ARProcess

ARProcess[{a₁,…,a_p},v]

represents a weakly stationary autoregressive process of order p with normal white noise variance v.

ARProcess[{a₁,…,a_p},Σ]

represents a weakly stationary vector AR process with multinormal white noise covariance matrix Σ.

ARProcess[{a₁,…,a_p},v,init]

represents an AR process with initial data init.

ARProcess[c,…]

represents an AR process with a constant c.

ARProcess

ARProcess[{a₁,…,a_p},v]

represents a weakly stationary autoregressive process of order p with normal white noise variance v.

ARProcess[{a₁,…,a_p},Σ]

represents a weakly stationary vector AR process with multinormal white noise covariance matrix Σ.

ARProcess[{a₁,…,a_p},v,init]

represents an AR process with initial data init.

ARProcess[c,…]

represents an AR process with a constant c.

Details

ARProcess is also known as AR or VAR (vector AR).
ARProcess is a discrete-time and continuous-state random process.
The AR process is described by the difference equation , where is the state output, is the white noise input, is the shift operator, and the constant c is taken to be zero if not specified.
The initial data init can be given as a list {…,y[-2],y[-1]} or a single-path TemporalData object with time stamps understood as {…,-2,-1}.
A scalar AR process can have real coefficients a_i and c, a positive variance v, and a non-negative integer order p.
An -dimensional vector AR process can have real coefficient matrices a_i of dimensions ×, real vector c of length , and the covariance matrix Σ should be symmetric positive definite of dimensions ×.
The AR process with zero constant has transfer function , where:
scalar process

vector process; is the × identity matrix
ARProcess[tproc,p] for a time series process tproc gives an AR process of order p such that the series expansions about zero of the corresponding transfer functions agree up to degree p.
Possible time series processes tproc include ARProcess, ARMAProcess, and SARIMAProcess.
ARProcess[p] represents an autoregressive process of order p for use in EstimatedProcess and related functions.
ARProcess can be used with such functions as CovarianceFunction, RandomFunction, and TimeSeriesForecast.

Examples

open all close all

Basic Examples (3)

Simulate an AR process:

Wolfram Language code: data = RandomFunction[ARProcess[2, {.3, -.5}, .1], {1, 10 ^ 2}]

Wolfram Language code: ListPlot[data, Filling -> Axis]

Covariance function:

Wolfram Language code: CovarianceFunction[ARProcess[{a}, σ^2], s, t]

Wolfram Language code:

DiscretePlot3D[CovarianceFunction[ARProcess[{.7, -.4, .5}, 1.], s, t], {s, 0, 10}, {t, 0, 10}, ExtentSize -> 1 / 2, ColorFunction -> "Rainbow"]

Correlation function:

Wolfram Language code: DiscretePlot[CorrelationFunction[ARProcess[{.5, .1, .3, -.2}, 1], h], {h, 0, 20}, ExtentSize -> 1 / 2]

Partial correlation function:

Wolfram Language code: DiscretePlot[PartialCorrelationFunction[ARProcess[{.5, .1, .3, -.2}, 1], h], {h, 1, 9}, ExtentSize -> 1 / 2]

Scope (38)

Basic Uses (11)

Simulate an ensemble of paths:

Wolfram Language code: data = RandomFunction[ARProcess[1, {.5}, 1], {30}, 4]

Wolfram Language code: ListLinePlot[data, Filling -> Axis]

Simulate with given precision:

Wolfram Language code: RandomFunction[ARProcess[1, {2 / 10, 1 / 10}, 1 / 10], {1, 4}, WorkingPrecision -> 20]["Path"]

Simulate a first-order scalar process:

Wolfram Language code: sample[a_] := RandomFunction[ARProcess[{a}, .1], {1, 200}];

Sample paths for positive and negative values of the parameter:

Wolfram Language code: ListPlot[sample[#], Filling -> Axis, PlotLabel -> ("a = " ~~ ToString[#])]& /@ {-0.9, 0.9}

Compare the serial dependence between consecutive values on scatter plots:

Wolfram Language code: pairs[a_] := Transpose[{Most[#], Rest[#]}]&[sample[a]["Values"]];

Wolfram Language code: ListPlot[pairs[#], PlotLabel -> ("a = " ~~ ToString[#])]& /@ {-0.9, 0.9}

Simulate a weakly stationary process with given initial values:

Wolfram Language code: sproc[x_] := ARProcess[0, {.4, .3}, 1, {x}];

Wolfram Language code: pts = {-4, 0, 4, 8};

Wolfram Language code: samples = Table[SeedRandom[4];RandomFunction[sproc[x], {30}], {x, pts}];

Wolfram Language code: ListLinePlot[samples, DataRange -> {0, 12}, PlotLegends -> (StringJoin["x = ", ToString[#]]& /@ pts)]

For a process with a trend, initial values influence the behavior of the whole path:

Wolfram Language code: tproc[x_] := ARProcess[0, {1.1, -0.04}, 1, {x}];

Wolfram Language code: tsamples = Table[SeedRandom[4];RandomFunction[tproc[x], {30}], {x, pts}];

Wolfram Language code: ListLinePlot[tsamples, DataRange -> {0, 12}, PlotLegends -> (StringJoin["x = ", ToString[#]]& /@ pts)]

Simulate a two-dimensional process:

