subscript[ℛ, 1]], Region[Subscript[ℛ, 2]]}

The boundary of a polygon with GeoGridPosition:

Wolfram Language code: Subscript[ℛ, 1] = Polygon[GeoGridPosition[{{{-0.9950503945490105, 1.2366760550756015}, {-0.9952074890903578, 1.2369207053693891}, {-0.9952196732768064, 1.2369073327446167}, {-0.9953160063787643, 1.236848436956935}, {-0.9954141759436825, 1.2369993898475449}, {-0. ... 197645333103}, {-0.9949098578570917, 1.2368130881428654}, {-0.9948663952535768, 1.2367477711687371}, {-0.9948714472169538, 1.2367426500757825}, {-0.9949211061652593, 1.2367089232486177}, {-0.9949439717990124, 1.236746107097628}}}, "Bonne"]]; Subscript[ℛ, 2] = RegionBoundary[Subscript[ℛ, 1]];
Wolfram Language code: {Region[Subscript[ℛ, 1]], Region[Subscript[ℛ, 2]]}

Subdivision Regions  (1)

The boundary of a SubdivisionRegion:

Wolfram Language code: ℛ = RegionBoundary[SubdivisionRegion[Cube[]]]

Compute the surface area:

Wolfram Language code: Area[ℛ]

Properties & Relations  (5)

The dimension of RegionBoundary for a full-dimensional region is one dimension less:

Wolfram Language code: RegionDimension[Ball[]]
Wolfram Language code: RegionDimension[RegionBoundary[Ball[]]]

The dimension of RegionBoundary for a lower-dimensional region is the same:

Wolfram Language code: RegionDimension[Sphere[]]
Wolfram Language code: RegionDimension[RegionBoundary[Sphere[]]]

RegionBoundary of a lower-dimensional region is the region itself:

Wolfram Language code: RegionBoundary[Circle[]]
Wolfram Language code: RegionBoundary[Sphere[]]

The boundary of a boundary is the boundary itself:

Wolfram Language code: RegionBoundary[RegionBoundary[Ball[]]]
Wolfram Language code: RegionBoundary[Ball[]]

The boundary consists of points for which SignedRegionDistance is zero:

Wolfram Language code: ℛ = Disk[];
Wolfram Language code: Reduce[{x, y}∈RegionBoundary[ℛ]⧦SignedRegionDistance[ℛ, {x, y}] == 0, {x, y}, Reals]
