EllipticE

EllipticE[m]

gives the complete elliptic integral .

EllipticE[ϕ,m]

gives the elliptic integral of the second kind .

Details

Mathematical function, suitable for both symbolic and numerical manipulation.
For and , $TemplateBox[{phi, m}, EllipticE2]=int_0^phi(1-m sin^2(theta))^(1/2)dtheta$ .
.
EllipticE[m] has a branch cut discontinuity in the complex m plane running from to .
EllipticE[ϕ,m] has branch cut discontinuities at and at .
For certain special arguments, EllipticE automatically evaluates to exact values.
EllipticE can be evaluated to arbitrary numerical precision.
EllipticE automatically threads over lists.
EllipticE can be used with Interval and CenteredInterval objects. »

Examples

open all close all

Basic Examples (5)

Evaluate numerically:

Wolfram Language code: EllipticE[0.4]

Plot over a subset of the reals:

Wolfram Language code: Plot[EllipticE[m], {m, 0, 1}]

Plot over a subset of the complexes:

Wolfram Language code: ComplexPlot3D[EllipticE[z], {z, -7 - 7I, 7 + 7I}, PlotLegends -> Automatic, Exclusions -> All, PlotTheme -> "Web"]

Series expansion at the origin:

Wolfram Language code: Series[EllipticE[m], {m, 0, 6}]

Series expansion at Infinity:

Wolfram Language code: Series[EllipticE[x], {x, ∞, 2}]//Normal

Scope (41)

Numerical Evaluation (5)

Evaluate numerically for complex arguments:

Wolfram Language code: EllipticE[3 + 2.5 I]

Wolfram Language code: EllipticE[3 + 2.5 I, 2.3 - 1.5 I]

Evaluate to high precision:

Wolfram Language code: N[EllipticE[1 / 3], 50]

Wolfram Language code: N[EllipticE[2 / 3, 2], 50]

The precision of the output tracks the precision of the input:

Wolfram Language code: EllipticE[0.1234567890000000000]

Wolfram Language code: EllipticE[0.1234567890000000000000000000000]

Wolfram Language code: EllipticE[2, 0.1234567890000000000000000000000]

Wolfram Language code: EllipticE[2, 0.123456789000000000000000000000000000000]

Evaluate EllipticE efficiently at high precision:

Wolfram Language code: EllipticE[0.4`500]//Timing

Wolfram Language code: EllipticE[0.4`100000];//Timing

Compute worst-case guaranteed intervals using Interval and CenteredInterval objects:

Wolfram Language code: EllipticE[1 / 10, Interval[{1.2, 1.3}]]

Wolfram Language code: EllipticE[CenteredInterval[-4, 1 / 100]]

Wolfram Language code: EllipticE[1 / 3, CenteredInterval[-4, 1 / 5]]

Or compute average-case statistical intervals using Around:

Wolfram Language code: EllipticE[ Around[2, 0.01], 1 / 2]

Compute the elementwise values of an array:

Wolfram Language code: EllipticE[{{1, 0}, {0, 1}}]

Or compute the matrix EllipticE function using MatrixFunction:

Wolfram Language code: MatrixFunction[EllipticE, {{1, 0}, {0, 1}}]

Specific Values (4)

Simple exact values are generated automatically:

Wolfram Language code: {EllipticE[0], EllipticE[1]}

Wolfram Language code: {EllipticE[0, m], EllipticE[ϕ, 0], EllipticE[Pi / 2, m]}

Find limiting values at branch cuts of the complete elliptic integral:

Wolfram Language code: {Limit[EllipticE[2 + ε I], ε -> 0, Direction -> 1], Limit[EllipticE[2 + ε I], ε -> 0, Direction -> -1]}

Find limiting values at branch cuts of the elliptic integral of the second kind:

Wolfram Language code:

{Limit[EllipticE[Pi / 2 + ε I, 2], ε -> 0, Direction -> -1], Limit[EllipticE[Pi / 2 + ε I, 2], ε -> 0, Direction -> +1]}

Values at infinity:

Wolfram Language code: {EllipticE[Infinity], EllipticE[ComplexInfinity]}

Wolfram Language code: EllipticE[Infinity, Infinity]

Find the root of the equation :

Wolfram Language code:

f[m_] := EllipticE[m] - 2;
xzero = N@Solve[f[m] == 0 && -2 < m < -1, m][[1, 1, 2]]//Quiet

Wolfram Language code: Plot[f[m], {m, -2, 2}, Epilog -> Style[Point[{xzero, f[xzero]}], PointSize[Large], Red]]

Visualization (3)

Plot the complete elliptic integral:

Wolfram Language code: Plot[EllipticE[m], {m, -10, 1}]

Plot the elliptic integral of the second kind:

Wolfram Language code: Plot[{EllipticE[-2, m], EllipticE[-1, m], EllipticE[1, m], EllipticE[2, m]}, {m, -10, 2}]

Plot the real part of :

Wolfram Language code: ComplexContourPlot[Re[EllipticE[z]], {z, -5 - 5I, 5 + 5I}, IconizedObject[«PlotOptions»]]

Plot the imaginary part of :

Wolfram Language code: ComplexContourPlot[Im[EllipticE[z]], {z, -5 - 5I, 5 + 5I}, IconizedObject[«PlotOptions»]]

Function Properties (10)

is defined for all real values less than or equal to 1:

Wolfram Language code: FunctionDomain[EllipticE[m], m]

takes all real values greater than or equal to 1:

Wolfram Language code: FunctionRange[EllipticE[m], m, y]//Quiet

EllipticE is an odd function with respect to its first parameter:

Wolfram Language code: EllipticE[-ϕ, m]

EllipticE is not an analytic function:

Wolfram Language code: FunctionAnalytic[EllipticE[x], x]

Has both singularities and discontinuities for :

Wolfram Language code: FunctionSingularities[EllipticE[x], x]//Quiet

Wolfram Language code: FunctionDiscontinuities[EllipticE[x], x]//Quiet

EllipticE is not a meromorphic function:

Wolfram Language code: FunctionMeromorphic[EllipticE[m], m]

is nonincreasing on its domain:

Wolfram Language code: FunctionMonotonicity[{EllipticE[x], x < 1}, x]

is injective:

Wolfram Language code: FunctionInjective[EllipticE[x], x]

Wolfram Language code: Plot[{EllipticE[x], 2}, {x, -5, 1}]

is not surjective:

Wolfram Language code: FunctionSurjective[EllipticE[x], x]

Wolfram Language code: Plot[{EllipticE[x], -1}, {x, -5, 2}]

is non-negative on its domain:

Wolfram Language code: FunctionSign[{EllipticE[x], x < 1}, x]

is concave on its domain:

Wolfram Language code: FunctionConvexity[{EllipticE[x], x < 1}, x]

Differentiation (4)

First derivative:

Wolfram Language code: D[EllipticE[m], m]

Higher derivatives:

Wolfram Language code: Table[D[EllipticE[m], {m, n}], {n, 1, 3}]//FullSimplify

Wolfram Language code: Plot[Evaluate[%], {m, -10, 1}, PlotLegends -> {"First Derivative", "Second Derivative", "Third Derivative"}]

Formula for the derivative:

Wolfram Language code: D[EllipticE[m], {m, n}]

Derivative with respect to the first argument of the elliptic integral of the second kind:

Wolfram Language code: D[EllipticE[ϕ, m], ϕ]

Integration (3)

Indefinite integral of EllipticE:

Wolfram Language code: Integrate[EllipticE[m], m]//FullSimplify

Definite integral of an odd function over an interval centered at the origin is 0:

Wolfram Language code: Integrate[EllipticE[ϕ, m], {ϕ, -1 / 2, 1 / 2}]

More integrals:

Wolfram Language code: Integrate[m^αEllipticE[m], m]

Wolfram Language code: Integrate[Sin[ϕ]EllipticE[ϕ, m], ϕ]

Wolfram Language code: Integrate[( Sin[2 ϕ]EllipticE[ϕ, m]/(1 - m Sin[ϕ]^2)^3 / 2), ϕ]

Series Expansions (4)

Taylor expansion for EllipticE:

Wolfram Language code: Series[EllipticE[m], {m, 0, 3}]

Plot the first three approximations for EllipticE around :

Wolfram Language code:

terms = Normal@Table[Series[EllipticE[m], {m, 0, n}], {n, 1, 3}];
Plot[{EllipticE[m], terms}, {m, -3, 1}]

Find series expansions at branch points:

Wolfram Language code: Series[EllipticE[m], {m, 1, 1}]

Series expansion for the elliptic integral of the second kind:

Wolfram Language code: Series[EllipticE[ϕ, m], {ϕ, 0, 10}]

Expand in series with respect to the modulus:

Wolfram Language code: Series[EllipticE[ϕ, m], {m, 0, 2}]

EllipticE can be applied to a power series:

Wolfram Language code: EllipticE[m + (m^2/2) + (m^3/3) + O[m]^4]

Wolfram Language code: EllipticE[x + (x^2/2) + (x^3/3) + O[x]^4, m]

Integral Transforms (2)

Compute the Laplace transform using LaplaceTransform:

Wolfram Language code: LaplaceTransform[EllipticE[-t], t, s]

HankelTransform:

Wolfram Language code: HankelTransform[EllipticE[-r], r, s]

Function Representations (6)

The definition of the elliptic integral of the second kind:

Wolfram Language code: Integrate[Sqrt[1 - m Sin[θ] ^ 2], {θ, 0, ϕ}, Assumptions -> ϕ ≥ 0]

Complete elliptic integral is a partial case of the elliptic integral of the second kind:

Wolfram Language code: EllipticE[(π/2), m]

Relation to other elliptic integrals:

Wolfram Language code: (1 - m)EllipticPi[m, m]//FullSimplify

Represent in terms of MeijerG using MeijerGReduce:

Wolfram Language code: MeijerGReduce[EllipticE[m], m]

Wolfram Language code: Activate[%]

EllipticE can be represented as a DifferentialRoot:

Wolfram Language code: DifferentialRootReduce[EllipticE[m], m]

TraditionalForm formatting:

Wolfram Language code:

EllipticE[m]//TraditionalForm
EllipticE[ϕ, m]//TraditionalForm

Applications (10)

Compute elliptic integrals:

Wolfram Language code: ∫Sqrt[ x^4 - 1]ⅆ x

Wolfram Language code: ∫Sqrt[x^3 - x^2 + 2 / 9 x]ⅆ x

Plot an incomplete elliptic integral over the complex plane:

Wolfram Language code: Plot3D[Im[EllipticE[x + I y, 1 / 2]], {x, -2Pi, 2Pi}, {y, -3, 3}]

Perimeter length of an ellipse:

Wolfram Language code:

x[t_] := a Cos[t];
y[t_] := b Sin[t];

Wolfram Language code: 4Integrate[Sqrt[Derivative[1][x][t]^2 + Derivative[1][y][t]^2], {t, 0, (Pi/2)}, Assumptions -> a > 0∧b > 0]

Use ArcLength to obtain the perimeter:

Wolfram Language code: ArcLength[Circle[{0, 0}, {a, b}]]

Series expansion for almost equal axes lengths:

Wolfram Language code: Series[%, {b, a, 6}]

Compare with an approximation by Ramanujan:

Wolfram Language code: Series[Pi (3a + 3b - Sqrt[(a + 3b)(b + 3a)]), {b, a, 6}]//Simplify[#, Assumptions -> a > 0]&

Arc length of a hyperbola as a function of the angle of a point on the hyperbola:

Wolfram Language code:

x[t_] := a Cosh[t]
y[t_] := b Sinh[t]

Wolfram Language code:

Integrate[Sqrt[x'[t] ^ 2 + y'[t] ^ 2], {t, 0, ArcTanh[(a /b)Tan[ϕ]]}, Assumptions -> a > 0 && b > 0 && b ^ 2 > a ^ 2Tan[ϕ] ^ 2]

Plot the arc length as a function of the angle:

Wolfram Language code: Plot[% /. {a -> 2, b -> 2}, {ϕ, -1, 1}]

Vector potential of a ring current in cylindrical coordinates:

Wolfram Language code: A = 2Integrate[(Cos[φ]/Sqrt[z^2 + r^2 + R^2 - 2 r R Cos[φ]]), {φ, 0, Pi}, Assumptions -> r > 0∧R > 0∧z > 0]

The vertical and radial components of the magnetic field:

Wolfram Language code: Bz = (1/r)D[r A, r]//Simplify

Wolfram Language code: Br = -D[A, z]//Simplify

Plot magnitude of the magnetic field:

Wolfram Language code: Plot3D[Evaluate[Sqrt[Br^2 + Bz^2] /. R -> 1], {r, -(3/2), (3/2)}, {z, -1, 1}]

Inductance of a solenoid of radius r and length a with fixed numbers of turns per unit length:

Wolfram Language code: 2r^2 a Integrate[Sinc[(x/2)]^2 BesselI[1, (x r/a)] BesselK[1, (x r/a)], {x, 0, Infinity}, Assumptions -> r > 0 && a > 0]

Inductance per unit length of the infinite solenoid:

Wolfram Language code: Limit[% / a, a -> Infinity]

Calculate the surface area of a triaxial ellipsoid:

Wolfram Language code:

area[{a_, b_, c_}] := With[{m = (a^2(b^2 - c^2)/b^2(a^2 - c^2)), θ = ArcSin[Sqrt[1 - (c^2/a^2)]]}, 2 π(c^2 + b Sqrt[a^2 - c^2] EllipticE[θ, m] + (b c^2 /Sqrt[a^2 - c^2])EllipticF[θ, m])] /; a > b > c;