Wolfram Language code:

α = {{.2, .1}, {-.3, .2}};
Σ = {{1.0, 0}, {0, 0.3}};
sample = RandomFunction[ARProcess[{α}, Σ], {1, 100}];

Create a 2D sample path function from the data:

Wolfram Language code:

s = TimeSeries[sample, ResamplingMethod -> Automatic];
f = s["PathFunction"];
g[t_ ? NumericQ] := f[t]

The color of the path is the function of time:

Wolfram Language code:

ParametricPlot[g[t], {t, 1, 100}, ColorFunction -> Function[{x, y, t}, (ColorData["BlueGreenYellow"][t])], PlotStyle -> Thick, AspectRatio -> 1, AxesLabel -> {x, y}]

Create a 3D sample path function with time:

Wolfram Language code: gg[t_ ? NumericQ] := Join[{t}, f[t]]

The color of the path is the function of time:

Wolfram Language code:

ParametricPlot3D[gg[t], {t, 1, 100}, ColorFunction -> Function[{t, x, y}, (ColorData["BlueGreenYellow"][t])], PlotStyle -> Thick, BoxRatios -> 1, AxesLabel -> {t, x, y}]

Simulate a three-dimensional process:

Wolfram Language code:

α = {{.2, .1, .1}, {-.3, .2, .1}, {-.3, .2, -.1}};
β = {{.2, .5, .1}, {-.2, .9, .5}, {.3, .1, -.4}};
Σ = {{1, 0, 0}, {0, .3, 0}, {0, 0, .1}};
SeedRandom[4];sample = RandomFunction[ARProcess[{α, β}, Σ], {1, 10 ^ 2}];

Create a sample path function from the data:

Wolfram Language code:

s = TimeSeries[sample, ResamplingMethod -> Automatic];f = s["PathFunction"];
g[t_ ? NumericQ] := f[t]

The color of the path is the function of time:

Wolfram Language code:

ParametricPlot3D[g[t], {t, 1, 100}, ColorFunction -> Function[{x, y, z, t}, (ColorData["BlueGreenYellow"][t])], PlotStyle -> Thick, BoxRatios -> 1, AxesLabel -> {x, y, z}]

Estimate process parameters:

Wolfram Language code:

sample = RandomFunction[ARProcess[{.2, -.4}, .1], {1, 300}];
eproc = EstimatedProcess[sample, ARProcess[2]]

Compare the sample covariance functions with that of the estimated process:

Wolfram Language code:

Show[ListPlot[CovarianceFunction[sample, {8}], Filling -> 0, PlotStyle -> PointSize[Medium]], DiscretePlot[CovarianceFunction[eproc, h], {h, 0, 8}, ExtentSize -> 1 / 2]]

Use TimeSeriesModel to automatically find orders:

Wolfram Language code: TimeSeriesModelFit[sample, "AR"]

Wolfram Language code: bestfit = %["BestFit"]

Compare the sample covariance functions with the best time series model:

Wolfram Language code:

Show[ListPlot[CovarianceFunction[sample, {8}], Filling -> 0, PlotStyle -> PointSize[Medium]], DiscretePlot[CovarianceFunction[bestfit, h], {h, 0, 8}, ExtentSize -> 1 / 2]]

Find the maximum likelihood estimator:

Wolfram Language code: proc = ARProcess[1, {.3, .4}, 1];

Wolfram Language code: SeedRandom[23];data = RandomFunction[proc, {100}];

Fix the constant and the variance and estimate the remaining parameters:

Wolfram Language code: res = FindProcessParameters[data, ARProcess[1, {a, b}, 1], ProcessEstimator -> "MaximumLikelihood"]

Plot the log-likelihood function together with the position of the estimated parameters:

Wolfram Language code: logℒ[x_Real, y_Real] := LogLikelihood[ARProcess[1, {x, y}, 1], data]

Wolfram Language code: ContourPlot[logℒ[x, y], {x, 0.1, .49}, {y, 0.1, .49}, Epilog -> {Red, Point[{a, b} /. res]}]

Estimate a vector autoregressive process:

Wolfram Language code:

proc = ARProcess[{1, 2}, {{{.2, .1}, {.5, .3}}}, {{1, .3}, {.3, .5}}];
data = RandomFunction[proc, {10 ^ 3}];

Wolfram Language code: eproc = EstimatedProcess[data, ARProcess[1]]

Compare covariance functions for each component:

Wolfram Language code:

Table[Show[ListPlot[CovarianceFunction[data["PathComponent", i], {8}], Filling -> 0, PlotStyle -> PointSize[Medium], PlotRange -> All], DiscretePlot[CovarianceFunction[eproc, h][[i, i]], {h, 0, 8}, ExtentSize -> 1 / 2]], {i, 1, 2}]

Forecast future values:

Wolfram Language code:

proc = ARProcess[2, {.1, .4}, .1];
sample = RandomFunction[proc, {1, 50}];

Find the forecast for the next 10 steps:

Wolfram Language code: forecast = TimeSeriesForecast[proc, sample, {10}]

Show the forecast path:

Wolfram Language code: forecast["Path"]

Plot the data and the forecasted values:

Wolfram Language code: ListLinePlot[{sample, forecast}, InterpolationOrder -> 0, Filling -> Axis]

Find a forecast for a vector-valued time series process:

