JacobiSN

JacobiSN[u,m]

gives the Jacobi elliptic function .

Details

Mathematical function, suitable for both symbolic and numerical manipulation.
, where and is the amplitude.
is a doubly periodic function in with periods and , where is the elliptic integral EllipticK.
JacobiSN is a meromorphic function in both arguments.
For certain special arguments, JacobiSN automatically evaluates to exact values.
JacobiSN can be evaluated to arbitrary numerical precision.
JacobiSN automatically threads over lists.

Examples

open all close all

Basic Examples (3)

Evaluate numerically:

Wolfram Language code: JacobiSN[2.5, 0.5]

Plot along the real axis:

Wolfram Language code: Plot[JacobiSN[x, 1 / 3], {x, -10, 10}]

Series expansions about the origin:

Wolfram Language code: Series[JacobiSN[z, m], {z, 0, 7}]

Wolfram Language code: Series[JacobiSN[z, m], {m, 0, 1}]

Scope (34)

Numerical Evaluation (5)

Evaluate to high precision:

Wolfram Language code: N[JacobiSN[2, 1 / 3], 50]

The precision of the output tracks the precision of the input:

Wolfram Language code: JacobiSN[2, 0.333333333333333333333333333333333333333333]

Evaluate for complex arguments:

Wolfram Language code: JacobiSN[2.5 + I, 1 - I]

Evaluate JacobiSN efficiently at high precision:

Wolfram Language code: JacobiSN[2, 0.3`500]//Timing

Wolfram Language code: JacobiSN[2, 0.3`10000];//Timing

Compute average-case statistical intervals using Around:

Wolfram Language code: JacobiSN[2, Around[1 / 2, 0.01]]

Compute the elementwise values of an array:

Wolfram Language code: JacobiSN[-(I π/3), {{1, 0}, {0, 1}}]

Or compute the matrix JacobiSN function using MatrixFunction:

Wolfram Language code: MatrixFunction[JacobiSN[-(I π/3), #]&, {{1, 0}, {0, 1}}]

Specific Values (3)

Simple exact values are generated automatically:

Wolfram Language code: {JacobiSN[z, 0], JacobiSN[z, 1]}

Wolfram Language code: {JacobiSN[0, m], JacobiSN[EllipticK[m] / 2, m], JacobiSN[EllipticK[m], m]}

Some poles of JacobiSN:

Wolfram Language code:

{JacobiSN[-3I EllipticK[1 - m], m], JacobiSN[-I EllipticK[1 - m], m], JacobiSN[I EllipticK[1 - m], m], JacobiSN[3I EllipticK[1 - m], m]}

Find a zero of :

Wolfram Language code: xzero = N@Solve[JacobiSN[x, 1 / 3] == 0 && 2 < x < 5, x][[1, 1, 2]]//Quiet

Wolfram Language code: Plot[JacobiSN[x, 1 / 3], {x, -π, 2π}, Epilog -> Style[Point[{xzero, JacobiSN[xzero, 1 / 3]}], PointSize[Large], Red]]

Visualization (3)

Plot the JacobiSN functions for various values of parameter:

Wolfram Language code: Plot[{JacobiSN[x, 0], JacobiSN[x, 0.8], JacobiSN[x, 1], JacobiSN[x, 4]}, {x, -2π, 2π}]

Plot JacobiSN as a function of its parameter :

Wolfram Language code: Plot[{JacobiSN[1, m], JacobiSN[2, m], JacobiSN[3, m]}, {m, -7, 10}]

Plot the real part of :

Wolfram Language code: ComplexContourPlot[Re[JacobiSN[z, 1 / 2]], {z, -4 - 4I, 4 + 4I}, IconizedObject[«PlotOptions»]]

Plot the imaginary part of :

Wolfram Language code: ComplexContourPlot[Im[JacobiSN[z, 1 / 2]], {z, -4 - 4I, 4 + 4I}, IconizedObject[«PlotOptions»]]

Function Properties (8)

JacobiSN is -periodic along the real axis:

Wolfram Language code: JacobiSN[x, m] == JacobiSN[x + 4EllipticK[m], m]

JacobiSN is -periodic along the imaginary axis:

Wolfram Language code: JacobiSN[x, m] == JacobiSN[x + 2I EllipticK[1 - m], m]

JacobiSN is an odd function in its first argument:

Wolfram Language code: JacobiSN[-x, m] == -JacobiSN[x, m]

JacobiSN is an analytic function:

Wolfram Language code: FunctionAnalytic[JacobiSN[x, m], {x, m}]

It has no singularities or discontinuities:

Wolfram Language code: FunctionSingularities[JacobiSN[x, m], {x, m}]

Wolfram Language code: FunctionDiscontinuities[JacobiSN[x, 3], {x, m}]

is neither nondecreasing nor nonincreasing:

Wolfram Language code: FunctionMonotonicity[JacobiSN[x, 1 / 3], x]

is not injective for any fixed :

Wolfram Language code: FunctionInjective[JacobiSN[x, m], x, Assumptions -> m > 1]

Wolfram Language code: FunctionInjective[JacobiSN[x, m], x, Assumptions -> m < 1]

Wolfram Language code: Plot[{JacobiSN[x, 1 / 3], .5}, {x, -10, 10}]

It is injective for :

Wolfram Language code: FunctionInjective[JacobiSN[x, 1], x]

Wolfram Language code: Plot[{JacobiSN[x, 1], .5}, {x, -10, 10}]

is not surjective for any fixed :

Wolfram Language code: FunctionSurjective[JacobiSN[x, m], x, Assumptions -> m∈Reals]

Wolfram Language code: Plot[{JacobiSN[x, 3], 1.5}, {x, -5, 5}]

JacobiSN is neither non-negative nor non-positive:

Wolfram Language code: FunctionSign[JacobiSN[x, m], {x, m}]

JacobiSN is neither convex nor concave:

Wolfram Language code: FunctionConvexity[JacobiSN[x, m], {x, m}]

Differentiation (3)

First derivative:

Wolfram Language code: D[JacobiSN[x, m], x]

Higher derivatives:

Wolfram Language code: derivs = Table[D[JacobiSN[x, m], {x, n}], {n, 1, 4}]//FullSimplify

Plot higher derivatives for :

Wolfram Language code:

Plot[Evaluate[derivs /. m -> 1 / 3], {x, -6, 6}, PlotLegends -> {"First Derivative", "Second Derivative", "Third Derivative", "Fourth Derivative"}]

Derivative with respect to :

Wolfram Language code: D[JacobiSN[x, m], m]

Integration (3)

Indefinite integral of JacobiSN:

Wolfram Language code: Integrate[JacobiSN[z, m], z]

Definite integral of an odd integrand over the interval centered at the origin is :

Wolfram Language code: Integrate[JacobiSN[z, 1 / 3], {z, -1, 1}]

More integrals:

Wolfram Language code: Integrate[JacobiSN[z, m]JacobiDN[z, m], z]

Wolfram Language code: Integrate[(JacobiSN[t, m]/JacobiDN[t, m]), t]

Wolfram Language code: Integrate[JacobiSN[z, m] ^ 3, z]

Series Expansions (3)

Taylor expansion for :

Wolfram Language code: Series[JacobiSN[x, 1 / 3], {x, 0, 7}]

Plot the first three approximations for around :

Wolfram Language code:

terms = Normal@Table[Series[JacobiSN[x, 1 / 3], {x, 0, n}], {n, 2, 7, 2}];
Plot[{JacobiSN[x, 1 / 3], terms}, {x, -2, 2}]

Taylor expansion for :

Wolfram Language code: Series[JacobiSN[2, m], {m, 0, 2}]

Plot the first three approximations for around :

Wolfram Language code:

terms = Normal@Table[Series[JacobiSN[2, m], {m, 0, n}], {n, 1, 3}];
Plot[{JacobiSN[2, m], terms}, {m, -2, 2}]

JacobiSN can be applied to power series:

Wolfram Language code: JacobiSN[ArcSin[x] + O[x]^7, m]

Function Identities and Simplifications (3)

Parity transformation and periodicity relations are automatically applied:

Wolfram Language code: JacobiSN[-u, m]

Wolfram Language code: JacobiSN[u + 4EllipticK[m] + 2 I EllipticK[1 - m], m]

Automatic argument simplifications:

Wolfram Language code: JacobiSN[z + EllipticK[m], m]

Wolfram Language code: JacobiSN[z + I EllipticK[1 - m], m]

Identity involving JacobiCN:

Wolfram Language code: JacobiCN[z, m] ^ 2 + JacobiSN[z, m] ^ 2//FullSimplify

Function Representations (3)

Representation in terms of Sin of JacobiAmplitude:

Wolfram Language code: Sin[JacobiAmplitude[z, m]]

Relation to other Jacobi elliptic functions:

Wolfram Language code: (JacobiCD[z, m]^2 - 1/m JacobiCD[z, m]^2 - 1)//FullSimplify

Wolfram Language code: JacobiSN[z, m]^2 == (1/1 + JacobiCS[z, m]^2)//FullSimplify

TraditionalForm formatting:

Wolfram Language code: JacobiSN[z, m]//TraditionalForm

Applications (11)

Map a rectangle conformally onto the upper half-plane:

Wolfram Language code:

Module[{n = 24, m = 0.3`20, p}, p = Flatten[Table[(2j / n - 1)EllipticK[m] + k / n I EllipticK[1 - m], {j, 0, n}, {k, 0, n}]];Row[{Graphics[Point[ReIm /@ p], Frame -> True, ImageSize -> Small], Graphics[Point[ReIm /@ Select[JacobiSN[p, m], NumberQ]], Frame -> True, ImageSize -> Small]}, Spacer[20]]]

Conformally map a square image onto a disk:

Wolfram Language code:

img = ExampleData[{"TestImage", "Mandrill"}];
With[{ω = N[3Beta[5 / 4, 5 / 4] / 2]}, ImageForwardTransformation[img, With[{z = ω(#[[1]] + I #[[2]])}, ReIm[JacobiSN[z, 1 / 2]JacobiDC[z, 1 / 2]]]&, Background -> 1., DataRange -> {{-1, 1}, {-1, 1}}]]

Solution of the pendulum equation:

Wolfram Language code: α[t_, ϕ_] = 2ArcSin[Sin[ϕ / 2]JacobiSN[t, Sin[ϕ / 2] ^ 2]]

Check the solution:

Wolfram Language code: D[α[t, 2], t, t] + Sin[α[t, 2]] /. t -> N[2, 100]

Plot solutions:

Wolfram Language code: Plot[{α[t, Pi / 3], α[t, Pi / 2], α[t, 99 / 100Pi]}, {t, 0, 10}]

Cnoidal solution of the Korteweg–De Vries equation:

Wolfram Language code:

f[x_, t_] = (1/m EllipticK[m])Sqrt[(a/m)](12a t EllipticE[m] + (4a (-2 + m) t + m (x - 6t β)) EllipticK[m]);
u[x_, t_] = -2a + (2a/m) + β - (2a EllipticE[m]/m EllipticK[m]) + 2a(1 - JacobiSN[f[x, t], m]^2);

A numerical check of the solution:

Wolfram Language code:

D[u[x, t], t] + 6u[x, t]D[u[x, t], x] + D[u[x, t], {x, 3}] /. {x -> Pi, t -> E, β -> 3, a -> 2, m -> 3 / 4}//N[#, {22, 50}]&

Plot the solution:

Wolfram Language code: Plot3D[Evaluate[u[x, t] /. {β -> 1, a -> 2, m -> 3 / 4}], {x, -2, 2}, {t, 0, 3}]

Closed form of iterates of the Katsura–Fukuda map:

Wolfram Language code: xn[n_, x0_, λ_] := JacobiSN[2^nInverseJacobiSN[-Sqrt[x0], λ], λ]^2

