InverseTransformedRegion

InverseTransformedRegion[reg,f,n]

represents the inverse transformed region , where reg is a region and f is a function.

Details and Options

Examples

open all close all

Basic Examples  (2)

The inverse transform of a rotated rectangle:

Wolfram Language code: ℛ = InverseTransformedRegion[Rectangle[], RotationTransform[π / 4]]
Wolfram Language code: Region[ℛ]
Wolfram Language code: Area[ℛ]

The inverse image of a disk through :

Wolfram Language code: ℛ = InverseTransformedRegion[Disk[], {Indexed[#, 1] Indexed[#, 2], Indexed[#, 1] + Indexed[#, 2]}&, 2];
Wolfram Language code: Region[ℛ]

Scope  (24)

Special Regions  (9)

Some inverse transformed regions are computed explicitly:

Wolfram Language code: ℛ = InverseTransformedRegion[Disk[], ShearingTransform[Pi / 4, {1, 0}, {0, 1}]]

Visualize the transformation:

Wolfram Language code: Region[ℛ]

The inverse image of the unit cuboid through a linear-fractional transformation:

Wolfram Language code: Subscript[ℛ, 1] = Cuboid[]; 𝒯 = TransformationFunction[{{7, 5, -2, 3}, {3, -8, 9, 4}, {-8, 3, 1, -6}, {1, 0, 0, 5}}]; ℛ = InverseTransformedRegion[Subscript[ℛ, 1], 𝒯]

Visualize the transformation:

Wolfram Language code: Region[ℛ]

The inverse transform of a translated unit Disk:

Wolfram Language code: ℛ = InverseTransformedRegion[Disk[], TranslationTransform[{2, 3}]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a sheared unit Rectangle:

Wolfram Language code: ℛ = TransformedRegion[Rectangle[], ShearingTransform[30Degree, {1, 0}, {0, 1}]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a rotated Triangle:

Wolfram Language code: ℛ = TransformedRegion[Triangle[], RotationTransform[π / 3]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a scaled Circle:

Wolfram Language code: ℛ = InverseTransformedRegion[Circle[], ScalingTransform[2., {1, 1}]];
Wolfram Language code: Region[ℛ]

The inverse image of the unit cube through a rotation transform:

Wolfram Language code: ℛ = InverseTransformedRegion[Cuboid[{0, 0, 0}, {1, 1, 1}], RotationTransform[Pi / 3, {1, 1, 1}], 3]

Visualize it:

Wolfram Language code: Region[ℛ]

An inverse transform of a rectangle by a linear transformation :

Wolfram Language code: ℛ = InverseTransformedRegion[Rectangle[], Function[p, {p[[1]] + p[[2]], p[[1]] - p[[2]]}]]

Visualize it:

Wolfram Language code: Region[ℛ]

Map points from a Triangle embedded in 2D into 3D by a nonlinear transformation :

Wolfram Language code: Subscript[ℛ, 1] = Triangle[{{0, 0}, {0, 1}, {1, 0}}];
Wolfram Language code: ℛ = InverseTransformedRegion[Subscript[ℛ, 1], {Indexed[#, 1] ^ 2 + Indexed[#, 2] ^ 2, Indexed[#, 3]}&, 3];

Visualize it:

Wolfram Language code: Region[ℛ]

Formula Regions  (4)

The inverse transform of a sheared ParametricRegion:

Wolfram Language code: pr = ParametricRegion[{Sin[θ], Sin[2θ]}, {{θ, 0, 2π}}];
Wolfram Language code: ℛ = InverseTransformedRegion[pr, ShearingTransform[30Degree, {1, 0}, {0, 1}]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a rotated ParametricRegion:

Wolfram Language code: pr = ParametricRegion[{{s, (1 + t) s ^ 2 - t}, -1 ≤ s ≤ 1 && 0 ≤ t ≤ 1}, {s, t}];
Wolfram Language code: ℛ = InverseTransformedRegion[pr, RotationTransform[Pi / 4, {1, 1}]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a sheared ImplicitRegion:

Wolfram Language code: ir = ImplicitRegion[x ^ 2 - y ^ 2 ≤ 1, {x, y}];
Wolfram Language code: ℛ = InverseTransformedRegion[ir, ShearingTransform[30Degree, {1, 0}, {0, 1}]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a scaled ImplicitRegion:

Wolfram Language code: ir = ImplicitRegion[x^2 + y^2 + z^2 < 1 || (x + 1)^2 + y^2 + z^2 < 1, {x, y, z}];
Wolfram Language code: ℛ = InverseTransformedRegion[ir, ScalingTransform[{1, 1 / 2, 1 / 2}]]

Visualize it:

Wolfram Language code: Region[ℛ]

Mesh Regions  (2)

An inverse transform of BoundaryMeshRegion objects is a BoundaryMeshRegion:

Wolfram Language code: InverseTransformedRegion[[image], TranslationTransform[{1}]]
Wolfram Language code: BoundedRegionQ[%]

2D:

Wolfram Language code: InverseTransformedRegion[[image], ShearingTransform[30Degree, {1, 0}, {0, 1}]]
Wolfram Language code: BoundedRegionQ[%]

3D:

Wolfram Language code: InverseTransformedRegion[[image], RotationTransform[π / 3, {1, 0, 1}]]
Wolfram Language code: BoundedRegionQ[%]