The area of an ellipsoid with half axes 3, 2, 1:

Wolfram Language code: area[{3, 2, 1}]//N

Calculate the area by integrating the differential surface elements:

Wolfram Language code:

NIntegrate[Evaluate[Sin[θ]Sqrt[b^2c^2Cos[ϕ]^2Sin[θ]^2 + a^2c^2Sin[ϕ]^2Sin[θ]^2 + a^2b^2Cos[θ]^2] /. {a -> 3, b -> 2, c -> 1}], {ϕ, 0, 2Pi}, {θ, 0, Pi}]

Parametrization of a Mylar balloon (two flat sheets of plastic sewn together at their circumference and then inflated):

Wolfram Language code:

x[u_, v_] := (Cos[v]/Sqrt[Cosh[2u]])
y[u_, v_] := (Sin[v]/Sqrt[Cosh[2u]])
z[u_, v_] := With[{f = ArcSin[(Sqrt[2]Sinh[u]/Sqrt[Cosh[2u]])]}, Sqrt[2](EllipticE[f, (1/2)] - (1/2)EllipticF[f, (1/2)])]

Plot the resulting balloon:

Wolfram Language code: ParametricPlot3D[{x[u, v], y[u, v], z[u, v]}, {v, 0, 2Pi}, {u, -8, 8}, PlotRange -> All]

Calculate the ratio of the main curvatures:

Wolfram Language code:

Module[{h, g}, h[u_] = x[u, v] / Cos[v];g[u_] = z[u, v];
(((g''[u]h'[u] - g'[u]h''[u]/(g'[u]^2 + h'[u]^2)^3 / 2))/((g'[u]/h[u]Sqrt[g'[u]^2 + h'[u]^2])))//Simplify]

Express the radius of the original sheets in terms of the radius of the inflated balloon:

Wolfram Language code: Module[{h, g}, h[u_] = x[u, v] / Cos[v];g[u_] = z[u, v];Integrate[Sqrt[h'[u]^2 + g'[u]^2]//Simplify, {u, 0, ∞}]]

Wolfram Language code: N[%, $MachinePrecision]

Parametrize an ellipse using EllipticE :

Wolfram Language code:

ellipse[ϕ_, {a_, b_}] := With[{u = a  EllipticE[ϕ, 1 - (b^2/a^2)]}, {a  JacobiSN[u, Sqrt[1 - (b^2/a^2)]], b JacobiCN[u, Sqrt[1 - (b^2/a^2)]]}]

Plot using elliptic parametrization and circular parametrization:

Wolfram Language code: With[{b = 1 / 2, a = 2}, ParametricPlot[Evaluate[{{a Cos[ϕ], b Sin[ϕ]}, ellipse[ϕ, {a, b}]}], {ϕ, -Pi, Pi}]]

Define the Halphen constant using elliptic integrals [MathWorld]:

Wolfram Language code:

SetAttributes[HalphenConstant, Constant];
HalphenConstant/:N[HalphenConstant, wp_] := N[EllipticNomeQ[Root[{EllipticK[#] - 2EllipticE[#]&, 0.82611476598497033617737323860075640603409051645331}]], wp]

Find the extended precision value:

Wolfram Language code: x = N[HalphenConstant, 50]

Verify that it is zero of the function :

Wolfram Language code: Sum[(2k + 1)^2(-x)^k(k + 1) / 2, {k, 0, 50}]

Properties & Relations (6)

EllipticE[ϕ,m] is real‐valued for real argument subject to the following conditions:

Wolfram Language code: FunctionDomain[EllipticE[ϕ, m], {ϕ, m}, Reals]

For real arguments, if , then for :

Wolfram Language code:

With[{m = 1 / 3}, {ParametricPlot[{ϕ, EllipticE[ϕ, m]}, {ϕ, -2Pi, 2Pi}, PlotStyle -> Thick], ParametricPlot[{JacobiAmplitude[u, m], JacobiEpsilon[u, m]}, {u, -4 EllipticK[m], 4EllipticK[m]}, PlotStyle -> Directive[Dashed, Orange]]}]

Wolfram Language code: Show[%, ImageSize -> Tiny]

For , this is only true for :

Wolfram Language code:

With[{m = 4}, {ParametricPlot[{ϕ, EllipticE[ϕ, m]}, {ϕ, -ArcSin[m^-1 / 2], ArcSin[m^-1 / 2]}, PlotStyle -> Thick], ParametricPlot[{JacobiAmplitude[u, m], JacobiEpsilon[u, m]}, {u, -(1/Sqrt[m])EllipticK[1 / m], (1/Sqrt[m])EllipticK[1 / m]}, PlotStyle -> Directive[Dashed, Orange]]}]