Wolfram Language code:

proc = ARProcess[{{{.3, .1}, {.9, .1}}, {{.2, -.4}, {.5, -.3}}}, {{1, .2}, {.2, .6}}];
data = RandomFunction[proc, {0, 15}];

Find the forecast for the next 10 steps:

Wolfram Language code: forecast = TimeSeriesForecast[proc, data, {10}]

Plot the data and the forecast for each component:

Wolfram Language code:

Row@Table[ListLinePlot[#["PathComponent", j]& /@ {data, forecast}, PlotLabel -> Subscript[x, j], PlotLegends -> {"data", "forecast"}], {j, 1, 2}]

Covariance and Spectrum (6)

For low order it is possible to find the closed form of the correlation function:

Wolfram Language code: CorrelationFunction[ARProcess[{a}, σ^2], h]//PiecewiseExpand

Wolfram Language code: CorrelationFunction[ARProcess[{1 / 3, 1 / 2}, σ^2], h]//FunctionExpand//PiecewiseExpand

Partial correlation function is zero for lags larger than the process order:

Wolfram Language code: PartialCorrelationFunction[ARProcess[{a, b}, σ^2], h]//Simplify[#, h ≠ 0 && Element[h, Integers]]&

Wolfram Language code: PartialCorrelationFunction[ARProcess[{a, b, c, d}, σ^2], 1]

Correlation matrix:

Wolfram Language code: Correlation[ARProcess[{a, b}, σ^2][{1, 2, 3}]]//Simplify//MatrixForm

Covariance matrix:

Wolfram Language code: Covariance[ARProcess[{a}, σ^2][{1, 2, 3}]]//Simplify//MatrixForm

Inverse of the covariance matrix of an ARProcess is symmetric multidiagonal:

Wolfram Language code:

cov = Covariance[ARProcess[{1 / 7, 1 / 4, 1 / 5}, 1][Range[8]]];
Inverse[cov]//MatrixForm

Covariance function for a vector-valued process:

Wolfram Language code:

Σ = {{Subscript[σ, 1]^2, ρ Subscript[σ, 1]Subscript[σ, 2]}, {ρ Subscript[σ, 1]Subscript[σ, 2], Subscript[σ, 2]^2}};
α = {{a, 0}, {0, b}};

Wolfram Language code: CovarianceFunction[ARProcess[{α}, Σ], h]//TraditionalForm

Power spectral density:

Wolfram Language code: Plot[PowerSpectralDensity[ARProcess[{.4, -.4, .3}, 1], w], {w, -π, π}, Filling -> Axis]

Wolfram Language code: PowerSpectralDensity[ARProcess[{a}, σ^2], w]

Vector ARMAProcess:

Wolfram Language code:

a = {{1 / 9, 0}, {1 / 3, 1 / 2}};
b = {{1, 3 / 4}, {1 / 2, -1 / 4}};
Σ = {{1, 1 / 3}, {1 / 3, 1}};
proc = ARMAProcess[{a}, {b}, Σ];

Wolfram Language code:

psd = PowerSpectralDensity[proc, ω];
psd//FullSimplify//MatrixForm

Stationarity and Invertibility (4)

Check if a time series process is weakly stationary:

Wolfram Language code: WeakStationarity[ARProcess[.3, {1, 2}, 1, {}]]

For a vector process:

Wolfram Language code: WeakStationarity[ARProcess[{{{.3, .2}, {-.4, .1}}}, {{1, .3}, {.3, .6}}]]

Find conditions for a process to be weakly stationary:

Wolfram Language code: cond2D = WeakStationarity[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2]]

Wolfram Language code: RegionPlot[cond2D, {Subscript[a, 1], -2, 2}, {Subscript[a, 2], -2, 2}, FrameLabel -> Automatic]

Find conditions for higher order:

Wolfram Language code: cond3D = WeakStationarity[ARProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, σ^2]]

Wolfram Language code:

RegionPlot3D[Simplify@cond3D, {Subscript[a, 1], -2, 2}, {Subscript[a, 2], -2, 2}, {Subscript[a, 3], -2, 2}, PlotPoints -> 40, AxesLabel -> Automatic]

Variance is positive only for a weakly stationary process:

Wolfram Language code: v = Variance[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, 1][∞]]//FullSimplify

Define stationarity conditions:

Wolfram Language code: cond = WeakStationarity[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, 1]]

Variance is positive, assuming weak stationarity:

Wolfram Language code: FullSimplify[v > 0, cond]

Autoregressive process is always invertible:

Wolfram Language code: TimeSeriesInvertibility[ARProcess[const, {Subscript[a, 1], Subscript[a, 2]}, σ^2]]

Estimation Methods (6)

The available methods for estimating an ARProcess:

Wolfram Language code:

methods = {Automatic, "MethodOfMoments", "MaximumConditionalLikelihood", "MaximumLikelihood", "SpectralEstimator", "MaximumEntropy"};

Wolfram Language code:

SeedRandom[14];
data = RandomFunction[ARProcess[2, {.4, .2, .3}, 1], {100}];

Wolfram Language code:

Grid[res = Table[{m, EstimatedProcess[data, ARProcess[3], ProcessEstimator -> m]}, {m, methods}], Frame -> All, Spacings -> {1, 2}, Alignment -> {Left, Center}]

