RegionDifference

RegionDifference[reg1,reg2]

gives the difference of the regions reg1 and reg2.

Details and Options

Examples

open all close all

Basic Examples  (2)

Difference of two disks:

Wolfram Language code: RegionDifference[Disk[{0, 0}, 2], Disk[{3, 0}, 2]];

Visualize it:

Wolfram Language code: Region[%]

Difference of two MeshRegion objects:

Wolfram Language code: RegionDifference[[image], [image]]

Scope  (16)

Special Regions  (6)

For some regions, the difference is computed explicitly:

Wolfram Language code: Subscript[ℛ, 1] = Triangle[{{0, 0}, {1, 0}, {0, 1}}]; Subscript[ℛ, 2] = Disk[{3, 0}, 1];
Wolfram Language code: Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

The regions are disjoint:

Wolfram Language code: Graphics[{Opacity[0.5], {Red, Subscript[ℛ, 1]}, {Green, Subscript[ℛ, 2]}, {Yellow, Subscript[ℛ, 3]}}]

Here the difference is empty:

Wolfram Language code: Subscript[ℛ, 1] = Cuboid[]; Subscript[ℛ, 2] = Ball[{0, 0, 0}, 2];
Wolfram Language code: Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

The cuboid is contained in the ball:

Wolfram Language code: Graphics3D[{Opacity[0.5], {Red, Subscript[ℛ, 1]}, {Green, Subscript[ℛ, 2]}}]

A difference of Line regions:

Wolfram Language code: ℛ = RegionDifference[Line[{{1}, {4}}], Line[{{2}, {3}}]];

Visualize it:

Wolfram Language code: Region[ℛ]

A difference of Polygon regions:

Wolfram Language code: Subscript[ℛ, 1] = Polygon[{{0, 0}, {3, -1}, {2, 0}, {3, 1}}]; Subscript[ℛ, 2] = Polygon[{{5, 0}, {2, 1}, {3, 0}, {2, -1}}];
Wolfram Language code: ℛ = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];

Visualize it:

Wolfram Language code: Region[ℛ]

A difference of two Cuboid regions:

Wolfram Language code: ℛ = RegionDifference[Cuboid[], Cuboid[{0.5, 0.5, 0.5}]];

Visualize it:

Wolfram Language code: Region[ℛ]

A difference of regions with different RegionDimension:

Wolfram Language code: ℛ = RegionDifference[Circle[{0, 0}, 1], Disk[{1, 0}, 1]];

Visualize it:

Wolfram Language code: Region[ℛ]

Formula Regions  (2)

A difference of ImplicitRegion objects is an ImplicitRegion:

Wolfram Language code: Subscript[ℛ, 1] = ImplicitRegion[x ≤ 1, {x}]; Subscript[ℛ, 2] = ImplicitRegion[x ≥ -1, {x}];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

2D:

Wolfram Language code: Subscript[ℛ, 1] = ImplicitRegion[x^2 + y^2 ≤ 1, {x, y}]; Subscript[ℛ, 2] = ImplicitRegion[x^2 + (y - 1)^2 ≤ 1, {x, y}];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

3D:

Wolfram Language code: Subscript[ℛ, 1] = ImplicitRegion[x^2 + y^2 + z^2 ≤ 1, {x, y, z}]; Subscript[ℛ, 2] = ImplicitRegion[(x - 1)^2 + y^2 + z^2 ≤ 1, {x, y, z}];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

nD:

Wolfram Language code: Subscript[ℛ, 1] = ImplicitRegion[x^2 + y^2 + z^2 + u^2 + v^2 ≤ 1, {x, y, z, u, v}]; Subscript[ℛ, 2] = ImplicitRegion[(x - 1)^2 + y^2 + z^2 + u^2 + v^2 ≤ 1, {x, y, z, u, v}];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

A difference of ParametricRegion objects:

Wolfram Language code: Subscript[ℛ, 1] = ParametricRegion[{u, v}, {{u, 0, 2}, {v, 0, 2}}]; Subscript[ℛ, 2] = ParametricRegion[{u + 1, v + 1}, {{u, 0, 2}, {v, 0, 2}}];
Wolfram Language code: ℛ = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];

Visualize it:

Wolfram Language code: Region[ℛ]