An inverse transform of MeshRegion objects is a MeshRegion:

Wolfram Language code: InverseTransformedRegion[[image], TranslationTransform[{1}]]
Wolfram Language code: MeshRegionQ[%]

2D:

Wolfram Language code: InverseTransformedRegion[[image], ShearingTransform[30Degree, {1, 0}, {0, 1}]]
Wolfram Language code: MeshRegionQ[%]

3D:

Wolfram Language code: InverseTransformedRegion[[image], RotationTransform[π / 3, {1, 0, 1}]]
Wolfram Language code: MeshRegionQ[%]

Derived Regions  (5)

The inverse transform of a reflected TransformedRegion:

Wolfram Language code: tr = TransformedRegion[Cuboid[], ShearingTransform[30Degree, {1, 0, 0}, {0, 1, 1}]];
Wolfram Language code: ℛ = InverseTransformedRegion[tr, ReflectionTransform[{0, 1, 1}]]

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a rotated RegionDifference:

Wolfram Language code: rd = RegionDifference[Rectangle[{0, 0}], Disk[{1, 0}, 1 / 2]];
Wolfram Language code: ℛ = InverseTransformedRegion[rd, RotationTransform[π / 4]];

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a scaled RegionBoundary:

Wolfram Language code: rb = RegionBoundary[Polygon[{{0, 0}, {3, -1}, {2, 0}, {3, 1}}]];
Wolfram Language code: ℛ = InverseTransformedRegion[rb, ScalingTransform[2, {1, 1}]];

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a reflected RegionProduct:

Wolfram Language code: rp = RegionProduct[Disk[{0, 0}, 1], Line[{{0}, {1}}]];
Wolfram Language code: ℛ = InverseTransformedRegion[rp, ReflectionTransform[{1, 0, 1}]];

Visualize it:

Wolfram Language code: Region[ℛ]

The inverse transform of a RegionUnion by a nonlinear transformation :

Wolfram Language code: ru = RegionUnion[Disk[{0, 0}, 2], Disk[{3, 0}, 2]];
Wolfram Language code: r1 = InverseTransformedRegion[ru, Function[p, {p[[1]] p[[2]], p[[1]] + p[[2]]}]];

Visualize it:

Wolfram Language code: Region[r1]

Geographic Regions  (2)

InverseTransformedRegion works on polygons of geographic entities:

Wolfram Language code: ℛ = Polygon[["france"]];
Wolfram Language code: InverseTransformedRegion[ℛ, RotationTransform[Pi / 3, {1, 1, 0}]]
Wolfram Language code: Region[ℛ]

Polygons with GeoPosition:

Wolfram Language code: ℛ = Polygon[GeoPosition[{{{40.083441, -88.235716}, {40.083607, -88.257488}, {40.082603, -88.257149}, {40.076136999999996, -88.25740499999999}, {40.076178, -88.270888}, {40.076516, -88.271558}, {40.083686, -88.271512}, {40.083659999999995, -88.267046}, ... 33323}, {40.098112, -88.228687}, {40.095216, -88.228627}, {40.095179, -88.238547}, {40.094480999999995, -88.238546}, {40.094508999999995, -88.23267}, {40.094106, -88.232556}, {40.090666999999996, -88.232477}, {40.090741, -88.235745}}}]];
Wolfram Language code: Region[ℛ]
Wolfram Language code: InverseTransformedRegion[ℛ, RotationTransform[Pi / 3, {1, 1, 0}]]

Polygons with GeoGridPosition:

Wolfram Language code: ℛ = Polygon[GeoGridPosition[{{{-0.9950503945490105, 1.2366760550756015}, {-0.9952074890903578, 1.2369207053693891}, {-0.9952196732768064, 1.2369073327446167}, {-0.9953160063787643, 1.236848436956935}, {-0.9954141759436825, 1.2369993898475449}, {-0. ... 197645333103}, {-0.9949098578570917, 1.2368130881428654}, {-0.9948663952535768, 1.2367477711687371}, {-0.9948714472169538, 1.2367426500757825}, {-0.9949211061652593, 1.2367089232486177}, {-0.9949439717990124, 1.236746107097628}}}, "Bonne"]];
Wolfram Language code: Region[ℛ]
Wolfram Language code: 𝒯 = InverseTransformedRegion[ℛ, RotationTransform[Pi / 3]]
Wolfram Language code: Region[𝒯]

CSG Regions  (1)

The inverse transform of linear CSGRegion:

Wolfram Language code: InverseTransformedRegion[CSGRegion["Difference", {Rectangle[{-1, -1}, {1, 1}], Rectangle[{-1 / 2, -1 / 2}]}], ScalingTransform[{1, 3}]]

Nonlinear:

Wolfram Language code: InverseTransformedRegion[CSGRegion["Difference", {Disk[], Disk[{0, 0}, 1 / 2]}], ScalingTransform[{1, 3}]]

Subdivision Regions  (1)

The inverse transform of a SubdivisionRegion in 2D:

Wolfram Language code: InverseTransformedRegion[SubdivisionRegion[Rectangle[]], ScalingTransform[{1, 3}]]

3D:

Wolfram Language code: InverseTransformedRegion[SubdivisionRegion[Cube[]], ScalingTransform[{1, 1, 3}]]