Compare log-likelihoods:

Wolfram Language code: LogLikelihood[#[[2]], data]& /@ res

Method of moments admits the following solvers:

Wolfram Language code: solvers = {Automatic, "LevinsonDurbin", "LeastSquares", "FindRoot", "NSolve"};

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code:

Grid[Table[{m, EstimatedProcess[data, ARProcess[3], ProcessEstimator -> {"MethodOfMoments", Method -> m}]}, {m, solvers}], Frame -> All, Spacings -> {1, 2}, Alignment -> {Left, Center}]

Use a general solver for moments when fixing or repeating parameters:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.4, b}, v], ProcessEstimator -> "MethodOfMoments"]

Maximum conditional likelihood method allows the following solvers:

Wolfram Language code: solvers = {Automatic, "FindMaximum", "NMaximize"};

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code:

Grid[Table[{m, EstimatedProcess[data, ARProcess[3], ProcessEstimator -> {"MaximumConditionalLikelihood", Method -> m}]}, {m, solvers}], Frame -> All, Spacings -> {1, 2}, Alignment -> {Left, Center}]

This method allows for fixed parameters:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.1, b}, v], ProcessEstimator -> "MaximumConditionalLikelihood"]

Some relations between parameters are also permitted:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {b, b}, v], ProcessEstimator -> "MaximumConditionalLikelihood"]

Maximum likelihood method allows the following solvers:

Wolfram Language code: solvers = {Automatic, "FindMaximum", "NMaximize"};

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code:

Grid[Table[{m, EstimatedProcess[data, ARProcess[2], ProcessEstimator -> {"MaximumLikelihood", Method -> m}]}, {m, solvers}], Frame -> All, Spacings -> {1, 2}, Alignment -> {Left, Center}]

This method allows for fixed parameters:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.1, b}, v], ProcessEstimator -> "MaximumLikelihood"]

Some relations between parameters are also permitted:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {b, b}, v], ProcessEstimator -> "MaximumLikelihood"]

Spectral estimator allows specification of windows used for PowerSpectralDensity calculation:

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2, .1}, 1], {100}];

Wolfram Language code:

Grid[Table[{m, EstimatedProcess[data, ARProcess[3], ProcessEstimator -> {"SpectralEstimator", "Window" -> m}]}, {m, {10, BartlettWindow, {3, HannWindow}}}], Frame -> All, Spacings -> {1, 2}, Alignment -> {Left, Center}]

Spectral estimator allows the following solvers:

Wolfram Language code: solvers = {Automatic, "FindMinimum", "NMinimize"};

Wolfram Language code:

Grid[Table[{m, EstimatedProcess[data, ARProcess[2], ProcessEstimator -> {"SpectralEstimator", Method -> m}]}, {m, solvers}], Frame -> All, Spacings -> {1, 2}, Alignment -> {Left, Center}]

This method allows for fixed parameters:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.1, b}, v], ProcessEstimator -> "SpectralEstimator"]

Some relations between parameters are also permitted:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {b, b}, v], ProcessEstimator -> "SpectralEstimator"]

Maximum entropy method:

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code: EstimatedProcess[data, ARProcess[2], ProcessEstimator -> "MaximumEntropy"]

It is also known as Burg method:

Wolfram Language code: EstimatedProcess[data, ARProcess[2], ProcessEstimator -> "Burg"]

Process Slice Properties (5)

Univariate SliceDistribution:

Wolfram Language code: SliceDistribution[ARProcess[c, {a}, σ^2], t]//PDF[#, x]&

Multivariate slice distributions:

Wolfram Language code: SliceDistribution[ARProcess[{.2, .3}, 1], {s, s + 3}]//Mean

Wolfram Language code: SliceDistribution[ARProcess[{.2, .3}, 1], {1, 2, 3}]//Covariance

Slice distribution of a vector-valued time series:

Wolfram Language code:

α = {{Subscript[a, 1], 0}, {0, Subscript[a, 2]}};
Σ = {{Subscript[σ, 1]^2, ρ Subscript[σ, 1]Subscript[σ, 2]}, {ρ Subscript[σ, 1]Subscript[σ, 2], Subscript[σ, 2]^2}};

Wolfram Language code: Mean[ARProcess[{c1, c2}, {α}, Σ][3]]

Wolfram Language code: Covariance[SliceDistribution[ARProcess[{c1, c2}, {α}, Σ], {1, 2, 3}]]//MatrixForm

First-order probability density function with zero initial conditions:

Wolfram Language code: pdf = PDF[ARProcess[c, {a}, σ^2, {}][t], x]//PiecewiseExpand//Simplify

Wolfram Language code:

Plot[Evaluate@Table[pdf /. {c -> 1, a -> .7, σ -> 1}, {t, 1, 4}], {x, -3, 6}, Filling -> Axis, PlotLegends -> {"t = 1", "t = 2", "t = 3", "t = 4"}]

Stationary mean and variance:

Wolfram Language code: μ = Mean[ARProcess[c, {Subscript[a, 1], Subscript[a, 2]}, σ^2][∞]]

Wolfram Language code: v = Variance[ARProcess[c, {Subscript[a, 1], Subscript[a, 2]}, σ^2][∞]]

Compare with the density function of a normal distribution:

Wolfram Language code: PDF[NormalDistribution[μ, Sqrt[v]], x]