Mesh Regions  (2)

A difference of BoundaryMeshRegion objects is a BoundaryMeshRegion:

Wolfram Language code: RegionDifference[[image], [image]]
Wolfram Language code: BoundedRegionQ[%]

2D:

Wolfram Language code: RegionDifference[[image], [image]]
Wolfram Language code: BoundedRegionQ[%]

3D:

Wolfram Language code: RegionDifference[[image], [image]]
Wolfram Language code: BoundedRegionQ[%]

A difference of full-dimensional MeshRegion objects is a MeshRegion:

Wolfram Language code: RegionDifference[[image], [image]]
Wolfram Language code: MeshRegionQ[%]

2D:

Wolfram Language code: RegionDifference[[image], [image]]
Wolfram Language code: MeshRegionQ[%]

3D:

Wolfram Language code: RegionDifference[[image], [image]]
Wolfram Language code: MeshRegionQ[%]

Derived Regions  (2)

A difference of BooleanRegion objects:

Wolfram Language code: Subscript[ℛ, 1] = BooleanRegion[Or, {Triangle[{{0, 0}, {2, 3}, {-2, 3}}], Triangle[{{0, 2}, {2, -1}, {-2, -1}}]}]; Subscript[ℛ, 2] = BooleanRegion[And, {Triangle[{{0, 0}, {2, 3}, {-2, 3}}], Triangle[{{0, 2}, {2, -1}, {-2, 2}}]}];
Wolfram Language code: ℛ = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];

Visualize it:

Wolfram Language code: Region[ℛ]

A difference of TransformedRegion objects:

Wolfram Language code: Subscript[ℛ, 1] = TransformedRegion[Cuboid[], RotationTransform[Pi / 8, {1, 0, 0}]]; Subscript[ℛ, 2] = TransformedRegion[Cuboid[], RotationTransform[Pi / 8, {0, 1, 0}]];
Wolfram Language code: ℛ = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];

Visualize it:

Wolfram Language code: Region[ℛ]

CSG Regions  (2)

A difference of CSGRegion objects in 2D:

Wolfram Language code: Subscript[ℛ, 1] = CSGRegion[{Disk[], Rectangle[]}]; Subscript[ℛ, 2] = CSGRegion[{Disk[{0, 0}, 1 / 2], Rectangle[{0, 0}, {1 / 2, 1 / 2}]}];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

A difference of CSGRegion objects in 3D:

Wolfram Language code: Subscript[ℛ, 1] = CSGRegion[{Cube[1.5], Cube[{0, 0, 1}, 3 / 4]}]; Subscript[ℛ, 2] = CSGRegion[{Cylinder[{{0, 0, -2}, {0, 0, 2}}, 1 / 3], Cylinder[{{-2, 0, 0}, {2, 0, 0}}, 1 / 2]}];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Subdivision Regions  (2)

A difference of SubdivisionRegion objects in 2D:

Wolfram Language code: Subscript[ℛ, 1] = SubdivisionRegion[Rectangle[]]; Subscript[ℛ, 2] = SubdivisionRegion[Rectangle[{1 / 2, 1 / 2}]];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

A difference of SubdivisionRegion objects in 3D:

Wolfram Language code: Subscript[ℛ, 1] = SubdivisionRegion[Cube[1]]; Subscript[ℛ, 2] = SubdivisionRegion[Tetrahedron[4]];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Applications  (4)

Difference of regions:

Wolfram Language code: {Subscript[ℛ, 1], Subscript[ℛ, 2]} = {[image], [image]};
Wolfram Language code: Multicolumn[Table[RegionDifference[Subscript[ℛ, 1], TransformedRegion[Subscript[ℛ, 2], TranslationTransform[{0, 0, t}]]], {t, 0, 2.5, 0.5}], 3, Appearance -> "Horizontal" ]

Define a disk annulus as the difference of two disks:

Wolfram Language code: annulus = RegionDifference[Disk[{0, 0}, 2], Disk[{0, 0}, 1]];
Wolfram Language code: Region[annulus]

The area is the difference of areas:

Wolfram Language code: Area[annulus]
Wolfram Language code: Area[Disk[{0, 0}, 2]] - Area[Disk[{0, 0}, 1]]