Compare the closed form with explicit iterations:

Wolfram Language code: Table[xn[n, 2 / 3, 3 / 7], {n, 0, 6}]//N

Wolfram Language code: With[{x0 = 2 / 3, λ = 3 / 7}, NestList[(4#(1 - #)(1 - λ#)/(1 - λ #^2)^2)&, x0, 6]]//N

Plot a few hundred iterates:

Wolfram Language code: ListPlot[Table[xn[n, 0.2`100, 2 / 3], {n, 0, 250}]]

Implicitly defined periodic maximal surface in Minkowski space:

Wolfram Language code: F = JacobiSN[(u[x, y]/Sqrt[1 - m]), m] - (Sin[x]/Cosh[y]);

Calculate partial derivatives:

Wolfram Language code:

partials  = Solve[{D[F, x] == 0, D[F, y] == 0, D[F, x, x] == 0, D[F, x, y] == 0, D[F, y, y] == 0}, {D[u[x, y], x], D[u[x, y], y], D[u[x, y], x, x], D[u[x, y], x, y], D[u[x, y], y, y]}]//Simplify;

Check numerically the equation for a maximal surface:

Wolfram Language code:

(1 - (Subscript[∂, y]u[x, y])^2)Subscript[∂, x, x]u[x, y] + 2Subscript[∂, x]u[x, y]Subscript[∂, y]u[x, y]Subscript[∂, x, y]u[x, y] + (1 - (Subscript[∂, x]u[x, y])^2)Subscript[∂, y, y]u[x, y] /. partials /. u[x, y] -> Sqrt[1 - m]InverseJacobiSN[Sech[y]Sin[x], m] /. {x -> 1, y -> 2, m -> 3``100}

Plot the maximal surface in Euclidean space:

Wolfram Language code:

Plot3D[Evaluate[Sqrt[1 - m]InverseJacobiSN[(Sin[x]/Cosh[y]), m] /. m -> 1 / 3], {x, -5, 5}, {y, -5, 5}, PlotRange -> All]

Solution of the Euler top equations for :

Wolfram Language code:

M1[t_] := Sqrt[A(M^2 - C ℰ/A - C)]JacobiCN[Sqrt[((B - C)(A ℰ - M^2)/A B C)]t, ((A - B)(M^2 - C ℰ)/(B - C)(A ℰ - M^2))]
M2[t_] := Sqrt[B(M^2 - C ℰ/B - C)]JacobiSN[Sqrt[((B - C)(A ℰ - M^2)/A B C)]t, ((A - B)(M^2 - C ℰ)/(B - C)(A ℰ - M^2))]
M3[t_] := Sqrt[C(A ℰ - M^2/A - C)]JacobiDN[Sqrt[((B - C)(A ℰ - M^2)/A B C)]t, ((A - B)(M^2 - C ℰ)/(B - C)(A ℰ - M^2))]

Check the solutions numerically:

Wolfram Language code:

{M1'[t] == ((1/B) - (1/C))M2[t]M3[t],
	M2'[t] == ((1/C) - (1/A))M3[t]M1[t],
	M3'[t] == ((1/A) - (1/B))M1[t]M2[t]} /.
	{M -> 1, ℰ -> 1, B -> 2, C -> 1 / 2, A -> 4, t -> 2.}

Plot the solutions:

Wolfram Language code:

Block[{A = 4, B = 2, C = 1 / 2, M = 1, ℰ = 1},
	Plot[Evaluate[{M1[t], M2[t], M3[t]}], {t, 0, 12}]]

Define a compacton solution of the nonlinear differential equation :

Wolfram Language code: u[ξ_] = JacobiSN[(ξ/2), -1]^2Boole[0 ≤ ξ ≤ 4EllipticK[-1]];

Verify the solution:

Wolfram Language code: u'[ξ]^2 == -u[ξ]^3 + u[ξ]//FullSimplify[#, 0 < ξ < 4EllipticK[-1]]&

Plot the compacton:

Wolfram Language code: Plot[u[ξ], {ξ, -1, 6}]