Wolfram Language code: FullSimplify[% - PDF[ARProcess[c, {Subscript[a, 1], Subscript[a, 2]}, σ^2][∞], x]]

Compute the expectation of an expression:

Wolfram Language code: Expectation[x[3] ^ 2, xARProcess[c, {Subscript[a, 1], Subscript[a, 2]}, σ^2]]

Calculate a probability:

Wolfram Language code: Probability[x[7] < 6, xARProcess[{a}, σ^2]]

Skewness and kurtosis functions are constant:

Wolfram Language code: Skewness[ARProcess[c, {a}, σ^2][t]]

Wolfram Language code: Kurtosis[ARProcess[c, {Subscript[a, 1], Subscript[a, 2]}, σ^2][t]]

Moment:

Wolfram Language code: Table[Moment[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], r], {r, 0, 5}]

Generating functions:

Wolfram Language code: CharacteristicFunction[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], w]

Wolfram Language code: MomentGeneratingFunction[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], w]

CentralMoment and its generating function:

Wolfram Language code: Table[CentralMoment[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], r], {r, 0, 5}]

Wolfram Language code: CentralMomentGeneratingFunction[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], w]

FactorialMoment has no closed form for symbolic order:

Wolfram Language code: Table[FactorialMoment[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], r], {r, 0, 5}]

Wolfram Language code: FactorialMomentGeneratingFunction[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], w]

Cumulant and its generating function:

Wolfram Language code: Table[Cumulant[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], r], {r, 0, 5}]

Wolfram Language code: CumulantGeneratingFunction[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2][t], w]

Representations (6)

Approximate an MA process with an AR process of order 3:

Wolfram Language code:

proc = MAProcess[.4, {.2, .3, -.1}, 1];
aproc = ARProcess[proc, 3]

Compare the covariance function for the original and the approximate processes:

Wolfram Language code: DiscretePlot[CovarianceFunction[#, h], {h, 0, 10}, ExtentSize -> 1 / 2, PlotLabel -> Head[#]]& /@ {proc, aproc}

Approximate a vector process:

Wolfram Language code:

proc = MAProcess[{.4, .2}, {{{.2, .5}, {-.3, .5}}}, {{.6, .2}, {.2, .4}}];
aproc = ARProcess[proc, 3]

Approximate an ARMA process with an AR process:

Wolfram Language code: ARProcess[ARMAProcess[c, {Subscript[a, 1], Subscript[a, 2]}, {Subscript[b, 1], Subscript[b, 2], Subscript[b, 3]}, v], 2]

Approximate an ARMA with fixed initial values:

Wolfram Language code:

proc = ARMAProcess[.4, {.2, -.3, -.2}, {.8, -.2, .7}, 1., {}];
aproc = ARProcess[proc, 3]

Compare sample paths:

Wolfram Language code:

SeedRandom[13];sample = RandomFunction[proc, {100}];
SeedRandom[13];asample = RandomFunction[aproc, {100}];
ListLinePlot[{sample, asample}, PlotLegends -> {"ARMA", "AR"}]

Approximate a SARIMA process with an AR process:

Wolfram Language code:

proc = SARIMAProcess[{.2, -.3, -.1}, 1, {.6, .2}, {4, {.3}, 1, {}}, 1];
aproc = ARProcess[proc, 15]

Compare sample paths:

Wolfram Language code:

SeedRandom[13];sample = RandomFunction[proc, {150}];
SeedRandom[13];asample = RandomFunction[aproc, {150}];
ListLinePlot[{sample, asample}, PlotLegends -> {"SARIMA", "AR"}]

TransferFunctionModel representation:

Wolfram Language code: TransferFunctionModel[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2], z]

For a vector-valued process:

Wolfram Language code:

α = {{.2, .3}, {0, .1}};
β = {{-.3, .1}, {.5, -.4}};
Σ = {{1, 0}, {0, 1}};
TransferFunctionModel[ARProcess[{α, β}, Σ], z]

PoleZeroPlot of a stationary AR process:

Wolfram Language code:

proc = ARProcess[{.3, .4, .1}, 1];
tfm = TransferFunctionModel[proc];

Wolfram Language code: PoleZeroPlot[tfm]

A non stationary AR process has at least one pole outside the unit circle:

Wolfram Language code:

proc = ARProcess[{.3, .5, .8}, 1, {}];
PoleZeroPlot[StateSpaceModel[proc]]

StateSpaceModel representation:

Wolfram Language code: StateSpaceModel[ARProcess[{Subscript[a, 1], Subscript[a, 2]}, σ^2]]

For a vector-valued process:

Wolfram Language code:

α = {{.2, .3}, {0, .1}};
β = {{-.3, .1}, {.5, -.4}};
Σ = {{1, 0}, {0, 1}};
StateSpaceModel[ARProcess[{α, β}, Σ]]

Applications (6)

Use ARProcess to estimate an ARMAProcess:

Wolfram Language code:

data = RandomFunction[proc = ARMAProcess[{.3}, {.2}, 1], {10 ^ 4}];
ar = EstimatedProcess[data, ARProcess[20]]

Transform the estimated process to ARMA with given orders:

Wolfram Language code: arma = ARMAProcess[ar, {1, 1}]

Compare log-likelihood values:

Wolfram Language code: LogLikelihood[#, data]& /@ {proc, arma}

Consider the mean daily temperature for Champaign in August 2012:

Wolfram Language code:

temp = TemporalData[TimeSeries, {{{20.5, 20.89, 22.5, 27.44, 26.5, 20.33, 18.83, 23.06, 20.83, 19.72,
    14.89, 15.28, 18.11, 18.72, 17.5, 20.83, 17.94, 13.56, 16.44, 14.33, 14.72, 15.83, 17.28,
    19.89, 20.44, 21.39, 24.89, 22.78, 22.83, 20.22, 24.4 ... te", 1}, 1,
  {ResamplingMethod -> {"Interpolation", InterpolationOrder -> 1}, ValueDimensions -> 1,
   MetaInformation -> {"Source" -> HoldForm[WeatherData["Champaign", "MeanTemperature",
        {{2012, 8}, {2012, 8}, "Day"}]]}}}, True, 10.1];

Wolfram Language code: temp["Source"]

Wolfram Language code: DateListPlot[temp, Joined -> True, Filling -> Axis]

Find process parameters:

Wolfram Language code: eproc = EstimatedProcess[temp, ARProcess[20]]

Compare CorrelationFunction of the model and the data:

Wolfram Language code:

ListPlot[TemporalData[CorrelationFunction[#, {30}]& /@ {temp, eproc}], Filling -> {1 -> {2}}, PlotStyle -> PointSize[Medium], PlotLegends -> {"Data", "Model"}]

The hourly readings of temperature in June 2011 near your location:

Wolfram Language code:

temp = TemporalData[TimeSeries, {{{20, 18.3, 17.2, 16.1, 15.6, 18.3, 21.1, 23.3, 25.6, 27.2, 28.3, 28.9,
    30, 30, 30, 30.6, 30, 28.3, 25.6, 22.8, 22.2, 20.6, 19.4, 17.8, 17.8, 16.1, 17.8, 17.8, 18.9,
    18.3, 19.4, 20, 18.3, 18, 18.3, 19, 20.6, 22.8 ...  "Hour"}]}, 1, {"Discrete", 1}, {"Discrete", 1}, 1,
  {ResamplingMethod -> {"Interpolation", InterpolationOrder -> 1},
   MetaInformation -> {"Source" -> HoldForm[WeatherData[FindGeoLocation[], "Temperature",
        {2011, 6}]]}}}, True, 10.1];

Wolfram Language code: temp["Source"]

Wolfram Language code: DateListPlot[temp, Joined -> True, Filling -> Axis]

Find model parameters:

Wolfram Language code: proc = EstimatedProcess[temp, ARProcess[48]]

Create TimeSeriesModel with estimated process:

Wolfram Language code: tsm = TimeSeriesModelFit[temp, proc]

Check goodness of fit by investigating residuals:

Wolfram Language code: {#["ACFPlot"], #["PACFPlot"]}&[tsm]

The daily exchange rates of the euro to the dollar from May 2012 through September 2012:

Wolfram Language code:

data = TemporalData[Automatic, {{{1.31, 1.31, 1.31, 1.3, 1.3, 1.3, 1.29, 1.29, 1.29, 1.27, 1.28, 1.28,
    1.27, 1.26, 1.26, 1.26, 1.25, 1.24, 1.24, 1.23, 1.24, 1.24, 1.25, 1.26, 1.25, 1.26, 1.25, 1.25,
    1.26, 1.26, 1.26, 1.26, 1.27, 1.27, 1.25, 1.25 ... Data`DateSpecification[{2012, 5, 2}, {2012, 9, 28}, "BusinessDay", "DayRange"]}, 1,
  {"Discrete", 1}, {"Discrete", 1}, 1,
  {MetaInformation -> {"Source" -> HoldForm[FinancialData]["EUR/USD",
       {{2012, 5, 1}, {2012, 9, 30}}]}}}, True, 9.];

Wolfram Language code: data["Source"]

Wolfram Language code: DateListPlot[data, Joined -> True, Filling -> Bottom]

The scatter plot of consecutive values indicates strong serial correlation:

Wolfram Language code: With[{vals = data["Values"]}, ListPlot[Transpose[{Most[vals], Rest[vals]}]]]

Fit an AR process to the exchange rates:

Wolfram Language code: eproc = EstimatedProcess[data, ARProcess[3]]

Forecast for 20 business days ahead:

Wolfram Language code: forecast = TimeSeriesForecast[eproc, data, {20}]

Plot the forecast with original data:

Wolfram Language code: DateListPlot[{data, forecast}, Joined -> True, Filling -> Bottom]

Daily mean temperature readings in years 2000–2011 near your location:

Wolfram Language code:

temp = TemporalData[TimeSeries, {{{-1.22, -4.2, 2.14, 9.92, 18.05, 20.6, 25.11, 23.63, 18.85, 10.11, 4.42,
    -0.59, -4.52, -0.63, 4.72, 13.81, 14.6, 22.48, 23.41, 23.75, 19.75, 12.52, 7.45, -2.27, -7.41,
    -3.33, 4.81, 9.41, 22.12, 21.34, 25.7, 23.2 ... , 1}, {"Discrete", 1}, 1,
  {ResamplingMethod -> {"Interpolation", InterpolationOrder -> 1},
   MetaInformation -> {"Source" -> HoldForm[WeatherData[FindGeoLocation[], "MeanTemperature",
        {{1980, 1}, {2012, 1}, "Month"}]]}}}, True, 10.1];