Define a ball shell (sometimes called spherical shell) as the generalization of an annulus to 3D:

Wolfram Language code: shell = RegionDifference[Ball[{0, 0, 0}, 2], Ball[{0, 0, 0}, 1]];
Wolfram Language code: RegionPlot3D[shell, PlotPoints -> 40, PlotStyle -> Opacity[0.5]]

The volume is the difference of volumes:

Wolfram Language code: Volume[shell]
Wolfram Language code: Volume[Ball[{0, 0, 0}, 2]] - Volume[Ball[{0, 0, 0}, 1]]

Create illusory contours:

Wolfram Language code: disks = RegionUnion[Disk[{0, 0}, 2], Disk[{6, 0}, 2], Disk[{3, 5}, 2]];
Wolfram Language code: RegionDifference[disks, Triangle[{{0, 0}, {6, 0}, {3, 5}}]]//Region

Properties & Relations  (5)

A point p belongs to RegionDifference[reg1,reg2] if it belongs to reg1 but not reg2:

Wolfram Language code: Subscript[ℛ, 1] = Disk[{0, 0}, 2]; Subscript[ℛ, 2] = Disk[{0, 3}, 2]; Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];

Use RegionMember to test membership:

Wolfram Language code: p = {0, 0};
Wolfram Language code: RegionMember[Subscript[ℛ, 3], p] == RegionMember[Subscript[ℛ, 1], p]∧ !RegionMember[Subscript[ℛ, 2], p]

RegionDifference is a Boolean combination ¬#2∧#1 of two regions:

Wolfram Language code: {Subscript[ℛ, 1], Subscript[ℛ, 2]} = {[image], [image]};
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]] == BooleanRegion[¬#2∧#1&, {Subscript[ℛ, 1], Subscript[ℛ, 2]}]

RegionSymmetricDifference can be found using RegionUnion and RegionDifference:

Wolfram Language code: {Subscript[ℛ, 1], Subscript[ℛ, 2]} = {[image], [image]};
Wolfram Language code: RegionSymmetricDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]] == RegionUnion[RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]], RegionDifference[Subscript[ℛ, 2], Subscript[ℛ, 1]]]

The RegionDimension of a difference is at most that of the first input:

Wolfram Language code: Subscript[ℛ, 1] = Disk[{0, 0}, 1]; Subscript[ℛ, 2] = Disk[{1, 0}, 1]; Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];
Wolfram Language code: RegionDimension[Subscript[ℛ, 3]] == RegionDimension[Subscript[ℛ, 1]]

It can be less, however:

Wolfram Language code: Subscript[ℛ, 1] = Disk[{0, 0}, 1]; Subscript[ℛ, 2] = ImplicitRegion[y > 0∨y < 0, {x, y}]; Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];

This difference is a line segment, and thus has dimension 1:

Wolfram Language code: RegionDimension[Subscript[ℛ, 3]]

If two regions are disjoint, the RegionMeasure of their difference is that of the first input:

Wolfram Language code: Subscript[ℛ, 1] = Disk[{0, 0}, 1]; Subscript[ℛ, 2] = Disk[{3, 0}, 1]; Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];
Wolfram Language code: RegionMeasure[Subscript[ℛ, 3]] == RegionMeasure[Subscript[ℛ, 1]]

If they overlap, you must subtract the measure of the RegionIntersection:

Wolfram Language code: Subscript[ℛ, 1] = Disk[{0, 0}, 1]; Subscript[ℛ, 2] = Disk[{1, 0}, 1]; Subscript[ℛ, 3] = RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]];
Wolfram Language code: RegionMeasure[Subscript[ℛ, 3]] == RegionMeasure[Subscript[ℛ, 1]] - RegionMeasure[RegionIntersection[Subscript[ℛ, 1], Subscript[ℛ, 2]]]

Possible Issues  (1)

Difference is defined only for regions with the same RegionEmbeddingDimension:

Wolfram Language code: Subscript[ℛ, 1] = Disk[]; Subscript[ℛ, 2] = Ball[{0, 0, 1}, 1];
Wolfram Language code: RegionDifference[Subscript[ℛ, 1], Subscript[ℛ, 2]]

Neat Examples  (1)

The difference of two spiral polygons:

Wolfram Language code: RegionDifference[[image], [image]]