The JacobiSN function appears in one of the canonical forms of the Lamé differential equation:

Wolfram Language code: eqn = y''[x] + (LameEigenvalueA[ν, j, m] - ν(ν + 1)m JacobiSN[x, m]^2)y[x];

One of the fundamental solutions of this equation is the LameC function:

Wolfram Language code:

y[x_] := LameC[ν, j, x, m];
eqn == 0//Simplify

Solve the Painlevé-VIII differential equation:

Wolfram Language code: DSolve[w''[z] == w[z] + 2w[z] ^ 3, w[z], z]

Parametrization of a Mylar balloon (two flat sheets of plastic sewn together at their circumference and then inflated):

Wolfram Language code:

With[{kk = N[π CarlsonRK[2, 4]]},
	ParametricPlot3D[{JacobiCN[u, (1/2)]Cos[v], JacobiCN[u, (1/2)]Sin[v],
	(1/Sqrt[2])(u - (1/3)JacobiSN[u, (1/2)]^3CarlsonRD[JacobiCN[u, (1/2)]^2, JacobiDN[u, (1/2)]^2, 1])},
	{u, -kk, kk}, {v, -π, π}, Exclusions -> None, PlotRange -> All]]

Properties & Relations (4)

Compose with inverse functions:

Wolfram Language code: {JacobiSN[InverseJacobiSN[z, m], m], InverseJacobiSN[JacobiSN[z, m], m]}

Use PowerExpand to disregard multivaluedness of the inverse function:

Wolfram Language code: PowerExpand[%]

Evaluate as a result of applying Sin to JacobiAmplitude:

Wolfram Language code: Sin[JacobiAmplitude[z, m]]

Solve a transcendental equation:

Wolfram Language code: Solve[JacobiSN[x, m]^2 + 2JacobiSN[x, m] == a, x]

Numerically find a root of a transcendental equation:

Wolfram Language code: FindRoot[JacobiSN[2, m]^2 - 4JacobiSN[4, m]^2 == -2, {m, -2}]

Possible Issues (2)

Machine-precision input may be insufficient to give the correct answer:

Wolfram Language code: JacobiSN[10. ^ 16, 1 / 3]

Wolfram Language code: N[JacobiSN[10 ^ 16, 1 / 3], 20]

Currently only simple simplification rules are built in for Jacobi functions:

Wolfram Language code: JacobiSN[z, m] ^ 2 + JacobiCN[z, m] ^ 2 - 1//FullSimplify

Wolfram Language code: JacobiSN[u, m]JacobiND[u, m]JacobiDS[u, m]//FullSimplify

Neat Examples (1)

Visualize JacobiSN as a function of the parameter in the complex plane:

Wolfram Language code: ComplexPlot[JacobiSN[12, z], {z, -9 - 9I, 9 + 9I}, ColorFunction -> {Automatic, None}]

Top

More Learning

Tech Support

Wolfram Solutions

Wolfram Solutions For Education

Get Started

Grow Your Skills

Work with Us

Educational Programs for Adults

Educational Programs for Youth

Read

JacobiSN

Details

Examples

Basic Examples (3)

Scope (34)

Numerical Evaluation (5)

Specific Values (3)

Visualization (3)

Function Properties (8)

Differentiation (3)

Integration (3)

Series Expansions (3)

Function Identities and Simplifications (3)

Function Representations (3)

Applications (11)

Properties & Relations (4)

Possible Issues (2)

Neat Examples (1)

Text

CMS

APA

BibTeX

BibLaTeX

JacobiSN

Details

Examples

Basic Examples (3)

Scope (34)

Numerical Evaluation (5)

Specific Values (3)

Visualization (3)

Function Properties (8)

Differentiation (3)

Integration (3)

Series Expansions (3)

Function Identities and Simplifications (3)

Function Representations (3)

Applications (11)

Properties & Relations (4)

Possible Issues (2)

Neat Examples (1)

See Also

Tech Notes

Related Guides

Related Links

History

Text

CMS

APA

BibTeX

BibLaTeX