Wolfram Language code: temp["Source"]

Wolfram Language code: DateListPlot[temp, Joined -> True, Filling -> Bottom]

Find process parameters:

Wolfram Language code: tsm = TimeSeriesModelFit[temp, "AR"]

Wolfram Language code: eproc = tsm["Process"]

Check stationarity assuming Automatic initial conditions:

Wolfram Language code: WeakStationarity[eproc]

Compare CorrelationFunction and PartialCorrelationFunction of the model and the sample:

Wolfram Language code:

modelCorr = DiscretePlot[#[eproc, h], {h, 1, 60}, PlotRange -> {-1, 1}, ExtentSize -> 1 / 2]& /@ {CorrelationFunction, PartialCorrelationFunction};
sampleCorr = ListLinePlot[#[temp["PathStates"], {1, 60}], PlotRange -> {-1, 1}, PlotLabel -> #]& /@ {CorrelationFunction, PartialCorrelationFunction};
MapThread[Show[#2, #1]&, {modelCorr, sampleCorr}]

The following data represents the return on DJIA and return on market capitalization for eight months during 1961. Fit a VAR model to this data:

Wolfram Language code:

data = TemporalData[{{1, {0.02619, 0.032994}}, {2, {0.02575, 0.033013}}, {3, {0.01442, 0.006127}}, {4, {0.02067, 0.022185}}, {5, {-0.02172, -0.030350}}, {6, {0.01913, 0.033709}}, {7, {0.03243, 0.022871}}, {8, {-0.03279, -0.020618}}}]

Wolfram Language code: ListLinePlot[data]

Wolfram Language code: eproc = EstimatedProcess[data, ARProcess[1]]

Simulate the estimated process:

Wolfram Language code: sample = RandomFunction[eproc, {1, 8}, 10 ^ 3];

Find the mean path for each component:

Wolfram Language code: mean = TimeSeriesThread[Mean, sample];

Wolfram Language code: ListLinePlot[mean]

Properties & Relations (7)

ARProcess is a special case of an ARMAProcess:

Wolfram Language code: TransferFunctionModel[ARMAProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, {}, σ^2], z]

Wolfram Language code: TransferFunctionModel[ARProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, σ^2], z]

Wolfram Language code: % - %%

ARProcess is a special case of an ARIMAProcess:

Wolfram Language code: TransferFunctionModel[ARIMAProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, 0, {}, σ^2], z]

Wolfram Language code: TransferFunctionModel[ARProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, σ^2], z]

Wolfram Language code: % - %%

ARProcess is a special case of a FARIMAProcess:

Wolfram Language code: TransferFunctionModel[FARIMAProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, 0, {}, σ^2], z]

Wolfram Language code: TransferFunctionModel[ARProcess[{Subscript[a, 1], Subscript[a, 2], Subscript[a, 3]}, σ^2], z]

Wolfram Language code: % - %%

ARProcess is a special case of a SARMAProcess:

Wolfram Language code: TransferFunctionModel[SARMAProcess[{a}, {}, {1, {g}, {}}, σ^2], z]

Wolfram Language code: TransferFunctionModel[ARProcess[{a + g, -a g}, σ^2], z]

Wolfram Language code: Simplify[% - %%]

ARProcess is a special case of a SARIMAProcess:

Wolfram Language code: TransferFunctionModel[SARIMAProcess[{a}, 0, {}, {1, {g}, 0, {}}, σ^2], z]

Wolfram Language code: TransferFunctionModel[ARProcess[{a + g, -a g}, σ^2], z]

Wolfram Language code: Simplify[% - %%]

Squared values of an ARCHProcess follow an AR process:

Wolfram Language code: proc = ARCHProcess[1, {.2, .3}];

Wolfram Language code: data = RandomFunction[proc, {10 ^ 4}]["PathStates"];

CorrelationFunction and PartialCorrelationFunction of squared values:

Wolfram Language code:

dataSQ = data ^ 2;
ListPlot[#[dataSQ, {30}], Filling -> Axis, PlotRange -> {-.2, 1}, PlotLabel -> #]& /@ {CorrelationFunction, PartialCorrelationFunction}

The corresponding autoregressive process:

Wolfram Language code: ar = ARProcess[proc]

CorrelationFunction and PartialCorrelationFunction of the AR process:

Wolfram Language code:

ListPlot[#[ar, {30}], Filling -> Axis, PlotRange -> {-.2, 1}, PlotLabel -> #]& /@ {CorrelationFunction, PartialCorrelationFunction}

Cumulated AR process is equivalent to an ARMAProcess:

Wolfram Language code:

ar = ARProcess[{a}, v];
proc = TransformedProcess[x[t] + x[t - 1], xar, t];

Corresponding ARMA process:

Wolfram Language code: arma = ARMAProcess[{a}, {1}, v];

Compare means:

Wolfram Language code: Mean[proc[t]]

Wolfram Language code: Mean[arma[t]]

Compare covariance functions:

Wolfram Language code: Table[CovarianceFunction[proc, t, t + k] - CovarianceFunction[arma, t, t + k], {k, 0, 10}, {t, 1, 10}]//Simplify