Wolfram Language code: Show[%, ImageSize -> Tiny]

Expand special cases:

Wolfram Language code: EllipticE[ArcCsc[Sqrt[m]], m]//FunctionExpand

Expand special cases under argument restrictions:

Wolfram Language code: EllipticE[z, 1]//FunctionExpand

Wolfram Language code: FunctionExpand[%, 0 < z < Pi / 2]

Numerically find a root of a transcendental equation:

Wolfram Language code: FindRoot[EllipticE[z, 2]^3 + EllipticE[z, 2] + z == 2, {z, I}]

Limits on branch cuts:

Wolfram Language code: Limit[EllipticE[Pi / 2 + ε I, 2], ε -> 0, Direction -> -1]

Wolfram Language code: Limit[EllipticE[Pi / 2 + ε I, 2], ε -> 0, Direction -> +1]

EllipticE is automatically returned as a special case for some special functions:

Wolfram Language code:

{HypergeometricPFQ[{-(1/2), (1/2)}, {1}, z], MeijerG[{{(1/2), (3/2)}, {}}, {{0}, {0}}, -z], MeijerG[{{0, 1}, {}}, {{-(1/2), (1/2)}, {}}, z], EllipticPi[z, (π/2), z], EllipticE[(π/2), z]}

Possible Issues (1)

Different conventions exist for the second argument:

Wolfram Language code: Integrate[Sqrt[1 - k ^ 2 Sin[t] ^ 2], {t, 0, z}, GenerateConditions -> False]

Wolfram Language code:

Integrate[Sqrt[(1 - m t ^ 2) / (1 - t ^ 2)], {t, 0, z}, GenerateConditions -> False]//Simplify[#, 0 < m < 1 && 0 < z < 1]&

Neat Examples (4)

Nested derivatives and integrals:

Wolfram Language code: NestList[D[#, x]&, EllipticE[x, m], 4]//TraditionalForm

Wolfram Language code: NestList[Integrate[#, x]&, EllipticE[x], 6]//FunctionExpand//TraditionalForm

Plot EllipticE at integer points:

Wolfram Language code: ArrayPlot[Table[Mod[Round[Abs[EllipticE[x y, 0.3]]], 2], {x, -50, 50}, {y, -50, 50}]]

Calculate EllipticE through an analytically continued Taylor series:

Wolfram Language code: ℱ[n_, z_] = (π/2) Underoverscript[∑, k = 0, n](Pochhammer[-(1/2), k] Pochhammer[(1/2), k] z^k/k!^2)

Wolfram Language code: EllipticE[0.6 - 0.2I]

Wolfram Language code: Plot[{Re@ℱ[n, 0.6 - 0.2I], Im@ℱ[n, 0.6 - 0.2I]}, {n, 0, 5}]

Riemann surface of :

Wolfram Language code:

Show[Plot3D[Evaluate[Table[Im[EllipticE[x + I y] + j 2 I (EllipticK[1 - (x + I y)] - EllipticE[1 - (x + I y)])], {j, -2, 2}]], {x, -9, 9}, {y, ##}, ClippingStyle -> None, PlotStyle -> Opacity[0.6], Mesh -> False, BoxRatios -> {1, 1, 1}, MaxRecursion -> 5, PlotRange -> {All, All, {-9, 9}}]&@@@{{-9, -10 ^ -6}, {10 ^ -6, 9}}]

Top

More Learning

Tech Support

Wolfram Solutions

Wolfram Solutions For Education

Get Started

Grow Your Skills

Work with Us

Educational Programs for Adults

Educational Programs for Youth

Read

EllipticE

Details

Examples

Basic Examples (5)

Scope (41)

Numerical Evaluation (5)

Specific Values (4)

Visualization (3)

Function Properties (10)

Differentiation (4)

Integration (3)

Series Expansions (4)

Integral Transforms (2)

Function Representations (6)

Applications (10)

Properties & Relations (6)

Possible Issues (1)

Neat Examples (4)

Text

CMS

APA

BibTeX

BibLaTeX

EllipticE

Details

Examples

Basic Examples (5)

Scope (41)

Numerical Evaluation (5)

Specific Values (4)

Visualization (3)

Function Properties (10)

Differentiation (4)

Integration (3)

Series Expansions (4)

Integral Transforms (2)

Function Representations (6)

Applications (10)

Properties & Relations (6)

Possible Issues (1)

Neat Examples (4)

See Also

Tech Notes

Related Guides

Related Links

History

Text

CMS

APA

BibTeX

BibLaTeX