Possible Issues (5)

Some properties are defined only for wide-sense stationary processes:

Wolfram Language code: CovarianceFunction[ARProcess[{2, 3, .3}, 1], h]

Use FindInstance to find an example of a weakly stationary AR process:

Wolfram Language code: FindInstance[a > 1 && WeakStationarity[ARProcess[{a, b, 1 / 3}, 1]], {a, b}]

Wolfram Language code: CovarianceFunction[ARProcess[{3 / 2, -5 / 4, 1 / 3}, 1], h]//DiscretePlot[#, {h, 0, 10}]&

A process without specified initial values must satisfy weak stationarity conditions:

Wolfram Language code: ProcessParameterAssumptions[ARProcess[{a}, v]]

Some properties will work after specifying initial value(s):

Wolfram Language code: RandomFunction[ARProcess[{1}, 1], {3}]

Add zero initial values:

Wolfram Language code: RandomFunction[ARProcess[{1}, 1, {}], {3}]

Levinson–Durbin estimation method is not always applicable:

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.4, b, b}, v], ProcessEstimator -> {"MethodOfMoments", Method -> "LevinsonDurbin"}]

Use a different solver:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.4, b, b}, v], ProcessEstimator -> {"MethodOfMoments", Method -> "NSolve"}]

The method of moments may not find a solution in estimation:

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {a * b, a, b}, v], ProcessEstimator -> {"MethodOfMoments", Method -> "NSolve"}]

Use a different solver:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {a * b, a, b}, v], ProcessEstimator -> "MaximumConditionalLikelihood"]

Maximum entropy estimation method does not allow fixed or repeated parameters:

Wolfram Language code:

SeedRandom[4];
data = RandomFunction[ARProcess[2, {.4, .2}, 1], {100}];

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.1, b, b}, v], ProcessEstimator -> "MaximumEntropy"]

Use a different solver:

Wolfram Language code: EstimatedProcess[data, ARProcess[c, {.1, b, b}, v], ProcessEstimator -> Automatic]

Neat Examples (2)

Simulate a weakly stationary three-dimensional ARProcess:

Wolfram Language code:

A = {{.2, .1, .1}, {0, -.2, .3}, {.2, -.1, .3}};
S = {{.8, .1, -.2}, {.1, .5, .1}, {-.2, .1, .3}};
proc1 = ARProcess[{A}, S];
data1 = RandomFunction[proc1, {100}]["PathStates"];

Wolfram Language code: Graphics3D[{ColorData["SolarColors"][RandomReal[]], Tube@Line@data1}]

Non-weakly stationary process, starting at the origin:

Wolfram Language code:

B = {{.9, .2, .8}, {-.2, .8, -.3}, {.2, .2, .4}};
S = {{.8, .1, -.2}, {.1, .5, .1}, {-.2, .1, .3}};
proc2 = ARProcess[{B}, S, {}];
data2 = RandomFunction[proc2, {100}]["PathStates"];

Wolfram Language code: Graphics3D[{ColorData["SolarColors"][RandomReal[]], Tube@Line@data2}]

Simulate paths from an AR process:

Wolfram Language code:

SeedRandom[154];
data = RandomFunction[ARProcess[{.3}, 1], {50}, 200];

Take a slice at 50 and visualize its distribution:

Wolfram Language code: sd = data["SliceData", 50];

Wolfram Language code:

cf = ColorData["Rainbow"];
sliced = BarChart[Last[#], Axes -> False, BarOrigin -> Left, AspectRatio -> 4, ChartStyle -> (cf /@ Rescale[MovingAverage[First[#], 2], {Min[sd], Max[sd]}, {0, 1}]), ImageSize -> 55]&[HistogramList[sd, {Range[Min[sd], Max[sd], (Max[sd] - Min[sd]) / 20]}]];

Plot paths and histogram distribution of the slice distribution at 50:

Wolfram Language code:

ListLinePlot[data, ImageSize -> 400, PlotRange -> All,
	AspectRatio -> 3 / 4, Epilog -> Inset[sliced, {51, 0}, {0, 10}], PlotStyle -> (cf /@ Rescale[sd]), BaseStyle -> Directive[Thin, Opacity[0.5]], PlotRangePadding -> {{0, 15}, {.5, .5}}]

Top

More Learning

Tech Support

Wolfram Solutions

Wolfram Solutions For Education

Get Started

Grow Your Skills

Work with Us

Educational Programs for Adults

Educational Programs for Youth

Read

ARProcess

Details

Examples

Basic Examples (3)

Scope (38)

Basic Uses (11)

Covariance and Spectrum (6)

Stationarity and Invertibility (4)

Estimation Methods (6)

Process Slice Properties (5)

Representations (6)

Applications (6)

Properties & Relations (7)

Possible Issues (5)

Neat Examples (2)

Text

CMS

APA

BibTeX

BibLaTeX

ARProcess

Details

Examples

Basic Examples (3)

Scope (38)

Basic Uses (11)

Covariance and Spectrum (6)

Stationarity and Invertibility (4)

Estimation Methods (6)

Process Slice Properties (5)

Representations (6)

Applications (6)

Properties & Relations (7)

Possible Issues (5)

Neat Examples (2)

See Also

Related Guides

History

Text

CMS

APA

BibTeX

BibLaTeX
